Summary of Contents for Lite-Puter DP-105R
- Page 1 User Manual DP-105R RS-485 Isolator DP-105R [EUM-C]...
-
Page 2: Table Of Contents
INDEX 1 INTRODUCTION .............................. 2 ............................... 2 EATURE ............................. 2 PECIFICATION ............................2 IMENSION ............................3 UNCTION ..........................4 YSTEM IAGRAM LIMITED WARRANTY ............................6 DP-105R [EUM-C]... -
Page 3: Introduction
Power supply: the power is supplied by RS-485 port (DC 12V). Protocol: RS-485 (DMX,EDX) Signal connector:4 pin green terminal x 2 Dimension: 66( W ) x 54( H ) x 23( D ) mm Weight: 128g 1-3 Dimension 54mm 66mm DP-105R [EUM-C]... -
Page 4: Function
1-4 Function 1. 4pin green terminal，RS-485 port (supply the power to DP-105R, DC 12V) DMX input port 2. 4pin green terminal，RS-485 port DMX output port Please note: GND of ECP-105R is isolate between the two 4pin green terminals About EDX cable line: The digital signal wiring is basically the same as RS-485 wiring. -
Page 5: System Diagram
1-5 System Diagram DP-105R [EUM-C]... - Page 6 DP-105R [EUM-C]...
-
Page 7: Limited Warranty
Other Lite-Puter or non-Lite-Puter products or devices offered, packaged, or sold with the product. 5. Lite-Puter does not warrant that the product will operate without interruption or free of error. World Headquarters： ： ： ：...
