Variable Resistor - BOXLIGHT SP-5t Service Manual

Electrical Parts List
Ref. No. Part No.
R643 401 037 8005
R644 401 038 0909
R645 401 038 9308
R646 401 038 9209
!
R647 402 079 7704
R654 401 038 2002
R655 401 037 5400
R656 401 037 5608
R657 401 038 9209
R658 401 037 5103
R659 401 037 5400
R660 401 039 0304
R661 401 037 5608
R662 401 038 7700
R663 401 038 9209
R664 401 037 7909
R665 401 038 0701
R666 401 037 9309
R667 401 038 0701
R671 401 238 4400
R672 401 238 4202
R673 401 038 6406
R674 401 037 5608
R681 401 038 0800
R682 401 037 5707
TRANSFORMER
!
T651 645 042 1921
COIL
L611 645 039 9749
L615 610 031 9998
L671 645 007 8125
L683 645 007 7975
L685 645 007 7975
L687 645 007 7975
DIODE
DB611 407 202 7705
D611 407 174 2302
D612 407 191 3900
D631 407 187 8209
D632 407 190 4106
D633 407 124 6800
D634 407 125 5307
407 140 0608
D635 407 190 4106
D641 407 149 0807
D642 407 206 6308
407 179 1706
D647 407 190 4106
D651 407 202 9808
D652 407 164 2206
D653 407 190 4106
D656 407 209 4509
407 187 7806
D660 407 179 4905
D661 407 149 0807
D665 407 149 0807
MISCELLANEOUS
!
TSW611 645 026 4511
645 043 3009
FB611 610 229 3531
FB612 610 229 3531
!
PC641 408 039 3502
!
PC642 408 039 3502
!
PC643 408 039 3502
!
PC644 408 039 3502
Description
MT-GLAZE 15K JA 1/10W
MT-GLAZE 220K JA 1/10W
MT-GLAZE 68K JA 1/10W
MT-GLAZE 6.8K JA 1/10W
FUSIBLE RES 1.0 JH 1/4W
MT-GLAZE 270 JA 1/10W
MT-GLAZE 1K JA 1/10W
MT-GLAZE 10K JA 1/10W
MT-GLAZE 6.8K JA 1/10W
MT-GLAZE 10 JA 1/10W
MT-GLAZE 1K JA 1/10W
MT-GLAZE 820 JA 1/10W
MT-GLAZE 10K JA 1/10W
MT-GLAZE 5.6K JA 1/10W
MT-GLAZE 6.8K JA 1/10W
MT-GLAZE 1.5K JA 1/10W
MT-GLAZE 2.2K JA 1/10W
MT-GLAZE 18K JA 1/10W
MT-GLAZE 2.2K JA 1/10W
MT-GLAZE 2.7K JA 1/3W
MT-GLAZE 1.5K JA 1/3W
MT-GLAZE 4.7K JA 1/10W
MT-GLAZE 10K JA 1/10W
MT-GLAZE 22K JA 1/10W
MT-GLAZE 100K JA 1/10W
TRANS,POWER,PULSE
INDUCTOR,1800U
PIPE CORE
INDUCTOR,47U K
INDUCTOR,100U K
INDUCTOR,100U K
INDUCTOR,100U K
DIODE D10XB60
DIODE AK06
DIODE FML-G16S
ZENER DIODE UDZ12B-TE-17
DIODE SFPL-52V
DIODE AG01A
ZENER DIODE RD27M-T1BB
ZENER DIODE 02CZ27-TE85L
DIODE SFPL-52V
DIODE 1SS355-TE-17
ZD UDZS-TE-175.1B
ZENER DIODE UDZ5.1B-TE-17
DIODE SFPL-52V
DIODE FMB-26L
DIODE FMB-24L
DIODE SFPL-52V
ZD UDZS-TE-176.8B
ZENER DIODE UDZ6.8B-TE-17
ZENER DIODE UDZ-TE-174.7B
DIODE 1SS355-TE-17
DIODE 1SS355-TE-17
SWITCH,THERMAL
THERMOSTATS
CORE
CORE
PC TLP721F(D4-GB)
PC TLP721F(D4-GB)
PC TLP721F(D4-GB)
PC TLP721F(D4-GB)
Ref. No. Part No.
!
PTH611 408 037 5607
ASSY,PWB,HIC MK6A
TRANSISTOR
Q01 405 014 4509
Q02 405 134 5905
INTEGRATED CIRCUIT
IC01 409 483 3803
CAPACITOR
C01 403 074 9502
C02 403 075 2304
C03 403 070 2606
C04 403 030 7009
C05 403 069 5601
C06 403 073 7301
C07 403 070 2606
C08 403 074 3104
C10 403 070 2606
C11 403 070 2606
RESISTOR
R01 401 038 0800
R02 401 037 5608
R03 401 037 9507
R04 401 038 0503
R05 401 037 5004
R06 401 037 5004
R07 401 038 3504
R08 401 037 5202
R09 401 037 7909
R11 401 038 6604
R12 401 038 6505
R13 401 148 2701
R14 401 092 3304

VARIABLE RESISTOR

VR01 645 041 5333
DIODE
D01 407 004 1000
D02 407 004 1000
610 287 5249 ASSY,PWB,LINE FILTER MK6A
1AA0B10C2920B
CAPACITOR
!
C601 404 081 4702
!
C602 404 081 4702
!
C603 404 081 4702
!
C604 404 081 4702
! C606 404 073 3904
404 059 9203
RESISTOR
!
R601 401 008 8607
VARIABLE RESISTOR
!
VA601 408 018 9808
COIL
! L601 645 041 4961
!
L602 645 041 4961
MISCELLANEOUS
!
F601 423 022 2102
F601A 645 000 5077
-10-
MK6-SP-5t01
Description
THERMISTOR NTH11D8R0LC
TR 2SC2412K T146 R
TR 2SA1037AK-T146-R
IC FA5332M
CERAMIC 680P K 50V
CERAMIC 0.068U Z 50V
CERAMIC 0.1U Z 50V
CERAMIC 68P J 50V
CERAMIC 0.01U K 50V
CERAMIC 470P K 50V
CERAMIC 0.1U Z 50V
CERAMIC 0.047U Z 50V
CERAMIC 0.1U Z 50V
CERAMIC 0.1U Z 50V
MT-GLAZE 22K JA 1/10W
MT-GLAZE 10K JA 1/10W
MT-GLAZE 1.8M JA 1/10W
MT-GLAZE 22 JA 1/10W
MT-GLAZE 0.000 ZA 1/10W
MT-GLAZE 0.000 ZA 1/10W
MT-GLAZE 330 JA 1/10W
MT-GLAZE 100 JA 1/10W
MT-GLAZE 1.5K JA 1/10W
MT-GLAZE 470K JA 1/10W
MT-GLAZE 47K JA 1/10W
MT-GLAZE 1.1K FA 1/10W
MT-GLAZE 1.2K FA 1/10W
VR,SEMI,1K M
DIODE DCC010-TB
DIODE DCC010-TB
MT-POLYEST 0.22U M 275V
MT-POLYEST 0.22U M 275V
MT-POLYEST 0.22U M 275V
MT-POLYEST 0.22U M 275V
CERAMIC 1000P K 250V
CERAMIC 1000P M 400V
CARBON 220K JA 1/2W
VARISTOR ENC471D-14AS
LINE FILTER
LINE FILTER
FUSE 250V 4A
HOLDER,FUSE
