Specifications

CPU
Chipset
Memory
Expansion
Slots
Storage
Audio
LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
2
®
• Onboard Intel Bay Trail-D J2900/J1900/J1800 (10W) SoC
Note: Please go to ECS website for the latest CPU support list.
®
• Intel Bay Trail-D J2900/J1900/J1800 SoC
• Single-channel DDR3L memory architecture
• 1 x 204-pin DDR3L SO-DIMM socket supports up to 8 GB
• Supports DDR3L SO-DIMM 1333 MHz
Note: Please go to ECS website for the latest Memory support list.
• 1 x PCI slot
• 1 x Full Size Mini PCIe slot (supports mSATA)
• 1 x Half Size Mini PCIe slot (supports WiFi/BT)
• Supported by Intel
- 1 x Serial ATA 3Gb/s devices
• Realtek ALC662-VD0-GR 48P
- 2 Channel High Definition Audio Codec
- Compliant with HD audio specification
• Realtek RTL8111G+Intel I211
- 10/100/1000 Fast Ethernet Controller
- wake-on-LAN and remote wake-up support
• 1 x PS/2 Keyboard connector and PS/2 Mouse connector
• 2 x COM ports (Support RS232/RS422/RS485)
• 1 x VGA port
• 1 x HDMI port
• 2 x RJ45 LAN connectors
• 3 x USB 2.0 ports
• 1 x USB 3.0 port
• 1 x Audio jack for line-out and microphone
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x 10-pin USB 2.0 header supports two USB 2.0 ports
• 1 x Serial SATA 3Gb/s connector
• 1 x Front Panel switch/LED header
• 1 x Front Panel audio header
• 1 x Clear CMOS jumper
• 1 x Buzzer
• 2 x JCOM connectors (supports additional eight COM ports)
• 1 x LPT header
• 1 x General Purpose Input/Output header
• 1 x Analog audio input connector (CD_H)
• 1 x HDD Power connector
• 1 x SPK_L header
• 1 x SPK_R header
• 1 x LVDS connector (For All-In-One Specification)
• 1 x LVDS Power connector (For All-In-One Specification)
• 1 x LCD power jumper(For All-In-One Specification)
BAT-I3 USER MANUAL
®
Bay Trail-D J2900/J1900/J1800 SoC
