- Page 1 ISO 9001 CERTIFIED Junior’2001 DMX Lighting Controller 【User Manual】 Lite-Puter Enterprise Co., Ltd. Website: www.liteputer.com.tw E-mail: litecom@ms2.hinet.net Lite-Puter JUNIOR [EUM-C]...
-
Page 2: Table Of Contents
3-3-1 Channel chase setting ..........15 3-3-2 Change the start channel of channel chase....16 3-3-3 Setting of Chase+Back ..........17 3-3-4 Chase Fader..............18 3-3-5 SUB chase..............19 3-4 Auto Fade 3-4-1 Auto Fade of individual channel........20 3-4-2 Auto Fade of constant channels ........21 Lite-Puter JUNIOR [EUM-C]... -
Page 3: Chapter Ijunior Introduction
DIMMER DIMMER LOAD CONSOLE 1-2 Specifications Power supply DC 15V / 1A DMX signal input / output DMX512 / 1990 DMX signal connector XLR 5-pin Dimensions 262(L) x 132(W) x 45(H)mm Weight 3 Kg CE Certificate ET87S-09-058 Lite-Puter JUNIOR [EUM-C]... -
Page 4: Power On
The machine will auto memorize all the setting before switching off. 1-6 Notice Please fill the battery for 4 hours before using this machine the first time. The data will be lost if the machine is not turned on for 7 days. Lite-Puter JUNIOR [EUM-C]... -
Page 5: Chapter Ii Device Introduction
Set channel Set channel Adjust chase speed Adjust chase speed MASTER Master dimming key MASTER Master fader for dimming value Indicator of master dimming key for recording scenes FUNC Display all functions Channel setting Call out scenes Display Lite-Puter JUNIOR [EUM-C]... -
Page 6: Rear Panel Functions
F U N C . R EC . E N T ER S U B S U B S U B S U B 4 S U B S U B 6 M A S T E R Lite-Puter JUNIOR [EUM-C]... -
Page 7: Channel Value Setting
STEP-4：Push 【VR-1】 for direct output to CH-2; mean while LCD will show the output value. The dimming of CH-2 is 52% CH.SET －－－ CH 2 = 52% －－－－ STEP-5：In this example, start channel is CH.2. Please do the steps above to change the start channel. Lite-Puter JUNIOR [EUM-C]... -
Page 8: Individual Channel Value Setting
3-1-3 Output setting of constant channels EX.： How to set the output value to 50% from CH-5 to CH-20 at one time? STEP-1：Press【CH】key then the vernier will go to CH CH.SET －－－ CH 1 = 0% －－－－－ Lite-Puter JUNIOR [EUM-C]... - Page 9 STEP-7：Press【ENTER】key to output the value of CH5 ~ CH20. CH.SET 21 The display will show the next －－－ CH 21 = 0% channel automatically. －－－－－ STEP-8：Please do as above steps to finish the setting of other constant channels. Lite-Puter JUNIOR [EUM-C]...
-
Page 10: Clear The Setting Of All Channels
ISO 9001 CERTIFIED 3-1-4 Clear the setting of all channels 2 options： (1). Press 【CL】+【CH】at the same time to clear the value setting of all channels. (2). Push【MASTER VR】to the bottom then press the【MASTER】key. Lite-Puter JUNIOR [EUM-C]... -
Page 11: Scenes Setting
KEYIN SC 1 … 40 STEP-3：Press any key of【SUB1】~ [ SUB6]. Users pressed key SUB 1 to SAVE TO SUB1 enter the scene into SUB 1. ENT=SURE ANY=NO Yes：Press【ENTER】 No：Press any key STEP-4：Press【ENTER】key to save 1 set scene into SUB 1. Lite-Puter JUNIOR [EUM-C]... -
Page 12: Save Scenes To Scene1 ~ Scene40
If there is no data in Scene 5, then the LCD will display, Name: Keyin ENGLISH. STEP-4：Use number keys【0…9】to enter a scene name. Name: XY Users can name Scene 5 with 9 Keyin ENGLISH. English letters at most. Change/ Blank Lite-Puter JUNIOR [EUM-C]... -
Page 13: Call Out By Sub1 ~ Sub6
SETTING SUB MASTER STEP-3：Press【ENTER】key to execute the output of SUB1 ~ SUB6. SUB MASTER 1--6 LITE-PUTER CORP. Press any hot key of【SUB1】~ [ SUB6], then the data in SUB1 ~ SUB6 will output 100%. Users keep on pressing 【SUB1】key LOAD SUBSCENE 1 Push【VR1 ~VR6】, then the data will output 0--100%. -
Page 14: Call Out By Scene1 ~ Scene40
STEP-4：Press【ENTER】key to confirm. SUB MASTER 1--6 LITE-PUTER CORP. 1.) Push MASTER VR to 100% and SUB 1 VR to 50%, then the total output value of Scene 1 is 50%. 2.) Push MASTER VR to 50% and SUB 1 VR to 50%, then the total output value of Scene 1 is 25%. -
Page 15: Clear The Output Of Scene
－－－－－ STEP-6：Press【ENTER】key to save the new data. SUB MASTER 1--6 LITE-PUTER CORP. Now the data in Scene5 is [ CH6 = 60%，CH7-CH20=50%] P.S. If users wish to adjust the value of other channels in the same scene, please repeat this function from the first step. -
Page 16: Chase
MAS. is the abbreviation of MASTER － MAS.=100% 0.5sec STEP-4：Use number keys【0…9】or【▲、▼】keys to set the start channel. CH CHASE 1 － MAS.=100% 0.5sec STEP-5：Press【ENTER】key and the vernier will move to the next line. CH CHASE 1 － MAS.=100% 0.5sec Lite-Puter JUNIOR [EUM-C]... -
Page 17: Change The Start Channel Of Channel Chase
STEP-10：Press【ENTER】and the vernier will move to the chaser speed setting in the second line. CH CHASE 7 － MAS.=100% 1sec STEP-11：Use【▲】or【▼】key to adjust to a proper chaser speed. CH CHASE 7 － Users adjusted to 0.7sec. MAS.=100% 0.7sec Lite-Puter JUNIOR [EUM-C]... -
Page 18: Setting Of Chase+Back
When the value of one channel is lower than the value of the back scene, the output will be the higher one. Press【SUB】key and the corresponding channel will output 100%. After escaping from chaser mode, the chaser speed will be memorized automatically. Lite-Puter JUNIOR [EUM-C]... -
Page 19: Chase Fader
FADE FADE STEP-4：Press【▼】 FADE FADE STEP-5：Press【ENTER】 CH CHASE 1 － MAS.=100% 1sec STEP-6：Push 【VR1 ~ VR6】 to the desired value then the chaser from CH-1 to CH-6 will be fade mode. CH CHASE 1 － MAS.=100% 1sec Lite-Puter JUNIOR [EUM-C]... -
Page 20: Sub Chase 3
STEP-5：Use【▲】or【▼】key to adjust the chaser speed. SUB CHASE 3 － MAS.=100% 1sec STEP-6：Push【VR1 ~ VR6】to desired value to adjust the output . In this setting, users execute the chase with VR3 –VR6 and control the dimming value of the Lite-Puter JUNIOR [EUM-C]... -
Page 21: Auto Fade
STEP-4：Use【▲】or【▼】key to change the channel and AUTO FADE will execute automatically; or to use number keys【0--9】to enter the channel number then press 【ENTER】key to execute the auto fade. AUTO FADE 3sec User pressed 【▲】key once. CH 2 >65% －－－－－ Lite-Puter JUNIOR [EUM-C]... -
Page 22: Auto Fade Of Constant Channels
STEP-9：The the LCD will display as below, AUTO FADE 20sec CH 3 > 65% －－ － STEP-12：Then press【ENTER】key to execute the auto fade. Auto Fade speed and Chase speed are separate system, so different speed is allowed. Lite-Puter JUNIOR [EUM-C]...
