Kompernaß GmbH
Burgstraße 21
D-44867 Bochum (Germany)
Last Information Update:
10 / 2007 · Ident.-No.: PFBS 9,6 V-102007 - 6
MULTI PURPOSE
PRECISION ROTARY TOOL
PFBS 9,6 V
MULTI PURPOSE PRECISION
ROTARY TOOL
Operating and safety instructions
Before you begin reading this information, please unfold the page with the illustrations
and familiarize yourself with all functions of the tool.
GB / IE / CY
Operating and safety instructions
Page
5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Parkside 6 V
Summary of Contents for Parkside 6 V
- Page 1 Kompernaß GmbH Burgstraße 21 D-44867 Bochum (Germany) Last Information Update: 10 / 2007 · Ident.-No.: PFBS 9,6 V-102007 - 6 MULTI PURPOSE PRECISION ROTARY TOOL PFBS 9,6 V MULTI PURPOSE PRECISION ROTARY TOOL Operating and safety instructions Before you begin reading this information, please unfold the page with the illustrations and familiarize yourself with all functions of the tool.
-
Page 3: Table Of Contents
Introduction For your safety ...Page 6 Proper use ...Page 6 Features and equipment ...Page 6 Included items ...Page 7 Technical information ...Page 7 Safety Safety advice ...Page 7 Operation Charging the battery pack ...Page 8 Inserting / removing the battery pack into / out of the drill / grinder ...Page 9 Changing a collet ...Page 9 Inserting / changing tools ...Page 9 Switching on and off / Setting the speed range ...Page 9... -
Page 4: Introduction
Introduction The following icons / symbols are used in this instruction manual: Read instruction manual! Observe caution and safety notes! Caution – electric shock! Dangerous electric current – danger to life! Amp-hours (Battery capacity) Rated idle running speed Direct current (Current and kind of tension) Voltage Multi-purpose precision... -
Page 5: Included Items
1 Operating instructions 1 Booklet “Guarantee and service” 1 Booklet “General safety advice” Technical information Model PFBS 9.6: Rated voltage: 9.6 V DC No-load speed: 5000 - 25 000 min Max. disc ø: 25 mm Rechargeable battery pack PFBS 9.6-2: Rated voltage: 9.6 V DC... -
Page 6: Safety / Operation
Safety / Operation To avoid danger to life from electric shock: A damaged drill / grinder, mains lead or plug presents a serious dan- ger to life from electric shock. Check the condition of the drill / grinder, charger, mains lead, mains plug and battery pack at frequent intervals. -
Page 7: Inserting / Removing The Battery Pack Into / Out Of The Drill / Grinder
Switch the charger off for at least 15 minutes between successive charging processes. To do this pull the mains plug (mains adapter of the socket. Inserting / removing the battery pack into / out of the drill / grinder Inserting the battery pack: Set the On / Off switch to position “0”. - Page 8 Operation Setting the appropriate speed Symbols on Material On / off switch (Drill / grinder switched off) Plastics and low melting point materials Stone, Ceramics Examples of appropriate tool selection Function Function Accessory Drilling HSS drill Milling Milling bits Engraving Engraving bits Polishing, Metal brush...
-
Page 9: Tips And Tricks
Operation / Maintenance and cleaning / Disposal / Information Tips and tricks If you use press too hard you run the risk of break- ing the tool or damaging the workpiece. You will achieve the best results by operating the tool at a constant rotational speed and using a low contact pressure on the workpiece.
