Kobalt K20LC-26A User Manual

20-volt circular saw
Hide thumbs

Advertisement

®
KOBALT
and the K Design
trademarks of LF, LLC. All Rights Reserved.
aTTaCH YOur rECEiPT HErE
Serial Number _______________ Purchase Date _______________
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-888-3KOBALT (1-800-356-2258), 8 a.m. - 8 p.m., EST, Monday - Friday.
AB12440
®
are registered
ITEM #0437514
20-VOLT

CirCuLar Saw

MODEL #K20LC-26A
Français p. 19
Español p. 39
kobalttools.com

Advertisement

loading

  Related Manuals for Kobalt K20LC-26A

  Summary of Contents for Kobalt K20LC-26A

  • Page 1: Circular Saw

    CirCuLar Saw ® ® KOBALT and the K Design are registered MODEL #K20LC-26A trademarks of LF, LLC. All Rights Reserved. Français p. 19 Español p. 39 aTTaCH YOur rECEiPT HErE Serial Number _______________ Purchase Date _______________ Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-888-3KOBALT (1-800-356-2258), 8 a.m.
  • Page 2: Table Of Contents

    TaBLE OF CONTENTS Product Specifications ............. . 2 Safety Information .
  • Page 3 SaFETY iNFOrmaTiON Know the Tool To operate this tool, carefully read this manual and all labels affixed to the circular saw before using it. Keep this manual available for future reference. important This tool should be serviced only by a qualified service technician. read all instructions Thoroughly General Safety rules For all Power Tools warNiNG: Read all safety warnings and all instructions.
  • Page 4: Safety Information

    SaFETY iNFOrmaTiON Personal Safety • Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. • Use personal protective equipment. Always wear eye protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection, used for appropriate conditions, will reduce personal injuries.
  • Page 5 SaFETY iNFOrmaTiON Battery Tool use and Care • Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. • Use power tools only with specifically designated battery packs. Use of any other battery packs may create a risk of injury and fire. • When a battery pack is not in use, keep it away from other metal objects, such as paper clips, coins, keys, nails, screws or other small metal objects that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire.
  • Page 6 SaFETY iNFOrmaTiON Further Safety instructions For all Saws Cause and operator prevention of kickback: — Kickback is a sudden reaction to a pinched, bound or misaligned saw blade, causing an uncontrolled saw to lift up and out of the workpiece toward the operator. —...
  • Page 7: Preparation

    SaFETY iNFOrmaTiON • The lower guard should be retracted manually only for special cuts, such as “plunge cuts” and “compound cuts.” Raise the lower guard with the retracting handle and, as soon as blade enters the material, the lower guard must be released. For all other sawing, the lower guard should be allowed to operate automatically. • Always observe that the lower guard is covering the blade before placing the saw down on the bench or floor. An unprotected, coasting blade will cause the saw to walk backwards, cutting whatever is in its path. Be aware of the time it takes for the blade to stop after switch is released. additional Safety rules For Circular Saws a.
  • Page 8 PaCKaGE CONTENTS...
  • Page 9 ParT DESCriPTiON Trigger switch Motor housing Main handle Auxiliary handle Bevel locking knob 0° - 50° bevel scale Edge-guide locking knob Blade-guard lever Lower blade guard Base plate Upper blade guard Dust-extraction port Depth-locking lever Depth scale Spindle-lock button Blade Blade bolt Blade outer flange Lock-off button...
  • Page 10 OPEraTiNG iNSTruCTiONS 1. Variable-Speed Trigger Switch Your saw is equipped with a trigger switch (A) to turn the saw on and off, and to control the speed. a. To start the saw, depress the lock-off button (S) and then squeeze the trigger switch. b.
  • Page 11: Operating Instructions

    OPEraTiNG iNSTruCTiONS 3. Installing a Saw Blade a. Remove the battery pack from the saw. b. Depress and hold the spindle-lock button (O). c. While keeping the spindle-lock button depressed, remove the blade bolt (Q) by turning it clockwise with the blade wrench (included). d.
  • Page 12 OPEraTiNG iNSTruCTiONS 4. Blade Guard System The lower blade guard (I) on the circular saw is there for the operator’s protection and safety. Do not alter it for any reason. If the lower blade guard becomes damaged or if the blade begins to run slowly or sluggishly, DO NOT operate the saw until the damaged part has been repaired or replaced.
  • Page 13 OPEraTiNG iNSTruCTiONS 6. Depth-Of-Cut Adjustment warNiNG: Always maintain the correct blade- depth setting. The correct blade-depth setting for all cuts should not exceed the thickness of the material being cut by more than 1/4 in. (6.5 mm). Greater blade depth will increase the chance of kickback, and cause the cut to be rough.
  • Page 14 OPEraTiNG iNSTruCTiONS 8. Cutting With the Circular Saw (8a – 8c) Refer to the figures in this section to learn the correct and incorrect ways of handling the saw. warNiNG: To make sawing easier and safer, always maintain proper control of the saw. Loss of control could cause an accident resulting in serious injury. DaNGEr: When lifting the saw from the workpiece, the blade is exposed on the underside of the saw until the lower blade guard closes.
  • Page 15 OPEraTiNG iNSTruCTiONS 9. Rip Cutting/Cross-Cutting When making a cross-cut or a rip cut, align the guideline with the blade-guide notch (T) on the base, as shown in Fig. 9. The distance from the saw blade to the saw base is approximately 1-1/2 in. (3.8 cm) on the left side of the saw and 4-1/4 in.
  • Page 16 OPEraTiNG iNSTruCTiONS 11. Bevel Cutting To make the best possible cut: a. Align the cutting line with the blade-guide notch (T) on the base when making 45° bevel cuts. b. Make a trial cut in scrap material along a guideline to determine the amount to offset the guideline on the cutting material.
  • Page 17 OPEraTiNG iNSTruCTiONS 12. Pocket Cutting warNiNG: Always adjust the bevel setting to 0° before making a pocket cut. Attempting a pocket cut at any other setting can result in loss of control of the saw and possible serious injury. a. Adjust the bevel setting to 0° and tighten the bevel locking knob.
  • Page 18: Care And Maintenance

    This warranty excludes blades, bits, bulbs and accessories. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state. Printed in China Kobalt ® & K Design ® are registered trademarks of LF, LLC.
