Configuring Your Printer

Adding a network connection to a USB-connected computer

For WINDOWS
OS-based
computers
For MACINTOSH
Computers
11
You can change the way you connect to your printer at any time.
To change the printer connection type from USB to a wireless (Wi-Fi) network:
1. On the printer control panel, press Home .
2. Press to select Network Settings , then press OK .
3. Press to select View Network Configuration , press OK , then confirm you
have an IP address.
4. If you have not already done so, connect to your wireless network. See
Configuring a wireless network connection, page
5. On your computer, disable any firewall you have installed until you have
successfully completed the installation For more information on firewalls, go to
www.kodak.com/go/inkjetnetworking.
6. Select Start > All Programs > Kodak > Kodak Printer Network Setup Utility .
7. If your wireless all-in-one printer (example: KodakESP5200+1133) is not listed:
a. Select No, my printer is not listed , then click Next .
b. From the drop-down list, select your printer ( ESP5200 Series (5250/5260 ).
c. Select Network - Wireless/WiFi , then click Next .
When your printer is detected, driver installation begins.
8. If your wireless all-in-one printer (example: KodakESP5200+1133) is listed:
a. Highlight the all-in-one printer that is connected to your network.
b. Select Yes, my printer is listed , then click Next .
When your printer is detected, driver installation begins.
9. When driver installation is complete, click Done .
The printer with a wireless connection is listed as the name of the printer plus a
number (for example, KodakESP5200+1133).
To change the printer connection type from USB to a wireless (Wi-Fi) network:
1. Disconnect the printer from the computer.
2. On the printer control panel, press Home .
3. Press to select Network Settings , then press OK .
to select View Network Configuration , press OK , then confirm you
4. Press
have an IP address. If you do not have an IP address, see
network connection, page
5. From the dock, open System Preferences .
6. Click Print & Fax .
7. Click the + sign to add the printer.
8. Select the printer from the list of available printers, then click Add .
The printer with a wireless connection is listed as the name of the printer plus a
number (for example, KodakESP5200+1133).
www.kodak.com/go/aiosupport
5.
5.
Configuring a wireless
