HD-SDeye
Full HD HD-SDI Camera
KP-HD1005-S5
Operation manual
Thank you for procuring this fine Hitachi Kokusai Electric color camera.
Before using the camera, please read this operation manual carefully and
keep this manual on file for ready reference in the future.
Hitachi Kokusai Electric Inc.
8BHB000295

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KP-HD1005-S5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hitachi Kokusai Electric KP-HD1005-S5

  • Page 1 Full HD HD-SDI Camera KP-HD1005-S5 Operation manual Thank you for procuring this fine Hitachi Kokusai Electric color camera. Before using the camera, please read this operation manual carefully and keep this manual on file for ready reference in the future.
  • Page 4 UDX Akihabara Bldg. 14-1 Sotokanda 4-choume, Chiyoda-ku, Tokyo 101-8980, Japan Phone: +81(0) 3-6734-9432, Fax: +81(0) 3-5209-5942 URL: http://www.hitachi-kokusai.co.jp Hitachi Kokusai Electric (Shanghai) Co., Ltd. Beijing Branch : Room 1413, Beijing Fortune Building, 5 Dong San Huan Bei-Lu, Chao Yang District, Beijing, 100004 China Phone: +86(0) 10-6590-8755/8756, Fax: +86(0) 10-6590-8757 Hitachi Kokusai Electric America, Ltd.
  • Page 5: Table Of Contents

    Lens ······································ 4-5 Setting ··································· 6-11 Specifications ·························· 12 Introduction Features Hitachi’s camera KP-HD1005-S5 is HD-SDI interface one High definition which support Full HD. ・They are high definition and wide viewing angle because it is full HD. ・Low delay HD video signal and long-distance transmission...
  • Page 6: Name And Function

    Name and function Tripode adaptor installation screw hole Flange back adjustment dial Adjust the flange back Refer to page 4 (Flange back adjustment) LENS connector [LENS] Connect the lens cable, when using automatic iris lens. Refer page (Lens connectors). Camera installation Camera menu setting operation switch [MENU] Back...
  • Page 7: Connections

    Connections Example of connection Supported formats RGB monitor SXGA 60p RGB cable AC100~230V HD-SDI output HD-SDI color camera KP-HD1005-S5 MU-HD101 back Coaxial cable ※Refer to cable length standard DC12V Power over coaxial DVI-D cable Coaxial cable Supported formats 1080 59.94i...
  • Page 8: Lens

    Lens Lens selection Lens connectors 1) Dimension A) of lens installation part should be according to When a lens-connector-free automatic iris lens is used, the the figure below. When the lens with dimention more than the optional lens plug is installed in the lens cable as follows. following size is installed, the internal damage of camera may Please refer the manual for signal and color combination of occur.
  • Page 9: Lens

    Note If an auto iris lens is used and the object distance is less than few meters, due to focus length of lens, slight blurring can occur at certain iris positions. In such case, please refer to page 10[Lens open setting] and set the lens to full open.
  • Page 10: Setting

    Setting Setup by the operating switch in a back part Up(U) Down(D) Right(R) Left(L) button: Movement of a cursor Center (Set) button : Determination of a selection item MENU buttons Composition of camera setting menu...
  • Page 11: Main Menu

    MAIN MENU Sensitivity enhancement setting (SENS UP) 1) Press the Set button for at least 2 seconds to display the (1) It is on a MAIN MENU display, a cursor can be united with Main menu on the monitor screen. SENS UP with the upper (below) direction switch, and a sensitivity rise setup can be switched with a horizontal direction switch.
  • Page 12: Gain Menu

    GAIN MENU SUB MENU SUB MENU GAIN MENU ……Chroma level setting CHROMA ……Gain mode setting MODE :AGC ……Detail correction setting DETAIL …… Fixed amplification setting *PRESET GAIN: 0dB ……Black level setting PEDESTAL …… Maximum amplification setting AGC LIMIT : 48dB ……Gamma correction setting GAMMA ……KNEE mode setting...
  • Page 13 TITLE (1) SLOPE 1 : KNEE slope 1 0 to 255 (2) SLOPE 2 : KNEE slope 2 0 to 255 (3) POINT 1 : KNEE point 1 0 to 255 (64 = 100%) TITLE Set data (4) POINT 2 : KNEE point 1 0 to 255 Text to display...
  • Page 14: System Menu

    (1) B/W MODE: TV FORMAT (video output) OFF : This mode is of color picture. The format displayed now is displayed (fixed value). ON : This mode is of black and white picture (2) ASPECT :Set ASPECT ratio AUTO(H):About 70% or less of proper value 16:9: 16:9 ratio AUTO(M):About 50% or less of proper value...
  • Page 15 Remote-contact operation The plug is wired as shown in the figure and connected to the remote connector of the camera rear panel. HR10A-10P-12P(73) (option) PC side (The placement which is seen from D-sub 9pin the back of plug) RS-232C mode Signal Remarks Pin No.
  • Page 16: Specifications

    Specifications Imaging device 1/3” Progressive Scan MOS Total pixels 2010(H)x1108(V) 2.2M pixels Effective pixels 1944(H)x1092(V) 2.1M pixels Sync system Internal Video output HD-SDI / Analog CVBS Video format HD-SDI: 1080 29.97p /59.94i/ 25p/ 50i CVBS: NTSC/ PAL Transmission distance HD-SDI Std mode: max100m (5C-2V 75ohm) HD-SDI POC mode: max 80m (5C-2V 75ohm/ Exclusive multiunit MU-HD101 use) Minimum illumination Color: 0.2lux(F1.2/AGC48dB)
