Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
OUT OF CIRCUIT BOARD
RC Board
Temp Board
Component
Board
LCD/Prism Ass'y
FN902
Cooling Fan
Power Board
AV BOARD
SW902
Thermal switch
-5-
MK6-SP-5t01
Main Board
Filter Board
F601
Fuse
FN905
Cooling Fan
FN903
Cooling Fan
A901
Lamp Ballast
Unit
FN903
Cooling Fan
SW904
Interlock switch
FN901
Cooling Fan
