Operating instructions

Remote control

RT AC 1
N. B. These operating instructions must be read before commissioning.
Failure to do so may be dangerous.
Machines may only be operated by personnel who are familiar with the appropriate safety
regulations.
The machines bear the conformity mark and thus comply with the
•
EC Low Voltage Directive (73/23/EEC)
•
EC EMC Directive (89/336/EEC)
In compliance with IEC 60974, EN 60974, VDE 0544 the machines can be used in environments
with an increased electrical hazard.
© 2007
Subject to alteration.
Dr. Günter - Henle - Straße 8 • D-56271 Mündersbach
Phone: +49 2680 181 0 • Fax: +49 2680 181 244
Item No.: 099-008197-EWM01
HIGHTEC WELDING GmbH
www.ewm.de
•
info@ewm.de
Revised: 23.06.2006
EWM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RT AC 1 and is the answer not in the manual?

Questions and answers

Related Manuals for EWM RT AC 1

Summary of Contents for EWM RT AC 1

  • Page 1: Remote Control

    • info@ewm.de Operating instructions Remote control RT AC 1 N. B. These operating instructions must be read before commissioning. Failure to do so may be dangerous. Machines may only be operated by personnel who are familiar with the appropriate safety regulations.
  • Page 2 Umbauten, die nicht which have not been expressly allowed modifications prohibeés, qui n´ont pas été ausdrücklich von EWM autorisiert sind, by EWM, this declaration will lose its autorisés expressément par EWM, cette verliert diese Erklärung ihre Gültigkeit. validity. déclaration devient caduque.
  • Page 3 Congratulations! You have chosen a quality product from EWM HIGHTEC WELDING GmbH. EWM machines provide results of the highest perfection thanks to their PREMIUM quality. Therefore we are happy to provide you with a full 3-year warranty according to our operating instructions.
  • Page 4 Machine and Company Data Please enter the EWM machine data and your company’s data in the appropriate fields. EWM HIGHTEC WELDING GMBH D-56271 MÜNDERSBACH TYP: SNR: ART: PROJ: GEPRÜFT/CONTROL: Name of Customer / company Name of Customer / company Adress...

  • Page 5: Table Of Contents

    Contents 1 Contents..............................5 2 Safety instructions ..........................5 3 Technical data ............................5 4 Machine description ..........................6 RT AC 1 ............................6 4.1.1 Front view ........................6 5 Commissioning ............................7 Area of application – proper usage....................7 5.1.1...

  • Page 6: Machine Description

    Machine description RT AC 1 Machine description RT AC 1 4.1.1 Front view Figure 4-1 Item Symbol Description Alternating current balance (TIG AC) Max. setting range: -15% to +15% (1% increments). The setting range may also be lower depending on the factory setting.

  • Page 7: Commissioning

    Commissioning Area of application – proper usage Commissioning Area of application – proper usage This remote control may only be connected to the remote control connection socket identified as such in the welding machine operating instructions. Always observe the operating instructions for the welding machine. The remote control must never be connected to a wire feed unit.

  • Page 8: Circuit Diagrams
