WJ-C1
Extended
Mode
Quick Start
Quick Start Essential
Parameters
AA101 – Frequency (Speed) Source (default 07
Keypad [parameter FA-01])
AA111 – Run Command Source (default 02
Keypad [Run Key])
AA115 – Stop Mode Selection (default 00
[Decelerate to Stop])
Hb102 – Motor Capacity in kilowatts
Hb103 – Motor Poles (default 01 - 4 poles)
Hb104 – Base Frequency (default 60Hz)
Hb105 – Maximum Frequency (default
60Hz)
Hb106 – Motor Voltage
Hb108 – Motor Current in Amps
FA-01 – Keypad Speed Setting (default 0.00)
FA-10 – Acceleration Time (default 10 seconds)
FA-12 – Deceleration Time (default 10 seconds)

Advertisement

loading
Need help?

Need help?

Do you have a question about the WJ-C1 and is the answer not in the manual?

Questions and answers

Related Manuals for Hitachi WJ-C1

Summary of Contents for Hitachi WJ-C1

  • Page 1 Hb102 – Motor Capacity in kilowatts Hb103 – Motor Poles (default 01 - 4 poles) Hb104 – Base Frequency (default 60Hz) Hb105 – Maximum Frequency (default 60Hz) WJ-C1 Hb106 – Motor Voltage Extended Hb108 – Motor Current in Amps Mode FA-01 –...

  • Page 2: Keypad Functions

    To Enter Programming Mode and Use the C1 Keypad for To Set the Motor Data Programming The motor parameters are grouped together KEYPAD FUNCTIONS intuitively for simple programming. The keypad provides an easy to use, interactive way to access and enter the Press the Esc key to enter Programming parameters.
  • Page 3 To Set the Run To Set the Speed Reference Command Source Press the Esc key to enter Programming Press the Esc key to enter Programming Mode Mode Press the Esc until A file group is reached Press Esc until A file group is reached Rotate the jog dial until the AA101 Rotate the jog dial until the AA111 parameter parameter is displayed...
  • Page 4 To Set the Speed in Hz Using To Set the Acceleration and the Keypad Parameters Deceleration Times Press the Esc key to enter Programming Press the Esc key to enter Programming Mode Mode Press Esc until the FA-01 parameter is Press the Esc key until FA-01 is reached reached Rotate the jog dial clockwise until FA-10...

  • Page 5: Tech Support

    To Set the Stop Mode TECH SUPPORT 980-500-7141 WEBSITE www.hitachi-iesa.com/ac-drives-inverters Press the Esc key to enter Programming EMAIL Mode inverter.info@hitachi-iesa.com Press the Esc key until parameter AA101 is reached Rotate the jog dial until parameter AA115 is reached Press the enter key...
