- Page 1 Hikvision Technical Manual DS-9600NI-SH Series Network Video Recorder Technical Manual ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 2 HIKVISION and then only on the condition that this notice is included in any such reproduction. No information as to the contents or subject...
- Page 3 Hikvision Technical Manual Overview Developed by Hikvision on the basis of the latest technology, DS-9600NI-SH Series Network Video Recorder has combined a series of patents and new technologies of video encoding/decoding, embedded system, storage, network technology, etc. DS-9600NI-SH Series NVR...
- Page 4 Hikvision Technical Manual Order Models DS-9604NI-SH, DS-9608NI-SH, DS-9612NI-SH, DS-9616NI-SH Note: 1. The default NVR provides no HDD or CD-R/W. 2. The manufacturer recommended HDD should be used for this device. ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 5: Main Features
Main Features User-friendly GUI for easy operation Connection to IP camera, IP dome and video server Connection to Hikvision, Panasonic, Sony, AXIS, Bosch, SANYO IP cameras, etc. Support decoding at H.264, MPEG4 compression standard, etc. Stream storage at PS standard capsulation format ... - Page 6 Configuration and call up of presets, patrols and patterns. Hard Disk Management Supports up to eight SATA HDD, eight network HDD(eight NAS disks or seven NAS disks+one iSCSI disk), each disk can support over 2TB ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 7 IP conflict, hard disk error and hard disk full. Various alarm response actions supported: camera recording, relay out, ©2006 – 2010 by HIKVISION. All rights reserved.
- Page 8 Import/export of device configuration files. Development Provision of SDK in Windows and Linux operating systems. Application software source code of Demo. Support and training service for application system development. ©2006 – 2010 by HIKVISION. All rights reserved.
-
Page 9: Typical Applications
Distributed video accessing businesses, including the global eyes, wide field of vision Networking video surveillance of examination hall Video surveillance of the intelligent buildings and residential communities Video surveillance of pipelining, workshops and warehouses ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 10: Rear Panel & Interfaces
⑪ RS-485 Serial Interface, RS485 keyboard port, ALARM IN, ALARM OUT ⑫ GND, when cascading multiple devices, it is required that grounding through GND first, and then connecting to the protection ground of control keyboard and power input ⑬ 100~240VAC Power Input ©2006 – 2010 by HIKVISION. All rights reserved. -
Page 11: Specifications
1 RS-485 keyboard serial interface Alarm in Alarm out Chassis 19” standard 2U chassis Power 100~240VAC, 6.3A, 50~60Hz supply Consumpti ≤70W (without HDD) Others Working -10℃~+55℃ temperatu Working 10%~90% humidity 450(W)×450(D)×95(H) Size(mm) Weight ≤8kg (without HDD) ©2006 – 2010 by HIKVISION. All rights reserved.
