HP QuickDock Maintenance And Service Manual page 11

Item Component
1 Security cable slot
2 Power button
3 Audio-out (headphone)
jack
4 Audio-in (microphone)
jack
5 USB ports (2)*
*There are 4 additional USB ports on the rear of the QuickDock.
Maintenance and Service Guide
Table 1-3
Right-Side Components
Function
Attaches an optional security cable to the
QuickDock.
✎
Turns on the computer.
✎
Produces QuickDock sound when
connected to optional powered stereo
speakers, headphones, ear buds, a
headset, or television audio.
✎
Connects an optional computer headset
microphone, stereo array microphone, or
monaural microphone.
Connect optional USB devices.
The security cable is designed to
act as a deterrent, but it may not
prevent the computer from being
mishandled or stolen.
The power button on the QuickDock
has the same function as the power
button on the computer, even if the
computer display is closed.
Speakers connected to the
QuickDock are muted when a
device is connected to the
headphone jack.
Product Description
1–7
