4. TOOLS

CONNECT HOSE FOR TOOL USE
CAUTION
! !
Always turn off appliance before connecting or
disconnecting hose.
How to Attach
4.1 Open Accessory Hose Suction Port
Insert hose end, aligning the indicator with the
unlock arrows.
Rotate clockwise to lock position (B).
4.2 Hold open the Accessory Hose Solution Port
door (C).
Plug Accessory Hose Solution Tube connector
by inserting firmly into Hose Solution Port (C)
and rotating clockwise to lock position.
How to Remove
4.3 Disconnect Accessory Hose Solution
Connector from Accessory Hose Solution Port
by rotating counter-clockwise and pulling upward. Do
not pull on tube, this may cause damage. Accessory
port door will automatically close.
Rotate accessory Hose end counterclockwise
from the locked position to the unlocked
position and remove by pulling out.
Snap Accessory Hose Suction Port door back
into place. Make sure to snap firmly to
ensure proper suction, unit may lose suction if
not closed properly.
4.4
A B
How to Attach Tools
CAUTION
!
To reduce the risk of injury from moving parts - Unplug before connecting
Hand tool.
Not to be used for grooming pets.
4.4 To ensure maximum performance and to protect your carpet,
be sure to place the handle in the upright position while using
the accessory hose. Placing handle in the upright position
shuts off the brushes.
NOTE: All tools attach to the hose in the same manner:
4.5 Connect tool to hose by sliding it onto connector until the
tab locks it securely (E).
Using your thumb, push forward and up on the latch to
remove tool (F).
4.1
4.2
(A).
A
C
4.3
B
Tube
TOOLS
(*Available on select models only.)
A. Stair Tool*: 6 inches wide, 2 built-in rows of brushes to
help provide the scrubbing action that some spots may need for
removal on your carpeted stairs.
B. Upholstery Tool has a built-in brush to help provide the
scrubbing action some spots may need for removal.
NOTE: Tools located and stored in Mesh Storage Bag.
4.5
!
