- Page 1 123 Industrial Loop Road Paynesville, MN 56362 Phone: 1-800-864-1649 www.master-mfg.com ASTER ASTER ARDNER ANUFACTURING Part Number PCD-E3-009B-MM Rev 2 Dec. 2012...
- Page 2 Note: Do not return product to the distributor/dealer for warranty work. Call Master Manufacturing at (800) 864-1649 for any warranty work or replacement parts. INTRODUCTION The purpose of this manual is to assist you in the assembly, operation and maintenance of your Master Gardner sprayer.
- Page 3 3.) Attach the trailer tongue (Item 8, figure B) to the sprayer frame (Item 7, figure B) aligning the holes and using the pin and hair pin (Item 3, figure B). Setup Charging the Battery 1.) Obtain the battery charger (Item 27, figure B) and plug the charger into an AC wall outlet and the other end into the charging port located on the sprayer.
- Page 4 Caution Do not spray on windy days. Protective clothing must be worn in some cases. Be sure to read the chemical label carefully. After all calibrations have been completed, add water and chemical to the tank. Always follow chemical manufacturer’s instructions for mixing. Operation Ensure battery is fully charged to provide optimum efficiency from the 12volt pump.
- Page 5 TROUBLE SHOOTING Pump will not turn on: 1. Ensure the power switch or remote switch is in the on position (the I position is on and the O position is off). 2. Ensure the battery is fully charged. Refer to SETUP: charging the battery. 3.
- Page 6 Master Gardner Frame Figure A Parts List Master Gardner Frame Figure A Item # Part Number Description 33-100158 Frame, Handle (Only available as entire frame) 33-100157 Handle adjustment knobs (pair with bolts) 33-100156 Hitch Pin TWA12.5x2-5/8 Wheel and Tire TWA12x1.75x1/2 Wheel, composite (plastic) 33-100155 Axel Nut and Washer (pair)
- Page 7 Master Gardner Tank Assembly Figure B...
- Page 8 Parts List Master Gardner Tank Assembly Figure B Item # Part Number Description TL-6B Tank Lid TLS-5D Basket Strainer TL-6B-GAS Gasket SG-4200-18 Spray Gun assembly SG-42ASSY-18 Nozzle Ass., SG-4200 gun RCH-14-15 Recoil Hose GC-100-KIT Gun Clips (pair) 31-100249 Nozzle Bracket NTL38 Nozzle body and nut NS-50...
