SB-E-2-220
ISS.04
Operation Manual
GFG – Gravity-feed Spray Gun
E
P 2 – 8

Advertisement

Table of Contents
loading

Related Manuals for DeVilbiss E P2 – 8

Summary of Contents for DeVilbiss E P2 – 8

  • Page 1 SB-E-2-220 ISS.04 Operation Manual GFG – Gravity-feed Spray Gun P 2 – 8...

  • Page 2: Ec Declaration Of Conformity

    Operation Manual GFG – Gravity-feed Spray Gun Important Read and follow all instructions and Safety Precautions before using this equipment Description The GFG Gravity-feed Spray gun Kit is approved to ATEX regulations 94/9/EC, protection level; II 2 G X, Suitable for use in Zones 1 and 2 Important: These spray guns are suitable for use with most solvent-based coating materials.

  • Page 3: Safety Warnings

    SAFETY WARNINGS Fire and explosion Solvents and coating materials can be highly flammable or combustible when sprayed. ALWAYS refer to the coating material supplier’s instructions and COSHH sheets before using this equipment. Users must comply with all local and national codes of practice and insurance company requirements governing ventilation, fire precautions, operation and house-keeping of working areas.

  • Page 4: Parts List

    Parts List Ref. No Description Part Number 1 Air cap/Retaining ring See chart 1 1a Spring clip JGA-156-K5 + 2 Nozzle See chart 2 3 Baffle & seal JGD-402-K #*+ 4 Spring adjusted needle Packing (kit of 2) Gti-445-K2 5 Spreader valve Gti-404-K # 6 Stud and screw Gti-408-K5...
  • Page 5 Chart 1. Air Cap and Nozzle Size Combinations Chart 2. Nozzle/Needle Combinations Air Cap Air Cap Part Nozzle Nozzle Order Needle Order Number Size Number Number AV-4239-30 AV-645-FF JGA-421-FF-K AV-4239-43 AV-645 FW JGA-421-FF-FW MB-4039-64 AV-645-EX JGA-421-DEX-K MB-4039-80 AV-6745-D JGA-421-DEX-K AV-4239-186 ©...

  • Page 6: Specification

    Specification Air supply connection - Universal ¼” BSP and NPS Maximum air pressure - = 7 bar (130 psi) Gun weight - 635 g Cup weight - 172 g Maximum service temperature - 40°C Materials of construction Gun body Polished aluminium Nozzle Stainless steel Needle...

  • Page 7: Preventative Maintenance

    Preventative Maintenance 1. Turn off air supply and relieve pressure in the airline or, if using QD system, disconnect from airline. 2. Empty coating material into a suitable container and clean the gun and cup, preferably in a gun wash machine. 3.
  • Page 8 ITW Finishing Systems and Products ITW Oberflächentechnik GmbH & Co. Ringwood Road, Bournemouth, Justus-von-Liebig-Straße 31 BH11 9LH, 63128 Dietzenbach England. Tel (060 74) 403-1 Tel. No. (01202) 571111 Telefax: (060 74) 403300 Telefax No. (01202) 581940, Website address Website address http://www.itw-finishing.de http://www.itweuropeanfinishing.com ITW Automotive Finishing UK...
