Chassis Parts - BOXLIGHT SP-5t Service Manual

Mechanical Parts List
Key No.
Part No.
CABINET PARTS
1 610 291 0193
(INcluding Key No. a to e)
a 411 025 3806
b 610 291 0186
c 610 287 6451
d 610 291 0261
e 610 285 7580
2 610 291 0599
(Including Key No. f and g)
f 411 001 9006
g 610 291 0292
3 610 287 6444
4 610 291 0254
5 610 285 7559
6 610 285 7627
7 610 286 6391
8 610 285 7634
9 610 285 7641
10 610 290 4628
11 610 287 6512

CHASSIS PARTS

21 610 285 8457
22 610 285 8464
23 610 291 2500
24 610 285 6743
25 610 285 6750
26 610 285 6767
27 610 285 6781
28 610 286 9378
29 610 285 8525
Description
COMPL,CABINET TOP-MK6E
SCR S-TPG BIN 2X4
ASSY,BUTTON P-MK6E
BUTTON-MK6B
CABINET TOP-MK6E
DEC INLAY-MK6A
COMPL,CABINET BTM A-MK6E
SCR BIN 3X8
COVER,LP-MK6E
ASSY,STAND LEG-MK6B
CABINET FRONT-MK6E
CAP LENS-MK6A
DEC AV SHEET-MK6B
DEC SHEET-MK6A
FILTER BASE L-MK6A
FILTER BASE R-MK6A
HOLDER SENSOR-MK6A
PANEL AV-MK6B
COMPL,MOUNTING INT-MK6A
COMPL,MOUNTING LENS-MK6A
HOLDER LP PWB-MP6A
HOLDER POWER PWB B-MK6A
HOLDER POWER PWB T-MK6A
HOLDER AC-MK6A
HOLDER L.F PWB B-MK6A
HOLDER L.F PWB T-MK6A
MOUNTING DUCT TOP-MK6A
Key No. Part No.
30 610 290 2082
31 610 286 8364
33 610 286 9811
34 610 287 7793
32 610 291 1039
35 610 285 1373
36 610 285 1380
37 610 291 0841
SCREWS-CABINET-
41 411 025 6500
42 411 001 9006
43 411 077 9009
SCREWS-CHASSIS-
44 412 058 5409
45 411 181 4303
46 411 025 5206
47 411 026 7704
48 411 030 5703
49 411 001 8702
50 411 001 8900
51 411 033 3003
-25-
MK6-SP-5t01
Description
MOUNTING DUCT BTM-M4GA
MOUNTING DUCT TOP BLUE-MK
SPACER SHEET*LP L-MK6A
SPACER SHEET*L.F-MK6A
SPACER SHEET*LP R-M4GAA
OPTICAL BASE BTM-MK6A
OPTICAL BASE TOP-MK6A
MOUNTING DUCT PBS-MP6A
SCR S-TPG BIN 3X8
SCR BIN 3X8
SCR TPG FLT 3X8
SPECIAL SCREW
BOLT HEX-SCT+SW+W 2.5X5
SCR S-TPG BIN 3X10
SCR S-TPG PAN 3X6
SCR BIN 2X4
SCR BIN 3X6
SCR BIN 3X8
SCR FLT 2X4
