ECS BAT-I3 User Manual page 9

Table of Motherboard Components
LABEL
1. CPU
2. SATA1
3. BZ
4. CPU_FAN
5. DIMM1
6. CLR_CMOS
7. JCOM3-6 & JCOM7-10 JCOM connectors (support additional eight COM ports)
8. AC_PWR
9. GPIO
10. F_PANEL
11. CASE
12. MINIPCIE2
13. LPT
14. SYS_FAN
15. HDD PWR
16. PCI
17. SPK_L
18. CD_H
19. MONO
20. F_AUDIO
21. SPK_R
22. F_USB
23. LCD_PWR
24. BKLT_PWR
25. LVDSPWR
26. LVDS
27. ATX12V
28. BT1
29. SMINIPCIE1
COMPONENTS
Onboard Intel® Bay Trail-D J2900/J1900/J1800 (10W) SoC
Serial ATA 3Gb/s connector
Buzzer
4-pin CPU cooling fan connector
204-pin DDR3L SDRAM SO-DIMM
Clear CMOS jumper
AC power jumper
General purpose Input/Output header
Front panel switch/LED header
Case open header
Half Size Mini PCI Express slot (supports WiFi/BT)
Printer header
4-pin system cooling fan connector
HDD power connector
32-bit add-on card slot
Speaker Left header
Analog audio input connector
MONO jumper
Front panel audio header
Speaker Right header
10-pin USB 2.0 header supports two USB 2.0 ports
LCD power jumper (For All-In-One Specification)
Backlight power jumper (For All-In-One Specification)
LVDS power connector(For All-In-One Specification)
LVDS connector (For All-In-One Specification)
4-pin +12V power connector
Battery
Full Size Mini PCI Express slot (supports mSATA)
BAT-I3 USER MANUAL
5
