Using the Dispenser

Your new washer has a dispenser drawer with four separate
compartments for your laundry products—two are for detergent,
one is for liquid chlorine bleach, and one is for liquid fabric
softener. Laundry products are diluted and dispensed
automatically at the proper time during the wash cycle, making it
unnecessary for you to return to the washer during the cycle to
add them.
It is normal for small amounts of water to remain in the
dispensers when the wash cycle is complete.
Do not put laundry additives directly into the wash tub. Always
use the proper dispensers when adding laundry products.
Choosing the Right Detergent
For best washing performance, use a High Efficiency (HE), or
low-sudsing, detergent.
To fill dispenser compartments
1. Pull out the dispenser drawer.
2. Add the desired laundry product to the proper compartment.
3. Push in the dispenser drawer carefully and completely (to
avoid spillage).
1
2
3
1. Prewash detergent compartment
2. Separator
3. Main Wash detergent compartment
4. Dispenser release lever
5. Bleach compartment
6. Fabric softener compartment
Prewash detergent compartment
(Number 1 in Dispenser Illustration)
Add detergent to this compartment when using the Prewash
option or Auto Soak. Liquid or powdered detergent may be used
in this compartment. The detergent will automatically be
dispensed during Prewash if the Prewash option is selected or
during the soak time if Auto Soak is selected.
Using High Efficiency (HE) detergent, add
recommended amount to the Prewash compartment and
the recommended amount to the Main Wash compartment.
4
5
6
Dispenser
the
Main Wash detergent compartment
(Number 3 in Dispenser Illustration)
Add liquid or powdered detergent to this compartment for your
main wash cycle. The detergent separator must always be in
place, either in the front or back position.
IMPORTANT: If you are using the Prewash option or the Auto
Soak with a wash cycle, powdered detergent must be used in the
Main Wash compartment since liquid detergents may seep out of
the Main Wash compartment during the prewash or soak time
before the main wash begins.
Do not fill beyond the "MAX" level.
Liquid or powdered color-safe bleach may be added to the
Main Wash compartment along with the same type of
detergent, liquid or powdered.
Liquid detergent: Put the SEPARATOR in the front position,
between the guides, as shown following. There will be no gap
between the bottom of the wash cycle detergent
compartment and the bottom of the separator.
1
2
Separator in front position, between guides
Powdered detergent: Put the SEPARATOR in the back
position, behind the guides, as shown following. There will be
a gap between the bottom of the wash cycle detergent
compartment and the bottom of the separator.
1
2
Separator in back position, behind guides
NOTE: The separator will be in the POWDER (back) position
when shipped from the factory.
LIQUI
1. Separator
2. Guide
LIQUI
1. Separator
2. Guide
SO
SO
