Table Of Contents - Jandy POOL LINK Installation Manual

Section 1. Important Safety Instructions ........... 4
Section 2. System Overview ............................. 6
2.1 Package Contents ............................ 6
2.2 System Component Specifi cations
and Dimensions ............................... 7
Section 3. Installation ........................................ 8
3.1 Pool Link Control System
Mounting ......................................... 8
3.2 Attach Labels .................................. 8
3.2.1 Wiring Diagram Label .................. 8
3.2.2 "What The Switches Do" Label ... 8
3.3 High Voltage Wiring ....................... 8
3.3.1 System Power ............................... 8
3.3.2 3HP (Standard) Relays ................. 8
3.3.3 Bonding the Pool Link ................. 8
3.4 Low Voltage Wiring ..................... 10
3.4.1 Wire Relays to Printed
Circuit Board ................................ 10
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAN FILTER)
PUMP MODEL
FILTER MODEL
CONTROL PANEL MODEL
NOTES:

Table of Contents

EQUIPMENT INFORMATION RECORD
3.4.2 In-Floor Cleaning System ............ 10
3.4.3 Wire Time Clock to Printed
Circuit Board ................................ 10
3.4.4 Connect Heater to Printed
Circuit Board ................................ 10
3.4.5 Connect Freeze Protection Sensor
to Printed Circuit Board ............... 11
3.4.6 Set Jumpers and Diode ................. 11
3.4.7 Connect System Power to
Printed Circuit Board ................... 12
Section 4. System Startup .................................. 13
4.1 Set Time Clocks and Test
Equipment ....................................... 13
4.2 Single-Speed Filtration Pump Plus
Cleaner Booster Pump Operation ... 13
4.3 Two-Speed Filter Pump Operation . 13
4.4 Heater Cool Down .......................... 13
4.5 Freeze Protection ............................ 13
Warranty .......................................................... 16
HORSEPOWER
SERIAL NUMBER
SERIAL NUMBER
Page 3
