7.4 tECHNICaL SpECIFICatIONS

The following specifications are not verified by Global Distribution GmbH in terms of plausibility
and accuracy:
Dimensions: ..................................................................... 370 x 61 x 266 mm
Weight: .............................................................................. 2.4 kg
Input/Output Impedance & Sensitivity: ....................... EQ Flat, Maximum Gain, Load = 100 kohm
Frequency range (Eq Flat, Maximum Gain, Load = 100 kohm):
Line: ................................................................................... 17 Hz – 16 kHz +/-0.5 dB
Mic. .................................................................................... 20 hz – 20 kHz +/-1,5 dB
tHd + N (Eq Flat, Maximum Gain, Mic = Off, Load = 100 kohm, w/20 kHz LpF):
Line: ................................................................................... 0.01% 1 kHz/0 dB
S/N ratio (Maximum Gain, Eq Flat, w/20 kHz LpF, a-Weighted, Master = 0 dBv Outout):
Line: ................................................................................... 95 dB
Mic: .................................................................................... 68 dB
Channel Separation (Maximum Gain, Eq Flat, 1 kHz = 0 dB, Mic Switching = Off):
L/R: .................................................................................... 85 dB
Reloop Distribution
Global Distribution GmbH, Schuckertstrasse 28,
48153 Münster / Germany
Fax: +49.251.6099368
Subject to technical alterations!
Illustrations similar to original product!
Misprints excepted!
