- Page 1 Walker, Michigan, U.S.A. 49534-7564 USER’S OPERATING AND INSTRUCTION MANUAL MODEL 2005 VARIABLE SLICE THICKNESS BREAD SLICER LISTED E65166 2005S20000-CV-1...
-
Page 2: Table Of Contents
2005 VARIABLE THICKNESS BREAD SLICER INDEX Section Description Document No. Page No. SAFETY INSTRUCTIONS ------------------------------- 2005S20001 --------------------- 1-1 DESCRIPTION/SPECIFICATIONS -------------------- 2005S20002---------------------- 2-1 Description -------------------------------------------------------------------------------------- 2-1 Physical Specifications----------------------------------------------------------------------- 2-1 OPERATING INSTRUCTIONS ------------------------- 2005S20003 --------------------- 3-1 MAINTENANCE -------------------------------------------- 2005S20004 --------------------- 4-1 Cleaning ----------------------------------------------------------------------------------------- 4-1... - Page 3 2005 VARIABLE THICKNESS BREAD SLICER INDEX (Continued) REPLACEMENT PARTS SECTION (Continued) Section Description Document No. Page No. PUSHER WITH STEPPER ----------------------------- 2005S20010 -------------------- 10-1 Drawing ------------------------------------------------------------------------------------ 10-1 Parts List ---------------------------------------------------------------------------------- 10-2 TABLES & COVERS -------------------------------------- 2005S20011 -------------------- 11-1 Drawing ------------------------------------------------------------------------------------ 11-1...
-
Page 4: Safety Instructions
2005 VARIABLE THICKNESS BREAD SLICER SAFETY INSTRUCTIONS Various safety devices and methods of guarding have been provided on this machine. It is essential; however, that machine operators and maintenance personnel observe the following safety precautions. Improper installation or operation of this equipment may cause injury to personnel or damage to equipment. -
Page 5: Description/Specifications
DESCRIPTION/SPECIFICATION Description The Oliver Model 2005 is a variable slice thickness bread slicer, which utilizes a new and innovative way to slice bread. The bread is moved past a circular blade, which is mounted to a moving arm, cutting each slice individually to whatever thickness is selected. - Page 6 2005 VARIABLE THICKNESS BREAD SLICER OVERALL MACHINE DIMENSIONS 2005S20002...
-
Page 7: Operating Instructions
Close both doors. Turn the machine on. The pusher will move back to home if the machine has been turned off while the pusher is out of the home (farthest left) position. The display will display the Oliver logo and language selections. Standard Operation: ·... -
Page 8: Maintenance
2005 VARIABLE THICKNESS BREAD SLICER MAINTENANCE WARNING DISCONNECT AND LOCK OUT THE MACHINE FROM THE POWER SUPPLY BEFORE CLEANING OR SERVICING. REMEMBER TO USE CARE AND WEAR CUT RESISTANT GLOVES WHENEVER YOU ARE WORKING WITH OR NEAR THE BLADE. Cleaning: (daily) Use a mild detergent solution applied with a cloth or spray cleaner on all exterior and interior surfaces as necessary. -
Page 9: Troubleshooting / Set-Up
2005 VARIABLE THICKNESS BREAD SLICER TROUBLE SHOOTING/ SET-UP GUIDE WARNING DISCONNECT AND LOCK OUT THE MACHINE FROM THE POWER SUPPLY BEFORE CLEANING OR SERVICING. WARNING REMEMBER TO USE CARE AND WEAR CUT RESISTANT GLOVES WHENEVER YOU ARE WORKING WITH OR NEAR THE BLADE. -
Page 10: The Blade Is Crushing The Bread
2005 VARIABLE THICKNESS BREAD SLICER The Blade Is Crushing The Bread. The bread may be too warm for slicing. A build-up on the blade from slicing warm bread or sticky fruit breads can cause this type of product damage or malfunction. -
Page 11: Manual Diagnostic And Set-Up Mode
2005 VARIABLE THICKNESS BREAD SLICER Manual Diagnostic and Set-Up Mode: The machine may be put into Manual Diagnostic Mode to check several functions of the machine. To enter this mode, simply do the following: Wait for the initial screen to come up (pusher must be in the home position, and may take up to a minute) or cycle the power switch to bring up the initial screen. - Page 12 2005 VARIABLE THICKNESS BREAD SLICER 4. The function of the switches for the doors can be verified as the doors are opened and closed by observing the “R DOOR” and “L DOOR” switches. 5. The function of the bread sensor can be verified by blocking the photo eye on the back wall of the bread platform (near the blade slot) and observing the “BREAD SWITCH”...
-
Page 13: Recommended Spare Parts
2005 VARIABLE THICKNESS BREAD SLICER RECOMMENDED SPARE PARTS PART NUMBER PART DESCRIPTION NO. REQ’D. 2005-25018K Cleaning Kit 2003-0006 Plate-Pusher W/Pins 2005-0115 Eye-Photo W/Harness 5757-7540 Switch-Reed W/ connectors 5250-0386 Bearing-Ball 1/2 X 1-1/8 5250-0387 Bearing-Ball 5/8 X 1-3/8 5251-3420 Bearing-Ball 4B Flange... - Page 14 2005 VARIABLE THICKNESS BREAD SLICER MAIN FRAME ASSEMBLY Rev. 10-8-03 2005S20007...
-
Page 15: Main Frame
2005 VARIABLE THICKNESS BREAD SLICER MAIN FRAME PARTS LIST ITEM NO. PART DESCRIPTION PART NUMBER Main Frame 2005-0054 Cover-Electrical 2003-0021 Track-Crumb Tray 2003-0038 Bumper-Rubber 5902-0021 Plate-Face 2003-0003 Tray-Crumb 2003-0037 Angle-Table Support 2003-0011-1 Spacer-Angle 2003-0034 *009 Stiffener 2003-0054-1 *010 Plate-splice 2005-0058 *Not shown on drawing Rev. -
Page 16: Blade & Clutch Drive
2005 VARIABLE THICKNESS BREAD SLICER BLADE & CLUTCH DRIVE ASSEMBLY 2005S20008... -
Page 17: Parts List
2005 VARIABLE THICKNESS BREAD SLICER BLADE & CLUTCH DRIVE PARTS LIST ITEM NO. PART DESCRIPTION PART NUMBER Motor-Brake 3/4 HP 6301-5611 Sheave 3L, 2-Grooves 1.5 OD 2003-0070 Belt-V 3L230 5601-1033 Nutbar 2001-0015 Gearmotor 1/8 HP DC (115 VAC) 6310-0008 Pulley-Timing Belt... -
Page 18: Cutoff Arm
2005 VARIABLE THICKNESS BREAD SLICER CUTOFF ARM ASSEMBLY 2005S20009... -
Page 19: Parts List
2005 VARIABLE THICKNESS BREAD SLICER CUTOFF ARM PARTS LIST ITEM NO. PART DESCRIPTION PART NUMBER Block-Pivot Outside 2001-0041 Bearing-Ball 5250-0387 Ring-Retaining #N5000-137 5840-1026 Shaft-Drive 2001-0047-1 Pulley-Timing Belt 2003-0044 Sheave-3L, 2-Grooves 3.882 OD 2003-0071 Ring-Retaining #5100-62 5840-1128 Side-RH Arm 2003-0046-1 Side-LH Arm... - Page 20 2005 VARIABLE THICKNESS BREAD SLICER PUSHER WITH STEPPER ASSEMBLY Rev. 10-8-03 2005S20010 10-1...
-
Page 21: Parts List
2005 VARIABLE THICKNESS BREAD SLICER PUSHER WITH STEPPER PARTS LIST ITEM NO. PART DESCRIPTION PART NUMBER Bar-Motor 2005-0049 Motor-Stepper 6300-0017 Pulley-Timing Belt 2005-0039 Belt-Timing # 510L050 5601-3420 Spindle-Idler 2001-0051 Pulley-Idler Timing 2001-0050 Bearing-Ball 5250-0386 Ring-Retaining # N5000-112 5840-1020 Clamp-Belt 2001-0034... - Page 22 2005 VARIABLE THICKNESS BREAD SLICER TABLE & COVER ASSEMBLY Rev. 10-8-03 2005S20011 11-1...
- Page 23 2005 VARIABLE THICKNESS BREAD SLICER TABLE & COVER PARTS LIST ITEM NO. PART DESCRIPTION PART NUMBER Guard-Blade 2005-0014-001 Knob-Screw 4560-2508-1106 Panel-Infeed 2005-0043-001 Nutbar-Infeed 2001-0102-001 Table-Rear Adj. Infeed 2005-0050-1 Pin 1/4 Diameter X 3/4 4475-0516-075 Nut-Cage 1/4-20 5832-0425 Nutbar-Outfeed 2001-0103-001 Table-Front Adj. Infeed...
- Page 24 2005 VARIABLE THICKNESS BREAD SLICER CLUTCH ASSEMBLY Rev. 12/13/12 CLUTCH ASSEMBLY PARTS LIST ITEM NO. PART DESCRIPTION PART NUMBER Bracket-Clutch 2005-0124 Spacer 2001-0032 Bearing-Flange Ball 5251-3420 Clutch 5604-5257 Cover-Clutch 5604-5518 Spacer-Anchor 2001-0017 Plate-Anchor 2001-0033 Pulley-Timing Belt 2001-0001 Belt-Timing # 165L050...
- Page 25 2005 VARIABLE THICKNESS BREAD SLICER Shaft-Drive 2005-0123 Crank 2003-0028 4384-0404-075 Cam, Arm Switch 2005-0120 Switch, Roller 5757-8002 Block, Limit Switch Spacer 1908-0408 Plate, Arm Switch 2005-0121 Rev. 12/13/12 2005S20012 12-2...
- Page 26 2005 VARIABLE THICKNESS BREAD SLICER ELECTRICAL SUB-PANEL ASSEMBLY 2005S20013 13-1...
- Page 27 2005 VARIABLE THICKNESS BREAD SLICER ELECTRICS 1-60-115 PARTS LIST ITEM NO. PART DESCRIPTION PART NUMBER Switch-Reed 5757-7540 Washer 8851-8466 Cord-Power 115V 2005-0102 Bushing-Strain Relief 5765-1079 Harness-Wire (Stepper) 2005-0100 Wire-Ground 6” 2005-0037 Harness-Wire 18” (Arm Sensor) 2005-0113 Harness-Wire (LT Door Switch)
- Page 28 2005 VARIABLE THICKNESS BREAD SLICER WIRE DIAGRAM 1-60-115 PAGE 1 OF 3 2005S20015 15-1...
- Page 29 2005 VARIABLE THICKNESS BREAD SLICER WIRE DIAGRAM 1-60-115 PAGE 2 OF 3 2005S20015 15-2...
- Page 30 2005 VARIABLE THICKNESS BREAD SLICER WIRE DIAGRAM 1-60-115 PAGE 3 OF 3 REV. 12-13-12 2005S20015 15-3...
- Page 31 WARRANTY PARTS Oliver Packaging & Equipment Company warrants that if any part of the equipment (other than a part not manufactured by Oliver Packaging & Equipment ) proves to be defective (as defined below) within one year after shipment, and if Buyer returns the defective part to Oliver Packaging & Equipment within one year, Freight Prepaid to Oliver Packaging &...
- Page 32 4. The service dealer will then complete an invoice and send it to the Parts and Service Department at Oliver Packaging & Equipment Company. 5. The Parts and Service Manager of Oliver Packaging and Equipment Company will review the invoice and returned parts, if applicable, and approve for payment.
- Page 33 This policy applies to all parts returned to the factory whether for warranted credit, replacement, repair or re-stocking. Oliver Packaging and Equipment Company requires that the customer obtain a Return Material Authorization (RMA) number before returning any part. This number should appear on the shipping label and inside the shipping carton as well.
