BOXLIGHT SP-5t Service Manual page 8

Electrical Parts List
Ref. No. Part No.
C1007 403 348 5803
C1009 403 157 1904
C1011 401 105 7909
C1014 403 162 4006
C1016 403 298 9609
C1017 403 162 4006
C1018 403 298 9609
C1028 403 205 7803
C1029 403 325 6304
C1031 403 325 6304
C1032 403 091 0209
C1033 403 298 9609
C1034 403 325 6304
C1036 403 091 0209
C1038 403 298 9609
C1039 403 162 4006
C1043 403 155 2200
C1044 403 298 9609
C1046 403 298 9609
C2001 403 298 9609
C2005 403 366 6202
C2008 403 366 6202
C2009TM 403 194 4609
C2011 403 157 3601
C2012 403 157 3601
C2014 403 366 6202
C2016 403 366 6202
C2021 403 157 3601
C2022 403 157 3601
C2091 403 157 3601
C2092 403 157 3601
RESISTOR
R1011 401 105 0405
R1021 401 105 0405
R1024 401 105 0504
R1026 401 203 9805
R1027 401 247 0202
R1028 401 105 0405
R1031 401 105 0603
R1032 401 105 0504
R1035 401 105 7909
R1036 401 105 0405
R1037 401 105 0405
R1043 401 105 7909
R1049 401 105 4205
R1051 401 105 2706
R1053 401 105 7909
R1054 401 211 9903
R1056 401 211 9903
R1067 401 105 7909
R1068 401 105 2706
R1071 401 105 2805
R1075 401 105 0504
R2001 401 105 4205
R2002 401 105 0405
R2003 401 113 4402
R2004 401 113 4402
R2007 401 113 4402
R2008 401 113 4402
R2011 401 113 4402
R2012 401 113 4402
R2013 401 113 4402
R2014 401 113 4402
R2016 401 113 4402
R2017 401 113 4402
R2018 401 105 5509
Description
CERAMIC 0.47U K 10V
CERAMIC 10P D 50V
MT-GLAZE 0.000 ZA 1/16W
ELECT 22U M 6.3V
CERAMIC 0.1U K 16V
ELECT 22U M 6.3V
CERAMIC 0.1U K 16V
TA-SOLID 2.2U M 16V
CERAMIC 0.22U K 10V
CERAMIC 0.22U K 10V
TA-SOLID 1U M 16V
CERAMIC 0.1U K 16V
CERAMIC 0.22U K 10V
TA-SOLID 1U M 16V
CERAMIC 0.1U K 16V
ELECT 22U M 6.3V
CERAMIC 3300P K 50V
CERAMIC 0.1U K 16V
CERAMIC 0.1U K 16V
CERAMIC 0.1U K 16V
CERAMIC 22U Z 10V
CERAMIC 22U Z 10V
ELECT 470U M 16V
CERAMIC 100P J 50V
CERAMIC 100P J 50V
CERAMIC 22U Z 10V
CERAMIC 22U Z 10V
CERAMIC 100P J 50V
CERAMIC 100P J 50V
CERAMIC 100P J 50V
CERAMIC 100P J 50V
MT-GLAZE 100 JA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 1K JA 1/16W
MT-GLAZE 2.7K FA 1/16W
MT-GLAZE 3.9K FA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 10K JA 1/16W
MT-GLAZE 1K JA 1/16W
MT-GLAZE 0.000 ZA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 0.000 ZA 1/16W
MT-GLAZE 33K JA 1/16W
MT-GLAZE 220 JA 1/16W
MT-GLAZE 0.000 ZA 1/16W
MT-GLAZE 12K FA 1/16W
MT-GLAZE 12K FA 1/16W
MT-GLAZE 0.000 ZA 1/16W
MT-GLAZE 220 JA 1/16W
MT-GLAZE 2.2K JA 1/16W
MT-GLAZE 1K JA 1/16W
MT-GLAZE 33K JA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 470K JA 1/16W
Ref. No. Part No.
R2019 401 105 0405
R2021 401 105 5509
R2022 401 105 0405
R2023 401 105 5509
R2024 401 105 0405
R2026 401 105 5509
R2027 401 105 0405
R2061 401 113 4402
R2062 401 113 4402
R2063 401 113 4402
R2064 401 113 4402
R2066 401 113 4402
R2067 401 113 4402
R2086 401 113 4402
R2087 401 113 4402
R2088 401 113 4402
R2089 401 113 4402
R2093 401 105 0702
R2094 401 105 0405
R2096 401 105 0702
R2097 401 105 0405
COIL
L1001 645 024 0669
L1002 645 024 0669
L1003 645 024 0669
L1006 645 025 0637
L1007 645 025 0637
L1017 645 014 2659
L1018 645 014 2659
L1019 645 014 2659
L1021 645 014 2659
L1022 645 014 2659
L1023 645 014 2659
L1024 645 014 2659
L2003 645 014 2659
L2004 645 002 3934
L2006 645 002 3934
L2007 645 002 3934
L2008 645 002 3934
L2009 645 002 3934
L2016 645 014 2659
L2017 645 014 2659
L2021 645 014 2659
L2022 645 014 2659
L2091 645 014 2659
L2092 645 014 2659
DIODE
D1001 407 179 0501
D1002 407 179 0501
D1003 407 179 0501
D1006 407 187 8209
D1007 407 187 8209
D1008 407 149 0807
D1009 407 149 0807
D1010 407 149 0807
D1012 407 149 0807
D1013 407 149 0807
D1014 407 149 0807
D1021 407 187 8605
D1022 407 187 8605
D1023 407 187 8605
D1024 407 187 8605
D1026 407 187 8605
D1027 407 187 8605
D1028 407 187 8605
D1029 407 187 8605
-8-
MK6-SP-5t01
Description
MT-GLAZE 100 JA 1/16W
MT-GLAZE 470K JA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 470K JA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 470K JA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 75 JA 1/16W
MT-GLAZE 100K JA 1/16W
MT-GLAZE 100 JA 1/16W
MT-GLAZE 100K JA 1/16W
MT-GLAZE 100 JA 1/16W
FILTER,EMI 20PF
FILTER,EMI 20PF
FILTER,EMI 20PF
FILTER,EMI 190PF
FILTER,EMI 190PF
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 50MHZ
FILTER,EMI 50MHZ
FILTER,EMI 50MHZ
FILTER,EMI 50MHZ
FILTER,EMI 50MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
FILTER,EMI 10MHZ
ZENER DIODE UDZ6.2B-TE-17
ZENER DIODE UDZ6.2B-TE-17
ZENER DIODE UDZ6.2B-TE-17
ZENER DIODE UDZ12B-TE-17
ZENER DIODE UDZ12B-TE-17
DIODE 1SS355-TE-17
DIODE 1SS355-TE-17
DIODE 1SS355-TE-17
DIODE 1SS355-TE-17
DIODE 1SS355-TE-17
DIODE 1SS355-TE-17
ZENER DIODE UDZ20B-TE-17
ZENER DIODE UDZ20B-TE-17
ZENER DIODE UDZ20B-TE-17
ZENER DIODE UDZ20B-TE-17
ZENER DIODE UDZ20B-TE-17
ZENER DIODE UDZ20B-TE-17
ZENER DIODE UDZ20B-TE-17
ZENER DIODE UDZ20B-TE-17
