Sub-Zero 700TF Use & Care Information Manual page 11

S U B - Z E R O I N T E G R AT E D
D E L I D R A W E R A N D S H E L F
The one-piece deli drawer and shelf assembly
in the tall refrigerator and combination units, is
easily removed for cleaning and repositioning.
The deli drawer is convenient for storage of
those small easy-to-lose items as well as to
keep deli items fresh.
Remove this assembly in much the same way
you remove the standard adjustable shelves in
the tall unit. See the instructions and illustra-
tion for Adjustable Glass Shelves on page 10.
C R I S P E R – M O D E L 7 3 6 T C ( I )
The crisper offers convenient storage of fruits
and vegetables and comes with two dividers.
To remove the crisper, the glass shelf must
first be taken out by lifting the glass off of the
plastic side shrouds. Next, lift the crisper bin
up off of the bin cradle. Refer to the illustration
below.
To replace the crisper, place the bin on top of
the bin cradle. The groove across the bottom
of the bin should align with the crossbar at the
front of the cradle. Next, place the glass shelf
on top of the side plastic side shrouds.
Crisper – Model 736TC(I)
U S E & C A R E
D R AW E R
D R A W E R R E M O V A L
IMPORTANT NOTE: Before removing the
top drawer from a base unit, you must first
disconnect the control cable as shown in the
illustration below.
To remove a storage drawer from your
Integrated tall or base unit, pull it open until it
stops. Raise the drawer front and pull out as
shown in the illustration.
To replace a drawer, raise the front of it and
place onto the tracks. Engage the hook at the
rear of each slide with slots in the back of the
drawer tub. For 36" (914) wide units, there are
tabs on each drawer that must be positioned
between the hooks. Then engage the small
white pegs at the front of each drawer slide
with holes at the front of the drawer tub.
You must first disconnect the control
cable before removing the top drawer of
a base unit.
Control cable disconnection
S T O R A G E
Storage drawer removal
11
