Table of Contents INTRODUCTION Product Overview ..............................1 StreamNet AVoIP™ Video Platform ...........................1 Device Application ................................1 Included with Your VIEW Pro Encoder ..........................1 CONNECTIONS Inputs and Connections............................2 Status LED ..................................2 10/100/1000 Ethernet Jack ...............................2 HDMI Inputs ..................................3 IR In....................................3 IR Out ....................................3 RS-232 (COM) ...................................3 19VDC Input ..................................3...
Page 4
VIEW PRO RS-232 CONTROL LUA File Driver Templates............................. 21 Preparing the New One-Way RS-232 Driver File ....................21 Preparing the Encoder/Decoder .......................... 23 Modifying the One-Way Driver File........................24 VIEW PRO AND VIEW LEGACY INTEROPERABILITY Control Sharing ..............................29 Audio Streaming Interoperability ......................... 29 IR Learning and Control ............................
Introduction PRODUCT OVERVIEW streamnet aVoIP™ V IDEo latforM The StreamNet IP platform is designed to send high-quality audio and video over a TCP/IP network (AVoIP™). An encoder, such as a VIEW Pro E120, takes digital video and audio from a source device, such as a receiver, cable box or DVR, and makes the source available anywhere on the StreamNet network.
Connections The VIEW Pro E120 Encoder has the following input and output connectors on the back of the unit. • 1x - IR Input connector compatible with SteamNet IR sensor (3.5mm) • 1x - IR Input Receiver window on front panel • 1x - IR Output connector compatible with SteamNet IR emitter (3.5mm) • 2x - Balanced Audio Input (Two Modular Phoenix-type connectors, left and right) • 3x - GPIO (General Purpose Inputs - Digital, 0/5V, Phoenix-type)
hDMI I nPuts The HDMI connectors on the E120 receive digital video and audio. Ir I This jack allows connection of an StreamNet compatible infrared receiver. The infrared receiver can pick up IR remote control signals for IR learning. Ir o This jack allows connection of an infrared transmitter.
Installation PHYSICAL CHARACTERISTICS IMEnsIons xCluDIng onnECtors Width: 12.2 inches (310mm) Length: 7.4 inches (188mm) Height: 1.75 inch (44.4mm) MOUNTING THE E120 The VIEW Pro encoder includes a Rack Mount Kit (910-0002-001) with rack-mount ears that attach to the encoder to facilitate mounting in a standard rack. Surface Mounting When mounted, the I/O connections are accessible from the back of the unit.
Page 9
There may some situations where the VIEW Pro cables cannot be concealed within a cabinet or in a wall. These cables can be surface mounted and concealed using the optional 910-0002-003 VIEW Pro Cable Raceway Kit. This raceway, in 12-inch joinable lengths, can be mounted to the wall to secure and cover the cables to the VIEW Pro devices.
THE E120 IN A NETWORK The VIEW Pro E120 encoder takes digital video and audio from source devices such as media/disc players, cable/satellite boxes, DVRs, and cameras, and then makes the digital video and audio available anywhere on the StreamNet® IP network. a StreamNet TCP/IP network using a standard 10/100/1000 Mbit Ethernet connection.
LUA FILE Control options for VIEW Pro devices using StreamNet Dealer Setup is facilitated but the .lua file found in the C:\Program Files x86)\ClearOne\StreamNet Application Suite\viewPro\drivers directory VIEW Pro has two DB9 Serial ports available on both Encoder and Decoder.
E120 SCREENS IN THE DEALER SETUP PROGRAM Verify the configuration information on the tabs for the E120 device as shown in the following screen examples: E120 DDIng an to a roJECt : 800.283.5936 EChnICal uPPort...
Page 13
1. Enter the following information: Device Name - Edit to name the E120 Device. Model Number - Select the E120 Device. 2. Enter the following information: GPIO Name - This is mainly used in macros By default this receives the Device Name. Source Names - Edit to name sources.
nforMatIon The Information tab contains all of the information about that particular A/V device: Current IP Address - The current IP address of the E120. Current Subnet Mask - The current subnet mask of the E120. Device Type - The type of device that this is. Model Number - The E120 model number.
DVD player, DVR, generic device, generic media server or cameras etc.) Driver File - The new driver file for the video source. (Allows you to select the designated .lua driver file. The ViewPro Lua files are stored in the ClearOne StreamNet Dealer Setup directory (C:\ Program Files (x86)\ClearOne\StreamNet Application Suite\viewPro\drivers).
Gain - The Audio Gain drop-down for setting the audio input gain up or down to match that of other sources in the system. Select from ± 0, 3, or 6 dB amplification or attenuation of audio source. Advanced Configuration - This button is unavailable and greyed out when any <Video Stream> source Enable check box is selected.
EDITING A STREAM Click on the name of the stream you are editing, then click on Edit Stream. On the Edit Stream screen you can select from preset characteristics for the stream. nstallatIon anual...
Page 18
Audio Device – The physical input port for the audio stream. Video Device – The physical input port for the video stream. Audio Preset File – The audio preset file that is linked to this stream. Video Preset File – The video preset file that is linked to this stream Driver File –...
Legacy Audio Support - This Premium Licensed Feature allows the creation of Audio-Only Streams which can be selected and listened to using the ClearOne Legacy Renderers (SLxxx, VLxxx). MultiCast RTSP Support - This Premium Licensed Feature allows an RTSP-compatible A/V or audio-only stream to be created within the Encoder.
Video Presets The following screen shows the “HD Video Distribution” in the Preset Editor with details on the right hand panel. : 800.283.5936 EChnICal uPPort...
Page 21
Video Presets Descriptions HD Video Distribution - Video Distribution containing high-definition content for large screen high quality applications. PC Presentation - Utilizes 4:4:4 Video at 24-bit color depth for maximum clarity. RTSP Lan Mode - Optimized for Distributing RTSP video streams for LAN applications. RTSP Wan Mode - Optimized for Distributing RTSP video streams for WAN applications.
Audio Presets The following screen shows the “PCM High Bitrate” in the Preset Editor with details on the right hand panel. : 800.283.5936 EChnICal uPPort...
Page 23
Audio Presets Descriptions PCM High Bitrate - Configured for High Definition Movie and Video Distribution applications. PCM Low Bitrate - Configured for Basic Digital Signage and Video Distribution applications. RTSP Audio - Configured using AAC Audio required by most RTSP applications. Setting Audio Preset Values Audio Bitrate - Sets the bitrate in bps of the audio encoding.
gPIo s EttIngs This tab allows you to choose a macro associated with each input state: High/Open and Low/ Closed. The VIEW Pro macros are created and used in the same manner as the VIEW legacy products. Refer to the Dealer Setup Manual, Chapter 11 Section 1 (11-1) for the “Favorites section,” which explains macros in detail.
2. Source Control. 3. Display Control The VIEW Pro .lua files are stored in the ClearOne StreamNet Dealer Setup directory : (C:\Program Files (x86)\ClearOne\StreamNet Application Suite\viewPro\drivers). If both Serial ports are to be used, then the Serial Comm Port number will need to be specified in each .lua File with a “1”...
Page 26
For Example: If you are creating a one way RS-232 file for a DVD you would: • Locate the Driver Template directory (i.e. C:\Program Files (x86)\ClearOne\StreamNet Application Suite\viewPro\drivers) • Copy the DVDTEMPLATE.LUA file into the Drivers folder that you created • Rename the DVDTEMPLATE.LUA...
PREPARING THE ENCODER/DECODER The next step is to configure the Encoder/Decoder device. Add the Encoder/Decoder as you normally would. Do NOT choose a source type that is tied to a specific manufacturer or product model. If you are in doubt choose the source type you would use if this were and IR device.
Once the device is added select the Sources tab for the Encoder/Decoder. Change the Driver file from IR to your newly created driver. For this example, we would change the driver file from IR to DVDTemplate.lua. Now Apply your changes. The Encoder/Decoder is now configured to use your one-way Driver file.
Page 29
In the RS-232 Protocol section of the .lua file, locate the communication settings. Normally these settings will include: Baud rate, Data Bit, Stop Bit, and Parity. Once you find them you will need to verify that these commands match those used in the driver file. To do this, open the file in your text editor: Do a text search for: baud= You are looking for this line:...
Page 30
Verify that the baud, bits, parity, and stop values in the driver file match the settings listed in the RS- 232 Protocol. Most devices use Baud=9600, Data bits=8, Parity=0, and Stop bits=1. Now locate the Command table in the driver file. Do a text search for: local CmdTable = : 800.283.5936 EChnICal...
Page 31
Below the local CmdTable = text are the available commands where you can enter RS-232 commands. For each command you will enter the command between the quotation marks. For example: To enter the RS-232 command for TUNE UP: Locate the TUNE UP command line: [‘TUNE UP’] = “”, Add the appropriate RS-232 command for the source to do a TUNE UP between the quotes [‘TUNE UP’] = “W 1 6 1”,...
Page 32
Your table should begin looking like this: Once you have completed your changes, save the file. From Dealer Setup, send the configuration to your Encoder/Decoder. The StreamNet GUI will now send the RS-232 command to the source via the DB9 port instead of the IR.
Conversely, StreamNet Devices can play audio streams from a VIEW Pro Encoder. At this time, video cannot be shared across the Products because they are using different compression schemes. » NOTE: Bridging Audio between VIEW Pro and StreamNet is a Licensed Feature. See your ClearOne business contact for additional information. nstallatIon anual...
IR LEARNING AND CONTROL The accessory kits for the IR Emitter and IR Receiver allow the use of these devices with the VIEW Pro products. For example, an IR Emitter can be placed over the integrated IR Receiver of a display so signals from the VIEW Pro can be used to control the display.
VIEW Pro Accessory Kits KIT DESCRIPTIONS The following accessory kits are available to meet the mounting and control needs of your VIEW Pro Encoders and Decoders: Part Number Kit Name Description 910-0002-001 VIEW Pro Rack Rack Mount Kit for VIEW Pro Encoder E120, Decoder D110 Mount • 2X - Rack Ear, Extended length (Included with...
To reduce the risk of this equipment becoming damaged it is suggested that the customer consider installing a surge arrestor. Any modifications to the device without express authorization from ClearOne is prohibited as per 47CFR15.21 and could void the users authority to operate the device.
E-mail: techsales@ClearOne.com roDuCt Eturns All product returns require a Return Material Authorization (RMA) number. Contact ClearOne Technical Support before returning your product. Make sure you return all the items and packing materials that originally shipped with your product. AVOIP™ HEADQUARTERS:...
