  • Page 1 SATURA SPOT LED PRO™ user manual    ...
  • Page 2 Elation Professional USA | 6122 S. Eastern Ave. | Los Angeles, CA. 90040 323-582-3322 | 323-832-9142 fax | www.elationlighting.com | info@elationlighting.com Elation Professional B.V.

  • Page 3: Table Of Contents

    General Guidelines Fixture Overview Fixture Installation Understanding DMX Fixture Menu EWDMX Wireless DMX Receiver Set Up DMX Channel Functions And Values Error Codes Cleaning and Maintenance Technical Specifications Optional Accessories cETLus Approval Mark SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 4: General Information

    Congratulations, you have just purchased one of the most innovative and ™ reliable lighting fixtures on the market today! The SATURA SPOT LED PRO been designed to perform reliably for years when the guidelines in this booklet are followed. Please read and understand the instructions in this manual carefully and thoroughly before attempting to operate this unit.
  • Page 5 You may also visit us on the web at www.elationlighting.com any comments or suggestions. For service related issue please contact Elation Professional®. ELATION SERVICE USA - Monday - Friday 8:00am to 5:00pm PST...

  • Page 6: Warranty

    No accessories should be shipped with the product. If any accessories are shipped with the product, Elation Professional® shall have no liability what so ever for loss of or damage to any such accessories, nor for the safe return thereof.

  • Page 7: Safety Instructions

    Do not operate this fixture if the power cord has become frayed, crimped and/or damaged. If • the power cord is damaged, replace it immediately with a new one of similar power rating. SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 8: General Guidelines

    • Use the original packaging and materials to transport the fixture in for service. DO NOT TOUCH the housing bare-hand during its operation. Turn OFF the power • and allow approximately 15 minutes for the fixture to cool down before replacing or serving. SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 9: Fixture Overview

    LEFT Button DOWN Button ENTER Button RIGHT Button MODE/ESC Button UP Button Carrying Handle(s) Wireless DMX Antenna 5pin DMX Output 5pin DMX Input 3pin DMX Output 3pin DMX Input powerCON IN Fuse SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 10: Fixture Installation

    F L A M M A B L E M A T E R I A L W A R N I N G Keep fixture at least 5.0 ft (1.5m) away from any flammable materials, decorations, pyrotechnics, etc. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 11 S A F E T Y C A B L E Always use a Safety Cable whenever installing this fixture in a suspended environment to ensure the fixture will not drop if the clamp fails. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 12 SECURING ™ Regardless of the rigging option you choose for your SATURA SPOT LED PRO always be sure to secure your fixture with a safety cable. The fixture provides a built-in rigging point for a safety cable on the hanging bracket as illustrated above. Be sure to only use the designated rigging point for the safety cable and never secure a safety cable to a carrying handle.

  • Page 13: Understanding Dmx

    1 to that fixture no matter where it is located in the DMX chain. The SATURA SPOT LED PRO™ can be controlled via DMX-512 protocol and the DMX address is set via the control menu.
  • Page 14 Connect the provided XLR cable to the female XLR output of your controller and the other side to the male XLR input of the SATURA SPOT LED PRO™ The diagram below illustrates a typical DMX-512 connection when the fixture is in the 26 Channel Extended Mode.
  • Page 15 5pin XLR connectors in to a 3pin line a cable adaptor must be used, these adaptors are readily available at most electric stores. The following chart details a proper cable conversion. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 16 That means changing the settings of one channel will only affect the selected fixture. In the case of the SATURA SPOT LED PRO™, when in the 26 Channel Extended Mode you should set the starting DMX address of the first unit to 1, the second unit to 27 (1 + 26), the third unit to 53 (27 + 26), and so on.

  • Page 17: Fixture Menu

    F I X T U R E M E N U ON-BOARD SYSTEM MENU The SATURA SPOT LED PRO™ comes with an easy to navigate system menu. The next section will detail the functions of each command in the system menu.
  • Page 18 . e l a t i o n l i g h t i n g . c o m w w w . e l a t i o n l i g h t i n g . c o m SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 19 Displays fixture run time from last power ON. The counter is reset after each time the fixture is powered OFF. INFORMATION - Time Information - Total Run Time Displays fixture total run time. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 20 5. After setting Channel 3 to the desired DMX address value, wait for approximately 20 seconds for the fixture to complete the address reset function. PERSONALITY - Status Settings - No DMX Status Define how fixture operates if NO DMX signal is detected. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 21 When ON, Control Panel buttons lock automatically after exiting main menu for 15 seconds. To unlock, keep MODE/ESC button pressed for 3 seconds. PERSONALITY – Temp C/F Define how fixture displays internal temperature (Celsius or Fahrenheit). SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 22 100%. PAN and TILT functions will still operate if the fixture needs to be positioned to a flat clear surface. With the individual functions, you can focus the light on a flat surface (wall) and perform fine adjustments. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 23 DMX-controller to the moving head. Adjust the desired scene numbers via the encoder (from – to). When you call up the scenes at your controller, they will automatically be transmitted to the moving head. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 24 • Press ENTER to confirm. • Select “Auto Program”. • Press ENTER to confirm. • Select “Master” or “Alone”. • Press ENTER to confirm. • Press MODE/ESC in order to return to the main menu. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 25 • Select “Edit Scenes”. • Select desired scene numbers. A maximum of 250 scenes can be programmed. • Press ENTER to confirm. • Press MODE/ESC in order to return to the main menu. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 26 Auto Pro Part 2 is Program 3 Auto Pro Part 3 is Program 6 The 3 Slave groups run the Auto Program in certain time segments, as shown in the following picture: SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 27: Ewdmx Wireless Dmx Receiver Set Up

    I N T E R N A L W I R E L E S S D M X R E C I E V E R ( E W D M X ) The SATURA SPOT LED PRO™ is equipped with an internal Elation Wireless DMX Receiver, which is fully compatible with an Elation Wireless DMX System.
  • Page 28 (Slow Flashing) = Paired with a EWDMX Transmitter but not receiving a DMX signal from a controller. GREEN (Solid) = Paired with a EWDMX Transmitter and receiving DMX data (Solid) = Not paired with a EWDMX Transmitter (FREE) SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 29: Dmx Channel Functions And Values

    . e l a t i o n l i g h t i n g . c o m D M X C H A N N E L F U N C T I O N S A N D V A L U E S SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 30 . e l a t i o n l i g h t i n g . c o m w w w . e l a t i o n l i g h t i n g . c o m SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 31 . e l a t i o n l i g h t i n g . c o m w w w . e l a t i o n l i g h t i n g . c o m SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 32 . e l a t i o n l i g h t i n g . c o m w w w . e l a t i o n l i g h t i n g . c o m SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 33: Error Codes

    (sensor failed or magnet is missing) or there is a motor failure (defective motor or defective motor IC drive on main PCB). This error may also be displayed if the head was blocked during a reset function. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 34 (sensor failed or magnet missing) or the stepping-motor is defective (or its driver circuit on the main PCB). The zoom motor is not located in the default position after the reset. SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 35: Cleaning And Maintenance

    Regular inspections are recommended to insure proper function and extended life. There are no user serviceable parts inside this fixture, please refer all other service issues to an authorized Elation service technician. Should you need any spare parts, please order genuine parts from your local Elation dealer.

  • Page 36: Technical Specifications

    Rigging: Clamps (Not Included) Working Position: Flat Surface / Inverted (180°) Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 37 . e l a t i o n l i g h t i n g . c o m w w w . e l a t i o n l i g h t i n g . c o m GOBOS PHOTOMETRIC DATA SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 38: Dimensional Drawings

    . e l a t i o n l i g h t i n g . c o m PHOTOMETRIC DATA (continued) DIMENSIONAL DRAWINGS Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. SATURA SPOT LED PRO™ User Manual Ver 1...
  • Page 39 . e l a t i o n l i g h t i n g . c o m CIRCUIT SCHEMATICS Please Note: Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice. SATURA SPOT LED PRO™ User Manual Ver 1...

  • Page 40: Optional Accessories

    Eloader II™ Software Updater Box EWDMXSYSTEM Wireless DMX System (1 Transmitter, 1 Receiver) AC3PDMX5PRO 5 ft. (1.5m) 3pin PRO DMX Cable (additonal lengths available) AC5PDMX5PRO 5 ft. (1.5m) 5pin PRO DMX Cable (additonal lengths available) SATURA SPOT LED PRO™ User Manual Ver 1...
