Note: The Base configuration of the SmartView
Synergy does not permit the attachment of a LCD
Screen or Fixed Front Control panel. Users must
connect their own LCD screen and attach a Remote
Control panel.
1.5.2 Rear panel
1
Power connector
2
USB maintenance port
3
Remote control panel connector
4
TV OUT connector
5
VGA OUT connector
6
VGA IN connector
1
2 3
4
5
6
7
