Summary of Contents for Lionel Red Comet Tinplate Set
- Page 1 75-1014-250 10/08 Red Comet Tinplate Set Red Comet Tinplate Set Owner’s Manual Owner’s Manual...
- Page 2 • Stamped metal trucks with operating latch couplers • Two #603 passenger cars • One #604 observation car • Minimum Curve: O-27 The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel , TrainMaster...
-
Page 3: Table Of Contents
Table of contents Running your train Running your train set Coupling Operating your locomotive’s E-unit Air whistle operation Maintaining and servicing your locomotive Lubricating your locomotive Replacing your locomotive’s lamp Limited Warranty/Lionel Service... -
Page 4: Running Your Train Set
Figure 1. Drawbar connection Power up your locomotive with your transformer. Your locomotive is designed to operate on 7-18 volts alternating current. Virtually all Lionel and Lionel-compatible alternating-current transformers are suitable. Note! Do not power your locomotive with direct current (DC) transformers. - Page 5 Running your train Coupling hen coupling your cars, lift the coupler arms on both couplers at the same time and move the cars together so that the hooks capture the latches. Note! Keep in mind that it’s easier to couple cars on a straight stretch of track. Figure 2.
-
Page 6: Operating Your Locomotive's E-Unit
Running your train Operating your locomotive’s E-unit our locomotive is equipped with a mechanical E-unit. The E-unit allows the locomotive to cycle through its operational states (forward, neutral, reverse, neutral, and so on) with interruptions in track power. The E-unit can be disconnected by sliding the E-unit lever to its OFF position. With the lever in the OFF position, the locomotive will not change directions after being stopped;... -
Page 7: Maintaining And Servicing Your Set
During the course of normal operations, the lamp may require replacement. Locate and remove the expired lamp and replace the lamp with Lionel part no. 600-0363-300, available from your authorized Lionel Service Center. (See the Lionel Service section on page 8 for more information.) -
Page 8: Warranty Information
(requires proof of purchase from the Lionel Authorized Retailer* it was originally purchased). Any products on which warranty service is sought must be sent freight or postage prepaid (Lionel will refuse any package when postage is due). Transportation and shipping charges are not covered as part of this warranty.
