HP UPS Network Module Configuration Menu

HP UPS Network Module Configuration Menu
overview
The HP UPS Network Module Configuration Menu provides an alternative, limited interface to the UPS
Network Module. System network values can be configured through the Configuration Menu and saved to
the UPS Network Module.
NOTE:
configured using the HP UPS Network Module web interface
interface

Accessing the Service Menu

You can access the Configuration Menu locally by launching a terminal emulation program (on page 14).
On the terminal emulation session screen running on the host computer:
Press any key. The initialization process completes, and you are prompted to enter the password.
1.
At the prompt, enter admin. The HP UPS Network Module Configuration Menu appears.
2.

Navigating the menus

After you have successfully initiated a terminal emulation session, the UPS Network Module Configuration
Menu appears.
•
Open a submenu by entering the corresponding option number at the prompt.
•
To enter or change configuration information, follow the on-screen prompts.
•
Enter 0 at the submenu prompt to go to the previous menu.
-or-
Enter 0 at the Main menu prompt to exit the utility.
•
Press the Enter key to refresh the screen.
•
You must restart the UPS Network Module to allow configuration changes to take effect.

Main menu

This menu only appears when accessing the UPS Network Module using a terminal emulation program.
Option number
1
All parameters included in the UPS Network Module Configuration Menu can also be
overview" on page 16).
Submenu
Reset
("HP UPS Network Module web
Description
Resets the UPS Network Module
HP UPS Network Module Configuration Menu 46
