3.5 Setup Parameter Descriptions

System Chapter
In the descriptions below, system default values/options are shown in
bold text
Memories Page
S1 Trip
S2 Speed Maximum
S3 Speed Average

Alarms Page

S4 Shallow Water Alarm
page 22 S10 to select units) and are all subject to any keel or waterline
offset added (see page 23 S18 to set an offset).
This alarm sounds as the depth passes below the set value and NOT as
the depth increases past this value.
S5 Deep Water Alarm
subject to any keel or waterline offset added (see page 23 s18 to set an
offset).
This alarm sounds as the depth increases past this value or decreases
past this value.
www.raymarine.com
The distance travelled since the last Trip Reset.
Resets to 0.00.
The maximum speed attained since switch on or since the
last Maximum Speed Reset.
Resets to current boat speed.
The average speed attained since switch on or since the last
Average Speed Reset.
Resets to current boat speed.
Sets the shallow depth at which the display will alarm.
The options are: Off and 0.0 to 25.0 feet (0.0 to 7.6 metres)
(0.0 to 4.1 fathoms).
Values are displayed in the previously selected units (see
Sets the deep depth at which the display will alarm.
The options are: OFF and 0.0 to 250 feet (0.0 to 76.2 metres)
(0.0 to 41.6 fathoms). Values are displayed in the previously
selected units (see page 22 -s10 to select units) and are all
Setup and Calibration
21
