Table of Contents

LDK 4016/05 7-inch Viewfinder
Contents
7-inch Viewfinder ................................................ 2
Front View LED's ................................................ 3
Front View Switches ........................................... 4
6.15.3
LDK 4016/05
7-inch Viewfinder
with PIP
User's Guide
How to use PIP ................................................... 5
Positioning the Viewfinder .................................. 6
User's Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LDK 4016/05 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GRASS VALLEY LDK 4016/05

Summary of Contents for GRASS VALLEY LDK 4016/05

  • Page 1 LDK 4016/05 7-inch Viewfinder User's Guide LDK 4016/05 7-inch Viewfinder with PIP User's Guide Contents 7-inch Viewfinder ..........2 How to use PIP ........... 5 Front View LED's ..........3 Positioning the Viewfinder ........6 Front View Switches ........... 4...
  • Page 2 LDK 4016/05 7-inch Viewfinder User's Guide 7-inch Viewfinder Reset button Red On-air Lamps This button resets the PIP signal to the top left These two red tally lamps on either side of the back corner of the picture. of the viewfinder light when the camera picture is on- air.
  • Page 3 LDK 4016/05 7-inch Viewfinder User's Guide Front View LED's Call LED ISO LED This green LED lights to attract the cameraman's This yellow LED lights to indicate that the camera attention. signal is being used though not necessarily on-air. On-air LEDs These red LEDs light to indicate that the camera is on-air.
  • Page 4 LDK 4016/05 7-inch Viewfinder User's Guide Front View Switches Brightness Control Picture In Picture Switch Controls the brightness of the viewfinder display. This switch is used to switch on the PIP signal. Aperture Correction Control Cursor Frame Selection This control varies the amount of aperture correction...
  • Page 5 LDK 4016/05 7-inch Viewfinder User's Guide How to use PIP The PIP signal is controlled by a toggle switch and works as follows: The first time toggle up gives the PIP signal in the top left corner of the total picture.
  • Page 6 LDK 4016/05 7-inch Viewfinder User's Guide Positioning the Viewfinder Transport Lock Lever Hood Lock Levers Unlocking Locking To swing out viewfinder Locking the viewfinder a. Unlock the transport lock lever. a. Rotate the two unlocking knobs marked FIXED/ FREE simultaneously in FREE direction and push the back of the viewfinder down all the way.
