Icom IC-FR4000 Service Manual page 36

[50PA UNIT]
REF ORDER
NO. NO.
R45 7030003560 S.RESISTOR
R46 7030000180 S.RESISTOR
R47 7030003320 S.RESISTOR
R48 7030003560 S.RESISTOR
R50 7030003200 S.RESISTOR
R51 7030003680 S.RESISTOR
R52 7030003600 S.RESISTOR
R53 7030003450 S.RESISTOR
R54 7030003320 S.RESISTOR
R55 7030003560 S.RESISTOR
R56 7030003440 S.RESISTOR
R57 7030003640 S.RESISTOR
R58 7030003660 S.RESISTOR
R59 7030003630 S.RESISTOR
R60 7030003520 S.RESISTOR
R61 7510001660 S.THRMISTOR
R62 7030003480 S.RESISTOR
R63 7030003480 S.RESISTOR
R64 7030003700 S.RESISTOR
R66 7030003600 S.RESISTOR
R67 7030003660 S.RESISTOR
R68 7030003640 S.RESISTOR
R69 7030003320 S.RESISTOR
C1 4030006860 S.CERAMIC
C2 4030006860 S.CERAMIC
C3 4030007010 S.CERAMIC
C4 4030007040 S.CERAMIC
C5 4030006860 S.CERAMIC
C6 4030006850 S.CERAMIC
C7 4030017200 S.CERAMIC
C8 4030009520 S.CERAMIC
C9 4030009520 S.CERAMIC
C10 4030017190 S.CERAMIC
C14 4030017890 S.CERAMIC
C17 4030018290 S.CERAMIC
C18 4030018050 S.CERAMIC
C19 4030018050 S.CERAMIC
C20 4030018170 S.CERAMIC
C21 4030018430 S.CERAMIC
C24 4030018030 S.CERAMIC
C25 4030018030 S.CERAMIC
C26 4030018460 S.CERAMIC
C30 4030018460 S.CERAMIC
C31 4030018030 S.CERAMIC
C32 4030018030 S.CERAMIC
C38 4030006860 S.CERAMIC
C39 4030006850 S.CERAMIC
C40 4030006860 S.CERAMIC
C41 4510007670 S.ELECTROLYTIC EEVHB1C100R
C43 4030006850 S.CERAMIC
C44 4030006860 S.CERAMIC
C45 4030006850 S.CERAMIC
C46 4030006860 S.CERAMIC
C47 4510007960 ELECTROLYTIC KMY25VB1000
C48 4030017190 S.CERAMIC
C49 4030017200 S.CERAMIC
C55 4030006860 S.CERAMIC
C56 4030009520 S.CERAMIC
C57 4030006860 S.CERAMIC
C58 4030011600 S.CERAMIC
C59 4030006860 S.CERAMIC
C60 4030006860 S.CERAMIC
C61 4510007690 ELECTROLYTIC LXZ25VB2200
C62 4030007170 S.CERAMIC
C64 4030007170 S.CERAMIC
C66 4030009520 S.CERAMIC
C68 4030006860 S.CERAMIC
C69 4510007570 S.ELECTROLYTIC EEVHB1C220UR
C70 4030007170 S.CERAMIC
C71 4030006860 S.CERAMIC
C72 4030006860 S.CERAMIC
C73 4030006860 S.CERAMIC
C74 4030006860 S.CERAMIC
C75 4030006850 S.CERAMIC
C76 4030006850 S.CERAMIC
C80 4030006860 S.CERAMIC
C81 4030006860 S.CERAMIC
C83 4030007130 S.CERAMIC
C85 4030018290 S.CERAMIC
C86 4030018450 S.CERAMIC
DESCRIPTION
ERJ3GEYJ 103 V (10 kΩ)
MCR10EZHJ 22 Ω (220)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
NTCG16 4LH 473KT
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 101 V (100 Ω)
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 100D-T
C1608 CH 1H 180J-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
GRM31BR32J102KY01L
C1608 CH 1H 020B-T
C1608 CH 1H 020B-T
GRM31AR32J471KW01D
ERF22X 6C2H 101J D01L
ERF22X 6C2H 390J D01L
ERF22X 6C2H 270J D01L
ERF22X 6C2H 270J D01L
ERF22X 6C2H 4R0C D01L
ERF22X 6C2H 6R0D D01L
ERF22X 6C2H 3R0C D01L
ERF22X 6C2H 3R0C D01L
ERF22X 6C2H 100J D01L
ERF22X 6C2H 100J D01L
ERF22X 6C2H 3R0C D01L
ERF22X 6C2H 3R0C D01L
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
GRM31AR32J471KW01D
GRM31BR32J102KY01L
C1608 JB 1H 102K-T
C1608 CH 1H 020B-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 221J-T
C1608 CH 1H 221J-T
C1608 CH 1H 020B-T
C1608 JB 1H 102K-T
C1608 CH 1H 221J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 101J-T
ERF22X 6C2H 390J D01L
ERF22X 6C2H 8R0D D01L
[50PA UNIT]
REF ORDER
NO. NO.
C87 4030018430 S.CERAMIC
C88 4030009500 S.CERAMIC
C89 4030009530 S.CERAMIC
C90 4030006850 S.CERAMIC
C91 4030006860 S.CERAMIC
C93 4030006850 S.CERAMIC
C94 4030006860 S.CERAMIC
C95 4030006850 S.CERAMIC
C96 4030006860 S.CERAMIC
C97 4510007940 ELECTROLYTIC KMY25VB100
C98 4030011730 S.CERAMIC
C99 4510007570 S.ELECTROLYTIC EEVHB1C220UR
C100 4030006860 S.CERAMIC
C101 4030006860 S.CERAMIC
C102 4030006860 S.CERAMIC
C103 4030011600 S.CERAMIC
C104 4510007570 S.ELECTROLYTIC EEVHB1C220UR
C105 4030006850 S.CERAMIC
C106 4030006850 S.CERAMIC
C107 4030006900 S.CERAMIC
C108 4030006900 S.CERAMIC
C109 4510007670 S.ELECTROLYTIC EEVHB1C100R
C110 4510007670 S.ELECTROLYTIC EEVHB1C100R
C111 4030006860 S.CERAMIC
C112 4030017890 S.CERAMIC
C113 4550006250 S.TANTALUM
C119 4030018170 S.CERAMIC
C125 4030018470 S.CERAMIC
C126 4030018470 S.CERAMIC
C134 4030017490 S.CERAMIC
J1 6510022800 S.CONNECTOR
J2 6510007020 CONNECTOR
J5 6510021390 CONNECTOR
T2 5910000920 TRANSFORMER CD-C-L030H-6R0
W2 7030003860 S.JUMPER
W3 7030003860 S.JUMPER
W4 7030003860 S.JUMPER
W5 7030003860 S.JUMPER
W6 7030003860 S.JUMPER
W10 7030003860 S.JUMPER
EP1 6910014490 TERMINAL
EP2 6910014490 TERMINAL
EP3 0910056177 PCB
[VARISTOR UNIT]
REF ORDER
NO. NO.
D1 1790000720 DIODE
EP1 6910012350 S.BEAD
EP2 0910056182 PCB
5 - 14
DESCRIPTION
ERF22X 6C2H 6R0D D01L
C1608 CH 1H 0R5B-T
C1608 CH 1H 030B-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
C1608 JB 1H 471K-T
C1608 JB 1H 102K-T
GRM31M2C2H101JV01L
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 JB 1H 471K-T
C1608 JB 1H 471K-T
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C1608 JB 1H 102K-T
ERF22X 6C2H 101J D01L
TEMSVA 1A 106M-8L
ERF22X 6C2H 4R0C D01L
ERF22X 6C2H 220J D01L
ERF22X 6C2H 220J D01L
C1608 JB 1A 105K-T
B10B-PH-SM3-TB
TMP-J01X-V6
IMSA-9230B-1-03Z024-T
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
OP-100 M3
OP-100 M3
B 5663G
DESCRIPTION
MA29W-B
MMZ1608Y 102BT
B 5662B
S.=Surface mount
