Summary of Contents for Humanware SmartView Versa+

  • Page 2: Table Of Contents

    SmartView Versa+ User Manual Table of contents Overview..........1 What’s in the box? ......2 Getting to know your SmartView Versa+ ..3 Getting started ........5 Inserting the battery ......5 Charging the battery ......6 Install SD card ........7 Install neck cord .........8 Using hold button……………………...10 Turning power on/off ......11 Using SmartView Versa+ as an electronic magnifier ..........11...
  • Page 3 SmartView Versa+ User Manual menu..........19 3.Use Left and Right buttons to change menu display mode......20 4.Use Up and Down buttons to change functions……………………………….21 5.Use OK button…...………………..21 6.Using Movie mode......22 7.Using Playback mode.....23 8.Using Music mode ......25 9.Using the Recorder mode ....27 10.System Setup ......29 Computer Software Installation....30 Connect to computer......31...

  • Page 4: Smartview Versa+ User Manual

    SmartView Versa+ User Manual Overview SmartView Versa+ is a lightweight handheld electronic magnifier with a large 4.3” widescreen display. provides magnification from 5x-15x, five viewing modes, as well as the ability to save images. The SmartView Versa+ also lets you listen to music, make recordings and watch movies.

  • Page 5: What's In The Box

    The SmartView Versa+ package contains the following: Detachable SmartView Versa+ neck cord USB cable Protective Video cable carrying case User manual Rechargeable AC power Earphones lithium battery adapter CD-ROM Writing Stand If any items are missing from your package, please contact HumanWare. Page 2...

  • Page 6: Getting To Know Your Smartview Versa

    SmartView Versa+ User Manual Getting to know your SmartView Versa+ 1. 4.3” widescreen display 2. Charging indicator light 3. Menu button 4. Arrow and OK buttons 5. SD card slot 6. Earphone/Video output jack 7. Return button 8. Crosshair Page 3...
  • Page 7 SmartView Versa+ User Manual 9. Power jack 10. Camera 11. Battery slot 12. Speaker 13. USB 14. Cord slot 15. Power switch Page 4...

  • Page 8: Getting Started

    SmartView Versa+ User Manual 16. Hold switch 17. Microphone 18. Freeze button 19. Foldout handle Getting started Inserting the battery Insert the battery as follows: 1. Turn the unit so that the back is facing 2. Press and slide open the battery. 3.

  • Page 9: Charging The Battery

    SmartView Versa+ User Manual Charging the battery - The battery should be charged prior to using the Versa+ for the first time. - Connect the adapter supplied with the unit to the power jack and plug the adapter into an AC outlet. The power LED indicator on the topside will turn red while charging.

  • Page 10: Install Sd Card

    Insertion and removal of the SD card should only be done with the unit turned off. * SD card is not included in the package; purchase from HumanWare or your distributor. Page 7...

  • Page 11: Install Neck Cord

    SmartView Versa+ User Manual Install neck cord Page 8...

  • Page 12: Using Hold Button

    SmartView Versa+ User Manual - Insert the small loop on the end of the cord under the pin in the cord slot as shown. - Pull the other end of the strap through the loop and tighten. Using Hold button Hold - Slide the Hold switch to the left to lock buttons.

  • Page 13: Turning Power On/Off

    SmartView Versa+ User Manual Turning power off/on Power - To turn on the Versa+, slide the Power switch to the left as shown in the diagram. - Slide the Switch again to turn off the unit. - The unit will automatically shut down after a period of 3 minutes of inactivity to preserve battery power.

  • Page 14: Using Smartview Versa+ As An Electronic Magnifier

    SmartView Versa+ User Manual Using SmartView Versa+ as an electronic magnifier Enter magnifier mode Switch the power on, SmartView Versa+ will automatically enter magnifier mode. Power Adjusting the Magnification Zoom In Zoom Out Page 11...
  • Page 15 SmartView Versa+ User Manual - Press the Up arrow button to zoom in, and press the Down arrow button to zoom out. SmartView Versa+ allows you to select up to 6 magnification levels. - Lifting the unit off the material will decrease the size of viewed material.

  • Page 16: Change Display Modes

    SmartView Versa+ User Manual Change display modes. Change Mode White Text Black Text Yellow Text Yellow Text Press the Right and Left arrow buttons to cycle through the viewing Page 13...

  • Page 17: Freeze

    SmartView Versa+ User Manual modes： - full color mode - high contrast white text on black background mode. - high contrast black text on white background mode. - high contrast yellow text on blue background mode. - high contrast yellow text on black background mode.

  • Page 18: Save Image

    SmartView Versa+ User Manual - Press the Freeze button to freeze the image on the screen. - Press the Freeze button again to release screen. 5. Save image OK button - Use Freeze button to capture an image. - Press the OK button. - Use the buttons to select “YES”...

  • Page 19: Turn Off Led Lighting

    SmartView Versa+ User Manual mode. 6. Turn off LED lighting OK button - Press the OK button to turn off/on LED lighting. This will reduce glare on glossy material or reflective surfaces such as a computer screen. Page 16...

  • Page 20: Writing Stand

    SmartView Versa+ User Manual 7. Writing Stand - Put the unit on the writing stand. - The camera end of the Versa+ will be raised off the table so that you may write underneath. 8. Foldout handle “Click” - Open the handle as shown until you feel a click.

  • Page 21: Using Smartview Versa+ As A Multimedia Player

    SmartView Versa+ User Manual Using SmartView Versa+ as a multimedia player: 1. Enter magnifier mode Switch the power on, SmartView Versa+ will automatically enter magnifier mode. Power 2. Use Menu button to enter menu Menu Page 18...

  • Page 22: Use Left And Right Buttons To Change Menu Display Mode

    SmartView Versa+ User Manual 3. Use Left and Right buttons to change menu display mode Change Mode Page 19...

  • Page 23: Use Up And Down Buttons To Change Functions

    SmartView Versa+ User Manual 4. Use Up and Down buttons to change functions Down You can choose these functions: - Magnifier - Playback - Setup - Recorder - Music - Movie 5. Use OK button to enter/confirm and Return button to cancel/go back. Page 20...

  • Page 24: Using Movie Mode

    SmartView Versa+ User Manual Return 6. Using Movie mode When you enter the movie mode, you will see the list of available movies. If the list is empty you must first download movies from your computer. Use the four arrows and OK button to operate the unit：...
  • Page 25 SmartView Versa+ User Manual - Select a movie: use to select - Play/Pause: press OK to play or pause movie. - Fast-forward/rewind: While the movie is playing press for fast-rewind and fast-forward. Then, use to increase/decrease the speed. There are 4 speed levels (2X, 4X, 6X, 8X) to choose.

  • Page 26: Using Playback Mode

    SmartView Versa+ User Manual 【To Download movie files】 - Connect the unit to a computer via the included USB cable. The Versa+ will appear as a removable storage device on your computer. - Open the removable storage device. If a folder “MPEG” does not exist you need to create one under the root directory.
  • Page 27 SmartView Versa+ User Manual [Select photos] - Use button to view previous photo; button to view next photo. - Use button to display 9 pictures at a time on screen. - Use to select pictures. Press the OK button to display the selected photo. - Use the Return button and the OK button to delete files.

  • Page 28: Using Music Mode

    SmartView Versa+ User Manual [Magnify photos] - After selecting a photo, use zoom in or zoom out. - Press the OK button to confirm your magnification level. - Then use the buttons to pan around the photo. - Press the OK button again to return back magnification adjustment.
  • Page 29 SmartView Versa+ User Manual 【Start to play】 - Use to select a song in play list. - Press the OK button to play music. - While the song list is displayed, press to enter delete menu, use and the OK button to confirm the deletion. - Press the Return button to quit playing.

  • Page 30: Using The Recorder Mode

    SmartView Versa+ User Manual 【To Download music files】 1. Connect the unit to a computer via the included USB cable. The Versa+ will appear as a removable storage device on your computer. 2. Open the removable storage device. If the "MP3" folder does not exist, you will need to create it in the root directory.

  • Page 31: System Setup

    SmartView Versa+ User Manual on storage capacity. [Playback Recorder file] - Press buttons to switch between saved voice files. - Use the OK button to start playing, press the OK button again to pause/play. - Adjust audio volume by pressing - Use the Return button and the OK button to delete files.
  • Page 32 SmartView Versa+ User Manual Key tones On /Off Format Internally / SD card Select Memory Internally / SD card LCD Shut-Off 15s / 30s / Never Auto Shut-Off 60s / 120s / Never Chinese, English, French, Languages German, Spanish, Dutch, Italian, and Portuguese Factory Reset Reset / Cancel...

  • Page 33: Computer Software Installation

    SmartView Versa+ User Manual Computer Software Installation The SmartView Versa+ comes with a CD-ROM with an electronic copy of this manual, USB drivers and the Blaze Video Magic software. In most cases connecting the Versa+ to your computer will be automatic. If your computer asks for USB drivers, use the drivers on the CD-ROM.

  • Page 34: Connect To Computer

    SmartView Versa+ User Manual Connect to computer - Turn on the Versa+. - Connect the unit to your computer with the USB cable. - The unit will appear as a removable mass storage device. - The following picture will be displayed on the LCD of the Versa+.
  • Page 35 SmartView Versa+ User Manual new Removable Disk Page 32...

  • Page 36: Connection To Tv

    SmartView Versa+ User Manual Connection to TV - Plug one end of the AV cable into the Versa+ and plug the yellow RCA jack into your TV video input. - The LCD will turn off automatically. - Press the Menu button for a few seconds, the image will switch to TV.
  • Page 37 SmartView Versa+ User Manual TV SYSTEM Page 34...

  • Page 38: Troubleshooting

    SmartView Versa+ User Manual Troubleshooting Problem Solution The screen is blank. ● Ensure that the power is on. ● Charge the battery. ● Reduce the magnification level. ● Ensure the image is below the crosshair. The unit will not turn ●...
  • Page 39 The screen is frozen ● Restart the unit. or distorted or any ●Remove and replace battery. other problem not mentioned in this manual. If your problem is not listed above, please contact HumanWare or your distributor. Page 36...

  • Page 40: Appendix A: Safety

    10°C and 40°C (50 and 104F). - Do not attempt to repair your SmartView Versa+ or open its case. This will void the warranty. Contact HumanWare to service this equipment. - Always unplug your unit before cleaning. Use only a damp, soft, lint-free cloth. Do...

  • Page 41: Appendix B: Technical Information

    SmartView Versa+ User Manual agents. - Use only the supplied power adapter to charge the battery as other adapters may damage the unit. Appendix B: Technical information Magnification 5x-15x Viewing modes Full color mode High contrast black on white High contrast white on black High contrast yellow on blue High contrast yellow on black Focus...

  • Page 42: Manufacturer Warranty

    SmartView Versa+ User Manual Manufacturer Warranty This device is a high quality product, built and packaged with care. All units and components are guaranteed against any operational defects as follows: US and Canada: one (1) year Europe: two (2) years Australia: one (1) year Other countries: one (1) year Warranty covers parts and labor.
  • Page 43 God. Please contact HumanWare or check on our website for versions of this manual in other languages. Une version française du manuel est disponible sur le site Web de HumanWare. Page 40...
  • Page 44 REV01...
