73-1984-250
5/04
Midwest Freight
Ready-to-Run Set
Owner's Manual
CAUTI O N—ELECTRI C TOY
NOT RECOMMENDED FOR CHILDREN UNDER EIGHT YEARS OF AGE. AS WITH
ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING
HANDLI N G AND USE TO REDUCE THE RI S K OF ELECTRI C SHOCK.
TRANSFORMER RATINGS—I N PUT:120 VAC; 60 HZ ONLY.
AC OUTPUT:20 V; 54 VA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Midwest FreightReady-to-Run Set and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lionel Midwest FreightReady-to-Run Set

Summary of Contents for Lionel Midwest FreightReady-to-Run Set

  • Page 1 73-1984-250 5/04 Midwest Freight Ready-to-Run Set Owner’s Manual CAUTI O N—ELECTRI C TOY NOT RECOMMENDED FOR CHILDREN UNDER EIGHT YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLI N G AND USE TO REDUCE THE RI S K OF ELECTRI C SHOCK. TRANSFORMER RATINGS—I N PUT:120 VAC;...
  • Page 2 In the event that such conditions exist, the transformer should not be used until properly repaired. The following Lionel marks may be used throughout this instruction manual and are protected under law. All rights reserved. Lionel ®...

  • Page 3: Table Of Contents

    • Boxcar • Tank Car • Caboose • 40-Watt Transformer • Three straight FasTrack track sections • One straight FasTrack terminal track section • Eight curved FasTrack track sections • Owner’s Manual • Service Center list • Lionel RailRoader Club flyer...

  • Page 4: Creating Your Layout Operating Your Transformer Safely

    • Parents should periodically inspect this product for potential hazards and, if necessary, have them repaired by an authorized Lionel Service Center. In the event that such a condi- tion exists, the transformer should not be used until it has been properly repaired.

  • Page 5: Building Your Lionel Layout

    Creating your layout Building your Lionel layout our set comes with eight curved, three straight, and one terminal section of track. Figure 1 provides some examples of layouts that you can build with these track sections. By adding more FasTrack track sections, you can create an endless number of exciting track arrangements for more fun, action, and variety.

  • Page 6: Wiring Your Transformer

    Creating your layout Wiring your Transformer hen connecting your transformer, make sure that all power connections are secure. Loose connections can produce extremely high temperatures. For this reason, do not touch the terminals or track connections during use. Also, do not locate scenery materials such as lichen or ground foam near the terminals.

  • Page 7: Running Your Train

    Refer to page 8 for information on coupling your cars. Power up your locomotive with your transformer. Your locomotive is designed to operate on 10-16 volts alternating current. Virtually all Lionel and Lionel-compatible alternating-current transform- ers are suitable. Do not power your locomotive with direct current (DC) transformers.

  • Page 8: Coupling

    Running your train Coupling hen coupling your cars, at least one of the mating couplers must be open as shown at the left in Figure 4. Press down on the lock release to open the coupler, then push the cars toward each other until they lock together.

  • Page 9: Transformer Functions

    Running your train Transformer functions s you turn the throttle control knob to the right, power to the track is increased. Figure 5 illustrates the throttle control knob settings. When the indicator reaches the green band, there should be sufficient power to operate the locomotive. The further into the green area the knob is turned, the faster your train will go.

  • Page 10: Horn Operation

    Dirt and grease may accumulate on the track, wheels, and rollers. The horn may sound intermittently as a result of this build-up. Cleaning the wheels and track should eliminate this problem. We suggest using the Lionel Lubrication and Maintenance Kit (6-62927), available at your authorized Lionel Dealer.

  • Page 11: Reverse Unit Procedure

    Running your train Reverse unit procedure he reverse unit (E-Unit) inside your Lionel locomotive is an electronic device that acts like the transmission in a car. When you apply power to the track, the locomotive moves in the direction specified by the reverse unit—or it sits in neutral, awaiting a power interruption. Power interruptions are the signal that tells the reverse unit to sequence to the next operational state.

  • Page 12: Maintaining And Servicing Your Set Lubricating Your Rs-3 Locomotive

    We recommend that you purchase a Lionel Lubrication and Maintenance Kit (6-62927), available from your authorized Lionel dealer. Two basic rules to keep in mind: never over-lubricate (a small amount will do), and avoid getting grease or oil on the locomo- tive’s wheels, contact rollers, or your track.

  • Page 13: Tire-Traction

    During the course of normal operations, the traction tires may become worn out. See your authorized Lionel Service Center for assistance. Refer to the Service Center list that is packed with this set.

  • Page 14: Replacing Your Locomotive's Lamps

    During the course of normal operations, these lamps may require replacement. Replacement lamps are available from your authorized Lionel Service Center or Lionel Service. Refer to the Service Center list that is packed with this set to locate a service center near you.

  • Page 15: Advanced Connections: Powering Two Isolated Blocks With Two Transformers

    Maintaining and servicing your set Advanced connections: powering two isolated blocks with two transformers s you expand your layout, you may decide to create two isolated blocks of track. Trains in each block are controlled by separate transformers. Before you operate your trains on this type of layout, be sure that your transformers are in phase.

  • Page 16: Limited Warranty/Lionel Service

    Lionel L.L.C. or an authorized Lionel L.L.C. Service Center, together with proof of original purchase will, at the option of Lionel L.L.C., be repaired or replaced, without charge for parts or labor. In the event the defective product cannot be repaired, and a replacement is not available, a refund of the original purchase price will be granted.

This manual is also suitable for:

Rs-3
