Table Of Contents - HP QuickDock Maintenance And Service Manual

1 Product Description
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
1.2 External Components . . . . . . . . . . . . . . . . . . . . . . . . 1-4
1.3 Design Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
1.4 Using the HP Expansion Accessory Adapter . . . . . 1-19
2 Troubleshooting
3 Illustrated Parts Catalog
3.1 Serial Number Location . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 QuickDock Components . . . . . . . . . . . . . . . . . . . . . . 3-2
4 Replacement Preliminaries
4.1 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Service Considerations . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.3 Preventing Damage to Removable Drives . . . . . . . . 4-2
4.4 Preventing Electrostatic Damage . . . . . . . . . . . . . . . 4-3
4.5 Packaging and Transporting Precautions . . . . . . . . . 4-4
4.6 Workstation Precautions . . . . . . . . . . . . . . . . . . . . . . 4-5
4.7 Grounding Equipment and Methods . . . . . . . . . . . . . 4-6
Maintenance and Service Guide
Connecting to AC Power . . . . . . . . . . . . . . . . . . . . 1-11
Connecting the Computer . . . . . . . . . . . . . . . . . . . . 1-13
Contents
iii
