Position the radio, display, keyboard, mouse and wireless keyboard controller in
their operating positions
Turn the mouse and keyboard upside down for easy access to the connect buttons
Turn on your display/monitor/LCD panel and select D-sub source if applicable
Turn on your 13.8 VDC power supply
Turn on the FLEX-5000C using the power button on the front panel (press momentarily). A
1-2 second delay between power on and seeing the blue light is normal
Blue light should show on the power button, fans should start inside and green light shows
on the wireless keyboard controller. If not, cut 13.8 VDC power and recheck your
connections
Blue light from the two cooling fans may also be seen through vents at bottom of front
panel
Press and release the "connect" button on the wireless keyboard controller
Press and release the "connect" button on the bottom of the keyboard
Wait at least 20 seconds before the next step
Press and release the "connect" button on the wireless keyboard controller again
Press and release the "connect" button on the bottom of the mouse
Move the mouse and check for pointer motion on the display
The mouse and keyboard reference sheet provides additional details
Information:
At this point you should see the Microsoft opening screen and hear sound if you added computer
speakers. If you are unable to spend about 5 minutes completing the next section, you may turn
off the system by turning off the power supply. It will not be possible to stop the computer by
using the front panel button
Set up your new computer and enter the product key
The following steps are the "Out of Box Experience" provided by your new computer's operating
system. The operating system is preinstalled but in a "sealed" state. It is not usable until you
accept the End User Licensing Agreement contained in the operating system. FlexRadio is not in
control of this process since the software use agreement is between you, the end user and
Microsoft.
FLEX-5000C Quick Start Guide
.
Version 1.2
Page 6
