- Page 1 Operating instructions Remote control RCX Expert 2.0 RCX Expert 2.0 Rob 099-008808-EW501 Observe additional system documents! 13.01.2016...
-
Page 2: General Instructions
+49 2680 181-0. A list of authorised sales partners can be found at www.ewm-group.com. Liability relating to the operation of this equipment is restricted solely to the function of the equipment. -
Page 3: Table Of Contents
Disposing of equipment ....................... 10 6.3.1 Manufacturer's declaration to the end user ..............10 Meeting the requirements of RoHS ..................... 10 7 Technical data ............................11 RCX ............................. 11 8 Appendix A ............................12 Overview of EWM branches ......................12 099-008808-EW501 13.01.2016... -
Page 4: Notes On The Use Of These Operating Instructions
Notes on the use of these operating instructions Explanation of icons Notes on the use of these operating instructions WARNING Validity of the document! This document is part of the complete documentation and valid only in combination with the "Power source"operating instructions for the product being used! •... -
Page 5: Explanation Of Icons
Notes on the use of these operating instructions Explanation of icons Explanation of icons Symbol Description Symbol Description Indicates technical aspects which the user Activate and release/tap/tip must observe. Switch off machine Release/do not activate Switch on machine Press and hold/switch Wrong Turn Correct... -
Page 6: Intended Use
3.1.1 Warranty For more information refer to the "Warranty registration" brochure supplied and our information regarding warranty, maintenance and testing at www.ewm-group.com! 3.1.2 Declaration of Conformity The designated machine conforms to EC Directives and standards in terms of its design and construction: •... -
Page 7: Machine Description - Quick Overview
Machine description – quick overview Front and rear views Machine description – quick overview Front and rear views Figure 4-1 Item Symbol Description Holder for suspending the remote control Operating panel Machine control, see the relevant control operating instructions Connection cable between operating panel and power source Fixing magnet To mount remote control on magnetisable surfaces Recessed grip... -
Page 8: Design And Function
Design and function Establishing the connections Design and function Establishing the connections CAUTION Damage to the machine due to improper connection! The remote controls have been developed to be connected to welding machines or wire feed units only. Connecting them to other machines may cause damage to the machines! •... -
Page 9: Maintenance, Care And Disposal
Maintenance, care and disposal General Maintenance, care and disposal DANGER Improper maintenance and testing The equipment may only be cleaned, repaired or tested by specialist, skilled persons! A skilled person is one who, due to training, knowledge and experience, is able to recognise the dangers that can occur during testing of this equipment as well as possible subsequent damage and who is able to implement the required safety procedures. -
Page 10: Disposing Of Equipment
In addition to this, returns are also possible throughout Europe via EWM sales partners. Meeting the requirements of RoHS We, EWM AG Mündersbach, hereby confirm that all products supplied by us which are affected by the RoHS Directive, meet the requirements of the RoHS (Directive 2011/65/EU). -
Page 11: Technical Data
Technical data Technical data Performance specifications and guarantee only in connection with original spare and replacement parts! Protection classification IP 23 -25 C to +40 C Ambient temperature Dimensions L x W x D in mm 310 x 230 x 110 Weight 2.0 kg EMC class... -
Page 12: Overview Of Ewm Branches
Appendix A Overview of EWM branches Appendix A Overview of EWM branches 099-008808-EW501 13.01.2016...
