  • Page 1 SB-E-2-252-I Operation Manual JGA – Suction Feed Spraygun P 2 - 8 © ITW Ltd 2001...
  • Page 2: Declaration Of Conformity

    Operation Manual JGA – Suction Feed Spraygun Important Read and follow all instructions and Safety Precautions before using this equipment Description The JGA Suction Feed Spraygun Kit is suitable for use with most solvent based coating materials. Nozzles and Needles are available in Stainless Steel.
  • Page 3: Fire And Explosion

    SAFETY WARNINGS Gloves must worn when Fire and explosion s pra yin g c leanin g th e Solvents and coating materials equipment highly flammable combustible when sprayed. ALWAYS Training – Personnel should be given refer to the coating material suppliers adequate training in the safe use of instructions COSHH...
  • Page 4: Parts List

    Parts List Ref. No Description Part Number Air Cap/Retaining ring See Chart 1 Spring Clip - Kit of 5 JGA-156-K5 Nozzle AV-645-** Baffle & Seal JGD-402-K Baffle seal - Kit of 5 GTI-33-K5 Packing GTI-439-K2 Spreader Valve GTI-405-K Stud and Screw GTI-408-K5 Needle See Chart 2...
  • Page 5: Specification

    Chart 2. Nozzle and Needle Combinations Chart 1. Aircap and Nozzle Size combinations Aircap Aircap Part Nozzle Nozzle Order Needle Order Number Size Number Number AV-4239-30 AV-645 FW JGA-421-FF AV-4239-43 AV-645-FF JGA-421-FF MB-4039-80 AV-645-EX JGA-421-EX AV-4239-186 Specification Air supply connection - Universal BSP and NPS Fluid Supply Connection -...
  • Page 6: Installation

    Installation 2. Attach the Cup Lid assembly (27) Important: To ensure that this equipment reaches you in first class to the Fluid Inlet connector (17). condition, protective coatings have 3. Position the Yoke at right angles to the Gun with the Cam lever to been used.
  • Page 7: Preventative Maintenance

    Preventative Maintenance 1. Turn off air and relieve pressure metal wire which could damage in the supply lines, or if using QD the cap and produce distorted system, disconnect from airline. spray patterns 2. Release Cup and raise the tube 5.
  • Page 8 ITW Finishing Systems and Products Ringwood Road, Bournemouth, BH11 9LH, England. Tel. No. (01202) 571111 Telefax No. (01202) 581940, Website address http://www.itweuropeanfinishing.com ITW Oberflächentechnik GmbH & Co. KG Justus-von-Liebig-Straße 31 63128 Dietzenbach Tel (060 74) 403-1 Telefax: (060 74) 403300 Website address http://www.itw-finishing.de ITW Surfaces Et Finitions 163-171 avenue des Auréats B.P.
