[MAIN UNIT]
REF ORDER
DESCRIPTION
NO. NO.
EP40 6910018460 S.BEA MMZ1005Y102C-T
EP41 6910018460 S.BEA MMZ1005Y102C-T
EP42 6910018460 S.BEA MMZ1005Y102C-T
EP43 6910018460 S.BEA MMZ1005Y102C-T
EP47 6910018460 S.BEA MMZ1005Y102C-T
EP48 6910018460 S.BEA MMZ1005Y102C-T
EP49 6910014690 S.BEA MPZ1608S221A-T
EP50 6910014690 S.BEA MPZ1608S221A-T
EP51 6910018460 S.BEA MMZ1005Y102C-T
EP52 6910014690 S.BEA MPZ1608S221A-T
EP53 6910014690 S.BEA MPZ1608S221A-T
EP54 6910014690 S.BEA MPZ1608S221A-T
EP55 6910014690 S.BEA MPZ1608S221A-T
EP56 6910018460 S.BEA MMZ1005Y102C-T
EP57 6910018460 S.BEA MMZ1005Y102C-T
EP58 6910018460 S.BEA MMZ1005Y102C-T
EP59 6910014690 S.BEA MPZ1608S221A-T
EP60 6910014690 S.BEA MPZ1608S221A-T
EP61 6910018460 S.BEA MMZ1005Y102C-T
EP62 6910018460 S.BEA MMZ1005Y102C-T
EP63 6910018460 S.BEA MMZ1005Y102C-T
EP64 6910018460 S.BEA MMZ1005Y102C-T
EP66 6910018460 S.BEA MMZ1005Y102C-T
EP68 6910018460 S.BEA MMZ1005Y102C-T
EP69 6910018460 S.BEA MMZ1005Y102C-T
EP70 6910018460 S.BEA MMZ1005Y102C-T
EP71 6910012350 S.BEA MMZ1608Y 102BT
[VR1 UNIT]
REF ORDER
DESCRIPTION
NO. NO.
R1 7210003250 VAR RV-320 (RK097221005H)
W1 8900016030 CBL OPC-1666 <TJM>
[VR2 UNIT]
REF ORDER
DESCRIPTION
NO. NO.
R1 7210003250 VAR RV-320 (RK097221005H)
W1 8900016030 CBL OPC-1666 <TJM>
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V
M.
LOCATION
B 127.7/36.8
B 127.7/34.1
B 127.7/35.9
B 127.7/33.2
T 45.7/57.9
T 91/61.3
T 121.3/152.3
T 109.4/155.1
T 119.3/144.2
T 128.6/143.6
T 126.3/144.3
T 113.9/138.9
T 108.6/147.8
B 119.3/38.5
B 119.3/37.6
B 119.3/36.7
B 117.2/36.3
B 117.2/35.1
B 119.3/34.3
B 119.3/33.4
B 119.3/32.5
B 119.3/31.6
B 127.7/35
B 41.6/14.3
T 52.6/10.4
T 45/8
T 47.5/130.7
H/V
M.
LOCATION
H/V
M.
LOCATION
S.=Surface mount
6 - 13
