- Page 1 User Manual (V1.0)
- Page 2 User Manual PREFACE Honorable customers: Thanks for choosing products of our company. The product with world cutting edge technologies—fingerprint/card recognition, computer communication, as well as microelectronics, is considered to be combination of three technologies: electronics, optics and computer communication. It is no doubt that it has become the first choice of standalone time & attendance for enterprises with its strong function and veracity.
-
Page 3: Table Of Contents
Delete All Users .................. 8 2.5. Function button ..................8 2.6. Register Management Cards ..............9 2.7. Illustration for pressing fingerprint ............. 9 2.8. Usage Notice .................... 9 FAQ ........................12 Appendix ......................15 Wiring Instruction ..................15 Wiring diagram of M5 ................16... - Page 4 Chapter 1. Product Introduction This chapter introduces the advantages, performance, and functionality of M5.
-
Page 5: Product Introduction
1.1. Product overview M5 is a biometric fingerprint and RFID Card reader with a compact design, which is suitable for installing on a door frame. With master cards, you can register or delete users under offline state. The USB power supply and debug make operations simple. -
Page 6: Size
User Manual 1.3. Size... -
Page 7: Operation Guide
User Manual Chapter2. Operation Guide This chapter is about the hardware operation and contains information of how to set the administrator, and how to add/delete users, etc. -
Page 8: Operation Guide
User Manual Operation Guide 2.1. Interface Introduction Note: The restart operation will not delete any user data stored in the device. 2.2. Upper Electricity The DC 12V Power supplies the power to the device. Blue LED flashes fast and Fingerprint Sensor lights with beeps. There are 4 cards in the packing: Enroll Card , Delete Card and User Card... -
Page 9: Register User's Card
User Manual have been registered. Register User’s Card 2.3.2. Swipe Enroll Card. The blue LED will flash quickly, and enter into registration stage. In time we can swipe the user card. 1. After finish enrolling current user, please swipe enroll card and then continue register another user. -
Page 10: Register Two Fingerprints And Card Of One User
User Manual 1. After finish enrolling current user, please swipe enroll card and then continue register another user. 2. After finish enrollment, please swipe enroll card TWICE to exit enroll status. Note: The wiegand output of fingerprint and card are the same 2.3.5. -
Page 11: Delete User's Card
User Manual Note: When place finger, Red LED flashes with long beep means the fingerprint does not exist in the device. Delete user’s card 2.4.2. Swipe Delete Card. The red LED will flash quickly, enter into a deletion stage. Now, you can delete the user. -
Page 12: Register Management Cards
User Manual and Delete Card) to run the machine. Note: The operation will not delete any user data stored in the device. 2.6. Register Management Cards Register Management Cards(Enroll Card and Delete Card): 2.7. Illustration for pressing fingerprint Correct method: Wrong method: Valid Left... - Page 13 User Manual 2. Humidity, dust, and direct light can affect the terminal’s performance. 3. Please don’t clean the surface of the optical fingerprint sensor with an organic impregnate such as alcohol or gasoline. 4. Recommended solution: Use one-sided adhesive tape to paste on the sensor and then remove the tape.
- Page 14 User Manual Chapter 3. Frequently asked questions and answers.
-
Page 15: Faq
User Manual Fingerprint has been enrolled but gets failure in identification. Reason Solution 1. The fingerprint was not captured Enroll the finger again. properly. 2. The fingerprint is too dry or too wet 1. Touch the forehead to increase oily with oil or cosmetics. - Page 16 User Manual module. Terminal beeps automatically when no one punches in/out. Reason Solution 1. Direct sun light or light too bright. Avoid direct sun light or other bright light. 2. Latent fingerprint on the surface of Clean sensor surface (adhesive tape sensor.
- Page 17 User Manual Chapter 4. Appendix The main theme of this chapter includes additional information in regards to wiring.
-
Page 18: Appendix
User Manual Appendix Wiring Instruction The following shows the wiring ports on the device:... -
Page 19: Wiring Diagram Of M5
User Manual Wiring diagram of M5 Communicate M5 to PC : Note: Please verify enroll card to enable the USB communication function.
