JAYLINE IS550 Installation & Operation Instructions

Insert wood fire
Hide thumbs Also See for IS550:

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual
JAYLINE IS550
INSERT WOOD FIRE
INSTALLATION & OPERATION INSTRUCTIONS
January 2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the IS550 and is the answer not in the manual?

Questions and answers

Related Manuals for JAYLINE IS550

Summary of Contents for JAYLINE IS550

  • Page 1 JAYLINE IS550 INSERT WOOD FIRE INSTALLATION & OPERATION INSTRUCTIONS January 2015...

  • Page 2: Pre-Installation

    Check the cavity dimensions to ensure the insert will fit. It is usually necessary to remove the bricks from the lower fireplace cavity. The base of the fireplace on which the Jayline Insert will rest must be level. If not, it should be leveled using mortar.

  • Page 3: Installation

    Installation requirements for Jayline Is550 fireplace insert and flue system, where timber framing is less than 50mm from the chimney structure. The installation should be carried out by a suitably qualified installation technician who will ensure the following: The minimum clearances determined by tests in accordance with AS/NZS 2918:2001 are complied with to prevent overheating of nearby combustibles.
  • Page 4 The appliance can then be bolted to the floor protector with two 6mm x 50mm dynabolts (or equivalent). Baffle Before lighting your appliance for the first time, make sure the baffle is in the correct position being as far to the rear as possible. January 2015 www.jayline.co.nz page ...
  • Page 5 WRITING BY THE TESTING AUTHORITY IS CONSIDERED TO BE IN BREACH OF THE APPROVAL GRANTED FOR COMPLIANCE WITH AN/NZS 4013:1999. 3. PLEASE ENSURE THAT ONLY COMPONENTS APPROVED BY JAYLINE ARE USED FOR THE INSTALLATION as substitutes may adversely affect performance and might nullify compliance with the requirements of AS/NZS 2918:2001.
  • Page 6 JaylIne Wood fIre Simply by burning your Jayline fire correctly, you can improve efficiency, reduce fuel consumption and minimise air pollution. Please note: Wood with a moisture content of 25% or less is the only approved wood to use in Clean Air Zones.
  • Page 7 Placing the pieces on the burning kindling can help prevent smothering. Your Jayline heater requires approximately 45-60 minutes to preheat the steel firebox before it can effectively emit heat into the room. A well maintained, hot fire will reduce the preheat cycle.
  • Page 8 (AS vIEwED FROM DOOR) Fire in cycles: Don’t expect perfectly steady heat output from your Jayline heater. Solid fuel heaters burn in cycles. A cycle is the time between the ignition of a load from charcoal and the consumption of the load back to a coal bed.
  • Page 9 The exhaust coming from the top of the flue system should be clear or white. A plume of blue or grey smoke indicates smouldering, inefficient combustion, air pollution and probably low operating temperatures. January 2015 www.jayline.co.nz page ...
  • Page 10 Correctly installed and operated, Jayline solid fuel heaters do not spill smoke into the house. There are three main reasons why some woodstoves smoke: Bad installation design: Incorrect flue installation, resulting in low flue temperatures and low draught, can make a wood heater more likely to spill smoke. For example, each elbow in the flue pipe assembly slows down the flow of gases and causes a small restriction to flow.

  • Page 11: Burning Coal

    (6 in.) across the largest dimension and a range of smaller pieces will be needed for effective stoking. Maximum log length varies according to model. BurnInG coal Due to their construction, the burning of coal in Jayline solid fuel heaters is prohibited. Please also refer to ‘Exclusions’ in the Warranty Page 16. January 2015 www.jayline.co.nz...
  • Page 12 General maintenance checks should include the following:- asH reMoval – Due to the high efficiency of your Jayline fire, ash removal should only be necessary every few weeks. Ashes can be removed easily through the fire door when the fire is at its lowest, such as first thing in the morning, or when it is completely out.
  • Page 13 Flue pipes can deteriorate very quickly with incorrect firing. consuMaBles Some parts of your Jayline fire are considered consumable. They are designed to be replaced as they will degrade over time. The life of the consumables will vary depending on;...
  • Page 14 WarnInGs Below is a list of warnings to ensure efficient and safe operation of your Jayline wood fire: • WarnInG: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR REKINDLE THE FIRE. WarnInG: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS IN THE VICINITY OF THIS APPLIANCE •...
  • Page 15 We select only certain companies to act as our Jayline dealers. They must have high standards and be able to provide a total service both pre and post sale to you the customer. Therefore we have every confidence that our dealers will be able to answer your questions or fix any problem that may occur.
  • Page 16 This warranty is non transferable. It is recommended you have your dealer inspect your appliance annually during the warranty period. JaylIne reserves the right to change specifications or design of its product without prior notice. January 2015 www.jayline.co.nz page 1...

  • Page 17: Warranty Card

    PLEASE COMPLETE AND RETURN WITHIN 0 DAYS OF INSTALLATION TO: RETAIL LINKS LTD PO BOX 05 ANNESBROOK, 0 NELSON NAME: ________________________________________________________________________ ADDRESS: ____________________________________________________________________ ______________________________________________________________________________ ______________________________________________________________________________ EMAIL: ________________________________________ PHONE: ________________________ MODEL: ______________________________________________________________________ SERIAL NUMBER: ______________________________________________________________ DATE PURCHASED: ____________________________________________________________ PURCHASED FROM: ____________________________________________________________ DATE INSTALLED: ______________________________________________________________ INSTALLED BY: ________________________________________________________________ January 2015 www.jayline.co.nz...
