CONNECTING THE DECODER
The VIEW Pro D110 Decoder connections are from the back of the unit
as shown in the following diagram:
8
6 GPIO Ports
for Control
COM2 Port for
3 Inputs and
Source or 3rd-Party
3 Outputs
Device Control
19 VDC
2 x USB
Network Port2
Input from
3.0 Ports
(Currently Not Used)
Power
for USB
Adapter
Audio/Video
Devices
COM1 Port for
2 HDMI
Source or 3rd-Party
Audio/Video Port
Device Control
Network Port1
3.5mm
Audio Output
(Currently Not Used)
DSP forced
air intake
3.5mm Line-level
Audio Intput
