- Page 1 V RM IR N Carpo 4 deluxe I N S T R U C T I O N M...
- Page 2 No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without written permission of the publisher, or processed, duplicated or distributed by using electronic systems. © N.V. Vermeiren N.V. 2012...
-
Page 3: Table Of Contents
Carpo 4 Deluxe 2012-04 Contents Productdescription ....................3 Intended Use ....................... 3 Safety instructions ...................... 4 Technical specifications ....................5 Components ........................ 6 Accessories ......................... 7 Location identification plate ..................7 Explanation of symbols ....................7 Use ..........................8 Remarks on electromagnetic compatibility (EMC) ............ 8 Carrying the scooter .................... - Page 4 Following the user instructions and the maintenance instructions are an essential part of the warranty. This manual reflects the latest product developments. Vermeiren has the right to introduce changes without the obligation to adapt or replace previously delivered models. For any further questions, please consult your specialist dealer.
-
Page 5: Productdescription
The electric scooter can be used on sidewalks, urban road. Under no circumstances the scooter may be used for driving on larger roads or expressways. Use only Vermeiren approved accessories. The manufacturer is not liable for damage caused by the lack of or improper service or as a result of not following instructions from this manual. -
Page 6: Safety Instructions
Carpo 4 Deluxe 2012-04 Safety instructions Use only Vermeiren approved accessories. Before getting on or off, taking apart or transporting your scooter, turn the start key to the “off” position. When transporting the scooter, no persons may be transferred along with it. -
Page 7: Technical Specifications
Carpo 4 Deluxe 2012-04 Technical specifications Technical terms below are valid for the scooter in standard settings and optimum environmental conditions. If other accessories are used, the tabulated values will change. Changes in outdoor temperatures, humidity, uphills, downhills, soils and battery levels can reduce output. -
Page 8: Components
Carpo 4 Deluxe 2012-04 Brand Vermeiren Address Vermeirenplein 1/15, B-2920 Kalmthout Type Rear wheel drive scooters, Class B Model Carpo 4 Deluxe Maximum occupant mass 150 kg Description Minimum dimensions Maximum dimensions Diameter Rear wheels (number) 100 x 50 mm-10 air (2) Tyre pressure, rear (driving) wheels Max. -
Page 9: Accessories
Carpo 4 Deluxe 2012-04 Accessories The following accessories are available for the scooters Carpo 4 Deluxe: • WARNING: Risk of injury - Be sure that crutches are attached very well and can not fall on the user. Crutch holder •... -
Page 10: Use
Carpo 4 Deluxe 2012-04 This chapter describes the everyday use. These instructions are for the user and the specialist dealer. The scooter is delivered fully assembled by your specialist dealer. The instructions intended for the specialist dealer on how to set up the scooter are given in § 3. -
Page 11: Carrying The Scooter
Carpo 4 Deluxe 2012-04 Other home devices like CD player, notebook, cordless phones, AM/FM radios, electric shavers and hair dryers, so far as we know, will have no influence provided that they function perfectly and their cabling be in an excellent condition. Please conform to the operating instructions accompanying such electric instruments to ensure trouble free operating of your scooter. -
Page 12: Operating The Brakes
Carpo 4 Deluxe 2012-04 To disassemble, please proceed as follows: • Switch the scooter off. • Remove the seat (see “Adjusting the seat” chapter). • Lift off the rear plastic cover of the batteries. • Loosen the straps used to fasten the batteries in place. -
Page 13: Correct Position In The Scooter
Carpo 4 Deluxe 2012-04 Correct position in the scooter Some recommendations for a comfortable use of the scooter: 1. Position your backside as close as possible to the back rest. 2. Make sure your upper legs are horizontal. Driving the scooter... - Page 14 Carpo 4 Deluxe 2012-04 • Driving Once you are seated on your scooter and have started it as described above, take hold of the speed lever with both hands, put your thumbs to push the speed lever in the required direction, i.e.:...
- Page 15 Carpo 4 Deluxe 2012-04 2.7.6 Going uphill L L L L WARNING: Control your scooter - Accustom yourself with the driving behavior of your scooter. L L L L WARNING: Control your scooter - Never put your scooter in neutral on slopes.
-
Page 16: Driving The Scooter On Ramps
Carpo 4 Deluxe 2012-04 Driving the scooter on ramps L L L L WARNING: Risk of injury - Do not exceed the maximum load of the ramps. L L L L WARNING: Risk of injury - Choose the correct ramps so there cannot be caused any injury or damage. -
Page 17: Neutral
6 = Emergency lights 7 = Lights (front and rear) 8 = Indicator (left) 9 = Indicator (right) Vermeiren is responsible for the changes in the software. For changes in the software contact Vermeiren. 2.11 Neutral L L L L... -
Page 18: Transport In The Car
Carpo 4 Deluxe 2012-04 Drive Neutral Motor stop lever 2.12 Transport in the car DANGER: Risk of injury - The scooter is not suited for use as a seat in a motor vehicle. WARNING: Risk of injury - Remove all loose parts prior to transportation. -
Page 19: Charging The Batteries
Carpo 4 Deluxe 2012-04 2.14 Charging the batteries WARNING: Risk of injury - Take out the key before you start charging. WARNING: Risk of fire - Keep away from flammable objects while charging as it may lead to fire of battery. -
Page 20: Installation And Adjustment
The instructions in this chapter are for the user and the specialist dealer. To find a service facility or specialist dealer near you, contact the nearest Vermeiren facility. A list of Vermeiren facilities can be found on the last page. -
Page 21: Adjusting The Steering Unit
Carpo 4 Deluxe 2012-04 Adjusting the steering unit The steering unit can be adjusted in to many different positions (stepless) to suit each driver. L L L L WARNING: Risk of injury - Never adjust the angle while you are driving. -
Page 22: Adjusting The Back
Carpo 4 Deluxe 2012-04 1 = Seat 2 = Seat depth rail 3 = Seat depth adjustment lever 4 = Receiver 5 = Seat guide 6 = Seat angle lever Adjusting the back L L L L WARNING: Risk of injury - Never perform adjustments while you are driving. -
Page 23: Adjusting The Armrests
Carpo 4 Deluxe 2012-04 Adjusting the armrests The angle of the armrest can be adjusted according following instructions: • Rotate the knob at the back of the armrest up or down. • Adjust the armrest to a comfortable position. • Release the knob... -
Page 24: Thermal Fuses
Carpo 4 Deluxe 2012-04 Check all around on both sides that the tube is not pinched between the rim and the edge of the tyre. Lightly push the air valve inwards and pull it out again to make sure that the tyre is positioned properly in the region of the air valve. -
Page 25: Changing The Battery
Lifetime of the scooter strongly is influenced by its use, storage, regular maintenance, servicing and cleaning. Regular Maintenance Please turn the scooter "OFF" and remove the cable of the battery charger before performing maintenance activities. The maintenance activities to ensure a good condition for your Vermeiren scooter are described below: • Before every ride Check the tyres and make them clean. -
Page 26: Shipping And Storage
Repairing and assembling of spare parts for your scooter may only be performed by the specialist dealer. Only authorized Vermeiren spare parts may be installed. Shipping and storage The shipping and storage of the scooter shall be according following instructions: •... -
Page 27: Plastic Parts
Carpo 4 Deluxe 2012-04 Never clean with steam and/or pressure washers. The cloth is washable; use only a cloth moistened by a mild commercial detergent. Do not use petrol, solvents, vaporizing solution or wax. We shall decline all liability for damage caused by the use of improper cleaning agents. -
Page 28: Inspection
Carpo 4 Deluxe 2012-04 Inspection In principle we recommend one inspection every year, and a minimum of one before usage is resumed. All of the following checks must be performed and documented by authorized persons: • Visually check the frame parts for plastic deformation, cracks and impaired functioning. (basic frame, seat frame, back frame, side parts, motor suspensions) •... -
Page 29: Troubleshooting
Carpo 4 Deluxe 2012-04 Troubleshooting The following list will assist you with the troubleshooting of your scooter. Problem Cause of problem • The scooter refuses to go once started. Key not in place or switched on. • No indication of load level Battery plug not connected (batteries not making contact). -
Page 30: Disinfection
Carpo 4 Deluxe 2012-04 Disinfection L L L L WARNING: Dangerous Products - The use of disinfectants is restricted to authorized personnel. L L L L WARNING: Dangerous Products, change on irritate your skin - You should wear suitable protective clothing because the disinfectants could irritate your skin. For this purpose you should also take note of the product information of the solutions concerned. - Page 31 Carpo 4 Deluxe 2012-04 Product name Laundry Surface Disinfection of excretions Area of Manufacturer or Active substance disinfection effectiv- Supplier disinfection 1 part sputum or stools + 2 parts eness (scrubbing- diluted so lution or 1 part urine + 1 part...
-
Page 32: Warranty
Carpo 4 Deluxe 2012-04 Warranty Excerpt from the "General Business Conditions": (...) 5. The warranty period for warranty claims is 24 months (6 months for batteries). (...) The guarantee excludes damage arising from structural changes to our products, insufficient maintenance, defective or improper handling or storage or the use of non-original parts. Likewise, the guarantee excludes parts or working parts subject to natural wear and tear. -
Page 33: Maintenance Plan
Carpo 4 Deluxe 2012-04 Maintenance plan Date Maintenance Remarks Paraph 1/1/2012 Greasing and general servicing non Disinfection book Date of the Reason Specification Substance and Signature disinfection concentration Abbreviations used in column 2 (reason): V = Suspected infection IF = Infection case... - Page 34 Dealer´s stamp: Dealer´s stamp: Date: Date: Dealer´s stamp: Dealer´s stamp: Date: Date: Dealer´s stamp: Dealer´s stamp: Date: Date: • For service checklists an additional technical information, please see our specialist dealers nearest to you. More information on our website at: www.vermeiren.com.
- Page 37 Notes ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 38 Notes ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 40 Fax: +41(0)31 818 40 98 website: www.reatime.it website: www.vermeiren.ch e-mail: info@reatime.it e-mail: info@vermeiren.ch Poland The Netherlands Vermeiren Polska Sp. z o.o Vermeiren Nederland B.V. Domstraat 50 Łączna PL-55-100 Trzebnica NL-3864 PR Nijkerkerveen Tel: +48(0)71 387 42 00 Tel: +31(0)33 2536424...
