7.4 TECHNICAL SPECIFICATIONS
The following specifications are not verified by Global Distribution GmbH in terms of plausibility and
accuracy:
Power Supply:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . DC6V, 1.5A (9w)
Dimensions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370 x 266 x 61 mm
Weight:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2.4kg (without USB and RCA cable)
Input/Output Impedance & Sensitivity: . . . . . . . . EQ Flat, Maximum Gain, Load = 100K Ohm
Frequency Range (EQ Flat, Maximum Gain, Load = 100K Ohm):
Line: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7Hz-16KHz +/-0,5dB
Mic:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Hz-20KHz +/-1,5dB
THD + N (EQ Flat, maximum Gain, Mic = off, Load = 100K Ohm):
Line: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.01% 1KHz/0dB
S/N Ratio (Maximum Gain, EQ Flat, W/20 kHz LPF, A-Weighted, Master = 0dBV Output):
Line: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95dB
Mic:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68dB
Channel Separation (Maximum Gain, EQ Flat, 1KHz =dB, Mic Switching = Off)
L/R: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85dB
44
