LDK 5307
7- I n c h h d Lc d V I e w f I n d e r
the LdK 5307 viewfinder for the Grass
Valley LdK 3000, LdK 4000 mk II, LdK
4000 elite, LdK 8000, LdK 8000 elite
series, and LdK 8300 cameras has
high brightness and contrast as well
as fast refresh rate making it ideal for
both indoor and outdoor use.
The LDK 5307 is a compact, high-quality,
flat panel color viewfinder designed to
work with most current Grass Valley
LDK high-definition cameras. The stylish
design allows for direct mounting to
the mini wedge plate of the camera
head in both EFP and SuperXpander
configurations.
With high brightness and contrast, and
a fast display refresh rate, the LDK 5307
7" LCD with anti-reflective panel
Menu
KEY FEATURES
• 7-inch LCD panel with backlight
• 16:10 aspect ratio (16:9 active video
plus monitor menu)
• High brightness and contrast
• 1:1 pixel zoom function
• Adjustable box and markers
www.grassvalley.com
is the perfect color viewfinder for both
indoor and outdoor applications.
™
The LDK 5307 color viewfinder has an
intuitive menu structure which not only
allows for settings of the viewfinder, but
can also be used to call up the camera
system menu via the viewfinder controls.
Three rotary controls, for contrast,
brightness, and peaking settings, are
easily accessible at the front panel. In
Assignable
buttons
Peaking
• Camera menu access
• Supports all current HD formats
• Fast response time
• Compact – LDK matching design
• EFP and SuperXpander use
• Easy accessible front controls
product data sheet
addition, three user assignable push
buttons are located at the front bezel of
the viewfinder.
The color temperature of the display
can be adjusted to match the operator's
personal preference without any affect
on the main video signal, allowing the
operator to match the display color
temperature with the color temperature
of the scene.
Short sunhood
Tilt mechanism with precise friction
Brightness
Contrast
• Robust magnesium housing
• Compatible with LDK 3000*,
LDK 4000 mk II*, LDK 4000 Elite*,
LDK 8000*, LDK 8000 Elite Series*,
and LDK 8300*
* Camera software package must have latest update
LED indicators:
ISO = Yellow
On-air = Red
Call = Green
