Digital Video Camcorder Operating Instructions PV-DV203-K Model No. Mini Before attempting to connect, operate or adjust this product, please read these instructions thoroughly. For assistance, please call : 1-800-561-5505 or visit us at www.panasonic.ca LSQT0724A DV203-K.p 1-4.p65 2003/06/11, 13:29...
Things You Should Know Thank you for choosing Panasonic! Date of Purchase You have purchased one of the most Dealer Purchased From sophisticated and reliable products on the market today. Used properly, we’re sure it Dealer Address will bring you and your family years of enjoyment.
Important Safeguards 1. Read Instructions — All the safety and operating 12. Power-Cord Protection — Power-supply cords instructions should be read before the unit is should be routed so that they are not likely to be operated. walked on or pinched by items placed upon or against them, paying particular attention to cords of 2.
Important Safeguards 19. Damage Requiring Service — Unplug this video unit e. If the video unit has been dropped or the cabinet from the wall outlet and refer servicing to qualified has been damaged. service personnel under the following conditions: f.
Table of Contents Things You Should Know ....................2 Important Safeguards ..................... 3 Precautions ........................4 Before Using ........................6 • Easy Cassette Eject/Insertion ..................7 Quick Guide ........................13 Supplying Power ......................16 Setting the Clock ......................18 Using the Palmcorder Menu ..................19 Camera Recording ......................
Before Using Unpack your Palmcorder 1 pc. AC Adaptor 1 pc. 8 MB Memory Card 1 pc. Battery Pack (RP-SD008BMK0) (CGR-D08/CGR-D08R) (PV-DAC11-K) with AC Cable and DC Cable 1 pc. A/V Cable (LSJA0280) 1 pc. Lens Cap (LSYF0535) 1 pc. Shoulder Strap with Lens Cap Strap (LSFC0016) (LSGQ0066)
Before Using Record Speed/Playback Time Erase Protection Use only those tapes having the Cassettes have a sliding record tab to Mini logo indicating the 6.35 mm digital ensure recordings are not accidentally standard. erased. Record Speed/ To prevent accidental erasure: Playback time Cassette type Slide the tab to the left (open).
Before Using Attaching the Shoulder Strap Hand Strap Adjust the length of the Hand Strap to the size of your hand as illustrated. Undo the two strap ends from their buckles. Thread the strap end through the Strap Attachment Rings. •...
Before Using Before you begin Using Built-in LED Light • Connect the Palmcorder to a power To brighten the natural colours in a scene. source. (pp. 16, 17) GAIN UP works together with the LED Light • Set POWER to CAMERA or M-CARD. to enhance the light’s brightness.
Do not reverse the polarity. Insert the Battery Tray. Replace battery with Panasonic PART NO. VSBW0004 (CR2025) only. Use of another battery may present a risk of fire or explosion. Caution: Battery may explode if mistreated. Dispose of used battery properly. Keep away from children.
Page 11
Before Using Remote Controlling Two Palmcorders You can control any two Panasonic Set POWER to VCR or CAMERA. Palmcorders with one Remote Control. In order for the remote to distinguish between • The POWER Lamp lights red. the two units, it is necessary to set one of •...
Before Using Self Demo Mode Before you begin If no operation takes place for approx. • Connect the Palmcorder to a power source. (pp. 16, 17) 10 minutes after the AC Adaptor was connected to the Palmcorder and the POWER Switch was turned to CAMERA Set POWER to CAMERA.
Quick Guide Before you begin Insert the Battery Pack • Charge the Battery. (p. 16) Insert the Battery Pack and slide it up until it locks with a click. Insert Cassette These Palmcorders are equipped with the Easy Cassette Eject System so it is easy to insert or remove tapes, even when the Palmcorder is on a tripod.
Page 14
Quick Guide Camera Recording When the LCD monitor is fully open, the Viewfinder automatically turns OFF. Set POWER to Adjust the Vision Adjustment Control to your eyesight. CAMERA. Viewfinder 180° 90° LCD Monitor Press REC/PAUSE to start recording. Use OPEN tab on underside of the Press REC/PAUSE again to pause LCD monitor to unlock.
Quick Guide Before you begin Insert Memory Card* • Charge the Battery. (p. 16) *Memory Card: MultiMediaCard or SD Memory Card (p. 95) • Be sure to insert the Memory Card before using Card PhotoShot. (p. 50) Below is a list of memory cards which can be used in this Palmcorder. Memory Card Capacity SD Memory Card (RP-SD008BMK0) (supplied)
Supplying Power Charge the Battery Pack on the AC Adaptor Connect and plug in the Power Cord as shown. • POWER Lamp will light. • Remove the DC Cable, if attached, from the adaptor. POWER Lamp Attach the Battery as shown to charge.
Supplying Power Battery Care Caution: To avoid damage to the Battery: • Charge only with specified charger. • Do not drop or jar the Battery. • Charge the Battery within an ambient • Use the Battery with specified models only. temperature range of 10 °C (50 °F) and •...
Setting the Clock Before you begin Set the Date and Time • Connect the Palmcorder to a power The date and time is calculated, including source. (pp. 16, 17) leap years, up to DEC 31 2089. • Set POWER to CAMERA or VCR. 2, 3, 4 Press MENU to display the Camera or VCR mode menu screen.
Using the Palmcorder Menu The Palmcorder features three menu Displaying the MENU displays: one for CAMERA mode (recording), one for M-CARD (Memory Card Photo Mode) and one for VCR mode Press MENU to display the CAMERA (playback). (pp. 102~106) or VCR menu (according to the •...
Camera Recording Simple Recording Before you begin Remove the lens cap and clip it to the hand • Connect the Palmcorder to a power strap. source. (pp. 16, 17) • Insert a cassette with the record tab closed. (p. 7) Set POWER to CAMERA.
Camera Recording Using the LCD Monitor The LCD (Liquid Crystal Display) monitor Use OPEN tab on underside of the can be used while recording. LCD monitor to unlock. Swing the LCD monitor fully open and adjust the viewing angle. • The LCD monitor will automatically 180°...
Camera Recording Digital PhotoShot Mode Use this feature to record a seven second Set POWER to CAMERA. (approx.) still image on the tape from the current camera picture. Audio is also recorded for on-the-spot narration. Or, you Press PHOTOSHOT in Record/Pause mode.
Camera Recording Zoom You can gradually zoom in for close ups or zoom out for wide angle shots. Set POWER to CAMERA. POWER Zoom slowly: ZOOM by lightly pressing the “T” (Telephoto) or the “W” (Wide Angle) side of the POWER ZOOM.
Camera Recording Recording Check To play back the final few seconds of the Press RECORDING CHECK last recorded scene in the REC/PAUSE briefly in the REC/PAUSE mode. mode. The [CHK] indication appears. After checking, the Palmcorder returns to the REC/PAUSE mode. •...
Special Effect Features CINEMA Mode You can record a picture compatible with a Set POWER to CAMERA. wide-screen TV equipped with S-Video picture terminal and Zoom/Wide features. Press MENU to display the CAMERA 3, 4 FUNCTIONS menu screen. JOG KEY Rotate JOG KEY to select CAMERA SETUP...
Special Effect Features Program AE Set POWER to CAMERA. The Auto Exposure feature can be used to make quality recordings in a variety of Press AUTO/MANUAL so that the scene situations. “MNL” indication appears in the EVF or 4, 5 the LCD monitor.
Special Effect Features Audio/Video Fade In/Out Fade In You can make smooth* scene transitions for a more professional look. In REC/PAUSE mode, hold down 1, 3, A FADE until the picture fades out. FADE Press REC/PAUSE to start recording. Release FADE and the picture will gradually fade in.
Special Effect Features Before you begin Photo Title • Connect the Palmcorder to a power You can use PhotoShot images stored on a source. (pp. 16, 17) Memory Card to record a WIPE or MIX • Set POWER to OFF before inserting a effect on a cassette.
Advanced Settings White Balance Auto White Balance (“AWB”) automatically Set POWER to CAMERA. maintains optimum colour balance in most lighting conditions. However, when using Digital Functions, etc., you may get better Press AUTO/MANUAL so that the results by using the manual adjustment. “MNL”...
Advanced Settings Auto Focus The Palmcorder automatically adjusts the focus over the entire zoom range. Manual Focus Use Manual Focus (MF) when recording ... Set POWER to CAMERA. • a subject through glass. • a scene where the subject is far from the Palmcorder and there are objects in the Press AUTO/MANUAL so that the foreground.
Advanced Settings High Speed Shutter Use to record high speed motion (e.g. a tennis stroke) with improved STILL or SLOW MOTION playback when watching the tape on this Palmcorder. Manual Selection Set POWER to CAMERA. 3, 4 JOG KEY Press AUTO/MANUAL so that the “MNL”...
Advanced Settings Adjusting the Iris Manually Set POWER to CAMERA. Normally, the Palmcorder adjusts the exposure automatically. However, when the Press AUTO/MANUAL so that the background is extremely bright, or when the “MNL” indication appears in the EVF or subject is backlit, you can compensate by the LCD monitor.
Playback Your Recordings Playback using the LCD Before you begin Monitor • Connect the Palmcorder to a power source. (pp. 16, 17) You can also use the LCD monitor to • Insert a recorded cassette. play back your recording. Set the POWER to VCR. •...
Playback Your Recordings Repeat Playback Press PLAY for more than 5 seconds in STOP mode. • The Palmcorder will go into Repeat Playback mode when the tape PLAY reaches its end. • The letter “R ” will appear in the EVF and LCD monitor.
Special Effect Features Note • Sound is muted during all special effects. Rapid Visual Search During playback, hold down A, B (FAST FORWARD/SEARCH) or PLAY REWIND/ (REWIND/SEARCH). SEARCH The search will continue for as long as the button is held down. Press (FAST FORWARD/ SEARCH) or...
Special Effect Features Note • Sound is muted during all special effects. Slow Motion Playback (Remote Control Only) Forward Slow: Press SLOW/F.ADV during play. Reverse Slow: Press SLOW/F.ADV during play. PLAY Press PLAY to release. (During reverse slow motion playback, time SLOW/ code indication may not change F.ADV...
Special Effect Features Note • Sound is muted during all special effects. Frame by Frame Advance When using Remote Control Press PAUSE during playback. PLAY Press SLOW/F.ADV to do a frame by frame advance. Press SLOW/F.ADV to do a frame PAUSE by frame reverse.
Page 38
Special Effect Features Note • Sound is muted during all special effects. Index Search (Photo/Scene) (Remote Control Only) Press MENU to display the VCR FUNCTIONS menu screen. Search for a particular scene by using the electronic index marks placed at the Rotate JOG KEY to select beginning of each recording.
Special Effect Features Strobe Multi Mode In Strobe Multi Mode, you can select the rate at which a succession of still screens Set POWER to VCR. are captured from the playback picture. Press MENU to display the VCR 3, 4, 5 FUNCTIONS menu screen.
Page 40
Special Effect Features Before you begin View Recording/Playback on • When using S-VIDEO Connector, your TV insert the DC Cable into the DC IN Terminal. (p. 17) [ TV with AUDIO/VIDEO IN Jacks ] Set POWER to CAMERA or VCR. To view what the Palmcorder is recording or to play back a tape on your TV.
Digital Features Digital Zoom CAMERA mode This feature is useful when you want to record close-up shots of subjects located Set POWER to CAMERA. beyond a normal zoom range of 1X to 10X magnification. With the digital zooming Press MENU to display the CAMERA feature, you can select a magnification of FUNCTIONS menu screen.
Digital Features Digital Zoom (Continued) VCR mode 3, 4 Set POWER to VCR. JOG KEY Press MENU to display the VCR MENU FUNCTIONS menu screen. Rotate JOG KEY to select DIGITAL POWER EFFECT , then press JOG KEY to display the DIGITAL EFFECT menu screen.
Digital Features Dual Digital Electronic Image CAMERA mode Stabilization System (D.E.I.S.) This feature helps compensate for any Set POWER to CAMERA. unintentional hand or body movement. It can be used in both the Recording and Press EIS to stabilize the picture. Playback (VCR) modes.
Digital Features Other Digital Functions Use the following features to add interest Set POWER to CAMERA or VCR. and professionalism to your recordings or playback. Select from twelve special Press MENU to display the menu effects. screen. 3, 4, 5 Rotate JOG KEY to select DIGITAL JOG KEY...
Digital Features Picture in Picture (PinP) You can display a PinP (still image) screen Set POWER to CAMERA. on the Main Picture. Note Press MENU to display the CAMERA • PinP position is fixed at the bottom right of FUNCTIONS menu screen. the screen.
Editing Features Before you begin Audio Dubbing using the • Turn on the Palmcorder. Built-in Microphone • Insert a pre-recorded tape to be dubbed. The original sound can be replaced with new sound using the built-in Palmcorder The original sound is recorded on microphone.
Page 47
Editing Features Press (PAUSE) to start Audio Dubbing. “A.DUB ” indication 4, 5 appears. PAUSE • Connect the Palmcorder to the TV in order to monitor the sound. (p. 40) To listen to the desired audio sound, set the Only NTSC (National Television Standards 12bit AUDIO setting of the VCR mode Committee) recorded tapes can be audio MENU (Menu OSD: p.
Page 48
Editing Features Copying your Tapes to Before you begin S-VHS or VHS Cassette • Connect both Palmcorder and VCR to their power sources. • Connect the Palmcorder to a VCR as Source (Playing) illustrated on the left. Palmcorder • Turn ON both units. •...
Editing Features Copying from Digital Before you begin Equipment (dubbing) • Connect both Palmcorders to their power sources. High quality digital-to-digital copying can be • Connect the two Palmcorders using the accomplished if both Palmcorders DV Interface Cable (i.LINK) incorporate the DV Input/Output (i.LINK) (4-pin to 4-pin).
Card Features Card PhotoShot Before you begin • Connect the Palmcorder to a power You can record still images to a Memory Card. source. (pp. 16, 17) Warning • Set POWER to OFF before inserting a • When using an M-CARD, DV Output will Memory Card.
Card Features Cautions for the Memory Card • While Memory Card data is being read, do not remove it, turn off the power, or subject unit to vibrations and/or shocks. • Do not leave the Memory Card in a place with high temperature, a place exposed to direct sunlight, or a place where electromagnetic waves and static electricity can be generated.
Card Features Before you begin Playback Still Images • Set POWER to OFF before inserting a You can view the images on the Memory recorded Memory Card. (pp. 50, 51) Card. Set POWER to M-CARD. 3, 4 • “PLAY: PUSH PLAY KEY” is displayed for 10 seconds.
Card Features Before you begin Delete Specific Images • Set POWER to OFF before inserting a You can delete unwanted images and recorded Memory Card. (pp. 50, 51) increase the remaining image memory. Warning: Once deleted, images cannot be restored. Set POWER to M-CARD.
Card Features Delete All Image Pages Before you begin You can delete all images from the Memory • Set POWER to OFF before inserting a Card easily with this operation. recorded Memory Card. (pp. 50, 51) Warning: Once deleted, images cannot be restored. Do steps 1 and 2 on page 53.
Card Features Format the Memory Card Before you begin • Set POWER to OFF before inserting a You can easily format your Memory Card recorded Memory Card. (pp. 50, 51) using this operation. Warning: Formatting permanently removes all image data. Do steps 1 and 2 on page 53.
Card Features Before you begin DPOF Setting • Set POWER to OFF before inserting a You can select the images to be printed, recorded Memory Card. (pp. 50, 51) the number of prints, and other print-related information (DPOF setting) on a Memory Card.
Transferring Your Images (Windows) You can transfer images from your Palmcorder tape to your PC (Personal Computer). System Requirements (for Palmcorder USB Device Driver/PHOTOVU MPEG4 Movie Messenger System) • IBM PC/AT or compatible • Video card that supports 16 bit colour at •...
Page 58
Transferring Your Images (Windows) Software Installation (Windows 98SE/Me/2000/XP) Caution • Please install Palmcorder USB Device Driver first before connecting the Palmcorder and your PC using USB Cable. Once Palmcorder USB Device Driver is installed, you must restart your computer for installation to take effect. •...
Page 59
Palmcorder USB Device Driver/Web Camera (CAMERA Mode) [ This screen is an example (Windows 2000) ] Click “Start,” “Settings,” and “Control Panel.” Double-click on “System”, verify [Panasonic USB Video Camera] is displayed in [Imaging Devices] of [Device Manager] of [Hardware]. DV203-K.p 57-62.p65 2003/06/11, 13:30...
Page 60
Transferring Your Images (Windows) Palmcorder USB Device Driver/SD Drive, Palmcorder File Converter (M-CARD Mode) [ This screen is an example (Windows 2000) ] Click “Start,” “Settings,” and “Control Panel.” Double-click on “System”, verify [USB Storage Device Controller]* is displayed in [Universal Serial Bus controllers] of [Device Manager] of [Hardware].
PHOTOVU/MPEG4 Movie Messenger System Connection (for PHOTOVU/MPEG4 Movie Messenger System) USB Terminal USB Terminal USB Cable (supplied) Turn on your PC. Set the Palmcorder POWER to VCR. Connect the Palmcorder to your PC (Windows) using the USB Cable (supplied). • “CAPTURE” appears in the EVF or the LCD monitor. •...
Page 62
[OK] and close the dialog box. By following the steps you can disconnect the cable safely. [ This screen is an example (Windows 2000) ] Double-click the icon in the task tray. Select [Panasonic Digital Palmcorder] and click [Stop]. Verify [Panasonic Digital Palmcorder] is selected and click [OK]. Click [OK].
Page 63
Connect the Palmcorder to your PC using the USB Cable (supplied) or DV Interface Cable (i.LINK) (not supplied). (pp. 61, 62, 73) Click on “Start,” “(All) Programs,” “Panasonic,” “MPEG4 MovieMessenger System 1.01,” then “MovieMessenger.” “PHOTOVU/MPEG4 MovieMessenger System 1.01” is opened.
Page 64
PHOTOVU/MPEG4 Movie Messenger System Before you begin Using Tape Image Data (USB) • Insert a recorded tape. (p. 13) By connecting the Palmcorder and PC with • Make Palmcorder-PC connections. the USB Cable, you can transfer Motion (pp. 61, 62) images and Still images saved on the DV •...
Page 65
PHOTOVU/MPEG4 Movie Messenger System Playing back the saved Repeat steps 1~4 on page 63 to run Motion and Still images the PHOTOVU/MPEG4 Movie You can play back the saved Motion images Messenger System. and Still images (p. 64) for confirmation. Click [VideoGift] to display the VideoGift screen.
Page 66
PHOTOVU/MPEG4 Movie Messenger System VideoGift Screen You can use these features using the VideoGift Screen. Settings Slider Drag the pointer of the playback start You can open the “Compression Settings” screen. (p. 71) position. Movie Mode E-mail You can attach the compressed image You can display motion images.
Page 67
PHOTOVU/MPEG4 Movie Messenger System Using the VideoGift Screen Repeat steps 1~4 on page 63 to run the PHOTOVU/MPEG4 Movie Messenger System. Click [VideoGift] to display the VideoGift screen. • The image captured last is displayed in the VideoGift screen. Caution for Windows 2000 users •...
Page 68
PHOTOVU/MPEG4 Movie Messenger System Setting the Mail Software Repeat steps 1~4 on page 63 to run It is possible to set the mail software to start the PHOTOVU/MPEG4 Movie up automatically when [E-Mail] of VideoGift Messenger System. is clicked. Note Click [VideoGift] to display the The e-mail Software must support MAPI VideoGift screen.
Page 69
PHOTOVU/MPEG4 Movie Messenger System Attaching captured Motion and Before you begin Still images to your e-mail • Insert a recorded tape. (p. 13) • Make Palmcorder-PC connections. You can easily transfer and compress your (pp. 61, 62) Motion images as attachments to your •...
Page 70
PHOTOVU/MPEG4 Movie Messenger System Sending a Portion of a Motion Repeat steps 1~4 on page 63 to run Image the PHOTOVU/MPEG4 Movie Messenger System. Click [VideoGift] to display the VideoGift screen. • The image captured last is displayed in the VideoGift screen. Caution for Windows 2000 users •...
Page 71
PHOTOVU/MPEG4 Movie Messenger System Setting the Size and Quality of Motion and Still Image Repeat steps 1~4 on page 63 to run the PHOTOVU/MPEG4 Movie Messenger System. Click [VideoGift] to display the VideoGift screen. • The image captured last is displayed in the VideoGift screen.
Page 72
PHOTOVU/MPEG4 Movie Messenger System Selecting a Frame from a Motion Image Repeat steps 1~4 on page 63 to run the PHOTOVU/MPEG4 Movie This screen is displayed when an individual Messenger System. frame from a moving image file is to be added as a still image.
Transferring Your Images (i.LINK) (Windows) PC Connection with DV Interface Cable (i.LINK) A video clip can be transferred directly to your PC (Personal Computer) via a DV Interface Cable (i.LINK) (not supplied) using products and software from a number of video editing software companies.
PHOTOVU/MPEG4 Movie Messenger System (i.LINK) Before you begin Using Tape Image Data • Insert a recorded Tape. (p. 13) By connecting the Palmcorder and PC with • Make Palmcorder-PC connections. the DV Interface Cable (i.LINK), you can (p. 73) transfer Motion images and Still images •...
Page 75
PHOTOVU/MPEG4 Movie Messenger System (i.LINK) Normal Detail [When selecting Detail] Note • Detail mode lets you specify the start and Movie end frames for the video segment you Capture want to capture and save. Still Capture Click on [Detail]. Click on [Movie Capture] at the point where you wish to capture a Motion image.
Palmcorder USB Device Driver/SD Drive Connection (for Palmcorder USB Device Driver/SD Drive) Note • For Palmcorder USB Device Driver/SD Drive, do not connect the i.LINK and USB terminals to the Palmcorder at the same time. USB Terminal USB Terminal USB Cable (supplied) Turn on your PC.
Page 77
Palmcorder USB Device Driver/SD Drive For Windows 98SE/Me/2000 users Connect the Palmcorder to your PC (Windows) using the USB Cable (supplied). • “CONNECT WITH PC” and “STORAGE” appears in the EVF or the LCD monitor. • The “Found New Hardware” screen of Windows is displayed. Note •...
Page 78
Palmcorder USB Device Driver/SD Drive Before you begin Using Memory Card Image • Install the Palmcorder USB Device Data Driver. (p. 58) By connecting the Palmcorder and PC with • Set POWER to OFF before inserting a the USB, you can transfer Still images recorded Memory Card.
The size of images captured with the Palmcorder can be increased or decreased to make them suitable for Internet and e-mail use. • To convert format for Panasonic Digital Palmcorder: Images can be converted to JPEG format and to file names that can be played back on the Palmcorder.
Page 80
• The Conversion results screen is displayed. Use “Help” for detailed instructions. When selecting “To convert format for Panasonic Digital Palmcorder” Select the file to be converted. Select the drive to which the converted file is to be saved.
Web Camera Before Using Web Camera* Features *Web Camera MSN Messenger and NetMeeting are software that can be linked and used together. Using the Palmcorder and the Internet, you can communicate with others by having picture and sound similar in fashion to a videophone. Please read this first •...
Page 82
Web Camera Connection (for Web Camera) Note • For Web Camera, do not connect the i.LINK and USB terminals to the Palmcorder at the same time. USB Terminal USB Terminal USB Cable (supplied) Turn on your PC. Set the Palmcorder POWER to CAMERA. For Windows XP users Connect the Palmcorder to your PC (Windows) using the USB Cable (supplied).
Page 83
Web Camera For Windows 2000 users Connect the Palmcorder to your PC (Windows) using the USB Cable (supplied). • “Found New Hardware” is displayed. • “CONNECT WITH PC” and “WEBCAM” are displayed in the EVF and LCD monitor. • Position the Palmcorder so that you are in the picture. •...
Page 84
Web Camera (For Windows XP users) For Windows Messenger (Windows XP only) When Windows Messenger is newly installed or when running for the first time, the following settings become necessary. For more details, please read the corresponding Help file. Note •...
Page 85
Web Camera (For Windows XP users) Type in your e-mail address and password. • You’ll need to get a hotmail address. If you do not have one, click on [Get a .NET Passport]. Please carefully read the displayed contents and then proceed. There are times when a Version Upgrade screen will be displayed.
Page 86
Web Camera (For Windows XP users) The person calling (inviting) side Double-click a person to call from those currently [on-line]. • “xxxx-conversation” screen is displayed. The person calling (inviting) side Click [Start Camera] in the “xxx-conversation” screen. • A message inviting the other person is displayed.
Page 87
Web Camera (For Windows 98SE/Me/2000 users) For MSN Messenger Service and Windows NetMeeting (Windows 98SE/Me/2000) When MSN Messenger Service is newly installed or when running for the first time, the following settings become necessary. For more details, please read the corresponding Help file.
Page 88
Web Camera (For Windows 98SE/Me/2000 users) Click on [Audio Tuning Wizard] in the [Tools] menu. • Select [Panasonic USB Microphone]* in the [Recording] menu. * If you are using Windows 2000, select [USB Audio Device] in the [Recording] menu. Note •...
Page 89
Web Camera (For Windows 98SE/Me/2000 users) The person calling (inviting) side Click [Start NetMeeting] in the “xxx-conversation” screen. The invited person side The Instant Message screen appears and a confirmation message is displayed. Click on [Accept]. The NetMeeting screen is automatically opened.
Warning Indications Windows 2000 In Windows 2000, startup PHOTOVU/ MPEG4 Movie Messenger System. Clicking on [VideoGift] may cause the type of error to occur to the left. If so, please perform the following instructions. Download and install Media Player (7.1 or later), go to http://www.microsoft.com/windows/ mediaplayer (current as of Oct.
Transferring Your Images (Macintosh) You can transfer images from your Palmcorder Memory Card to your Macintosh. System Requirements (for Built-in SD Drive) • Mac OS 9.0~9.1 • CD-ROM drive (for installation) • iMac, iBook or Power Macintosh G3 with • USB Port USB port or Power Mac G4 •...
Transferring Your Images (Macintosh) Before you begin Using Built-in SD Drive • Set POWER to OFF before inserting a recorded Memory Card. (pp. 50, 51) Set the Palmcorder POWER to M-CARD. Connect the Palmcorder to your Macintosh using the USB Cable (supplied).
The clock battery is pre-installed. Follow the steps below if replacement becomes necessary. WARNING Replace battery with Panasonic or Newsun type CR2025 only. Use of another battery may present a risk of fire or explosion. Caution: Battery may explode if mistreated. Dispose of used battery properly. Keep away from children.
About the Memory Card (MultiMediaCard or SD Memory Card) • Model PV-DV203-K can be used with either a MultiMediaCard or a SD Memory Card. • Both of these exterior Memory Cards (MultiMediaCard and SD Memory Card) are lightweight and removable.
Specifications Power Source: Palmcorder: 7.2 V DC (Battery) 7.8 V DC (AC Adaptor) AC Adaptor: 110/120/220/240 V AC, 50/60 Hz Battery: Lithium-Ion Type DC 7.2 V Power Consumption: Palmcorder : 7.2 V/7.8 V DC 5.5 W AC Adaptor : 18 W 1 W (when not in use.) Digital Interface USB/i.LINK (IEEE1394)
If the heads are cleaned.) • If the dirty heads cannot be cleaned with the head cleaner, the Palmcorder needs to be cleaned at a Servicentre. Please consult a distributor or Panasonic Servicentre. • Video head cleaners can be purchased from Servicentres.
Page 98
Before Requesting Service Tape Operations Caution • When you go from function to function (PLAY, FF, REW etc.), please note that the unit will not accept a new function operation until the previous operation is complete. • The POWER Button and all function buttons, (PLAY, FF, REW, etc.) are only operational after the tape has been completely loaded.
On-Screen Displays (OSD) The following warning displays appear in the EVF and the LCD monitor. Indications Condition If the Palmcorder is in CAMERA mode without a cassette inserted, “ ” will flash and “TAPE NOT INSERTED” will appear for 5 seconds. Recording will not start. If the Palmcorder is in CAMERA mode or Audio dub mode with the cassette sliding record tab opened, “...
Page 100
On-Screen Displays (OSD) Indications Condition If the Palmcorder is in Photo Title (CAMERA mode) and the DV Interface Cable (i.LINK) is connected, “DISCONNECT DV CABLE” appears. In this case, remove the DV Interface Cable (i.LINK) from the Palmcorder. If you are attempting to record from a Cassette by pressing PHOTOSHOT, when the USB Cable is connected, “DISCONNECT USB CABLE”...
5770 Ambler Drive, Mississauga, Ontario L4W 2T3 PANASONIC PRODUCT – LIMITED WARRANTY Panasonic Canada Inc. warrants this product to be free from defects in material and workmanship and agrees to remedy any such defect for a period as stated below from the date of original purchase.
MENU OSD Camera Mode Menu Screen CINEMA (p. 25) When set to ON, you can record a picture compatible with a wide-screen TV equipped with S-Video picture terminal. EFFECT (p. 44) To select one of the 10 digital functions. Setting to OFF cancels the previously selected digital function.
Page 103
MENU OSD LCD/EVF SETUP (p. 21) Setting to ON displays the menu for adjusting the LCD brightness, colour level, and the EVF brightness. REMOTE (p. 11) VCR1: To receive signals from the Remote Control, set to VCR1. VCR2: To receive signals from the Remote Control, set to VCR2.
Page 104
MENU OSD VCR Mode Menu Screen BLANK SEARCH (p. 34) Select ON to go directly to a blank portion of the tape. SEARCH (p. 38) To select the desired Index Search function. PHOTO: To search for Photo shot pictures. SCENE: To search for scenes marked with Index signal.
Page 105
MENU OSD DATE/TIME (p. 107) The date and time can be set and displayed on the screen. C. DISPLAY (p. 108) To select the desired type of counter indication displayed on the LCD Monitor or in the viewfinder. C. RESET (p. 108) Setting to ON resets the counter to zero.
Page 106
MENU OSD M-CARD Mode Menu Screen [ Photo Rec Mode Menu Screen ] REC MODE (p. 50) To select Photo Rec Mode. DISPLAY (p. 110) Select to OFF to cancel all Displays on the screen. DCF NO. (pp. 52, 110) Select to OFF to cancel DCF (Design rule for Camera File system) No.
Electronic Viewfinder/LCD Monitor Indications Here are some of the basic indications which will appear on the Palmcorder EVF and LCD Monitor. Only Date and Time indications will be recorded onto the tape. CAMERA/VCR Mode Battery Remaining Date and Time Indication (Menu OSD: pp.
Page 108
Electronic Viewfinder/LCD Monitor Indications CAMERA/VCR Mode IMPORTANT NOTE: WARNING Indication (pp. 99, 100) • Display must be set to ALL for MF, AE, The warning displays appear in the W.BALANCE or BACK LIGHT indications EVF and the LCD monitor. to be displayed on the EVF or LCD Panel when selected.
Page 109
Electronic Viewfinder/LCD Monitor Indications CAMERA/VCR Mode p q r Z.MIC Indication (Menu OSD: p. 102) Zoom Magnification Level (p. 41) This display appears when ZOOM MIC is set to ON. Digital EIS Indications (p. 43) This display appears when EIS is Light Indication (p.
Page 110
Electronic Viewfinder/LCD Monitor Indications PHOTO Mode [ Photo Rec Mode ] [ Photo Play Mode ] [ Photo Play Mode ] Image Page Remaining Indication Recording Mode (p. 50) POWER is set to M-CARD. • Image pages left in selected mode. “0”...
Index of Controls Front View Lens Built-in LED Light Card Slot Door p. 9. p. 15. Remote Sensor p. 10. Built-in Twin Capsule 2-Way Microphone System Rear View POWER ZOOM pp. 23, 41. PHOTOSHOT VOLUME p. 22. p. 34. JOG KEY TAPE EJECT pp.
Index of Controls Side View Electronic LCD (Liquid Viewfinder (EVF) Crystal Display) p. 14. Monitor pp. 14, 21, 33. OPEN Built-in Speaker pp. 14, 21, 33. Rear View USB Terminal pp. 61, 76, 82. Clock Battery Tray p. 94. Card Slot DV Input/Output p.
Index of Controls Side View BACK LIGHT MAGIC PIX p. 25. p. 42. FADE LIGHT p. 27. p. 9. PLAY pp. 14, 33. pp. 14, 33. M-PLAY RECORDING CHECK pp. 52, 53. p. 24. MULTI p. 39. p. 49. p. 35. FOCUS p.
Index of Controls AC Adaptor AC Power Cord pp. 16, 17. CAUTION: POWER Lamp This unit will operate on 110/120/220/ pp. 16, 17. 240 V AC. An AC plug adaptor may be required for voltages other than 120 V AC. Please contact either a local or foreign electrical parts distributor for assistance in selecting an alternate AC plug.
Index About the Memory Card ..95 Fast Forward/Rewind Check Rapid Visual Search ... 35 AC Adaptor ..6, 16, 17, 93 Recording Check ....24 ..........35 Accessories (Optional) ..93 Focus ........30 Recording Images From a Accessories (Supplied) ..6 Format the Memory Card ...
Page 116
