Configuration
Thereafter, you will be prompted to enter your user name and your
password
(default: user: admin, pass: ctr).
The welcoming text of the embedded web server will appear. Now you
can proceed with Section 4.3.1.

4.2.2 Configuring via a null-modem cable

Prerequisites:
A PC with web browser and a free 9-pin serial interface, as well as a
zero-modem cable are required. Connect the zero-modem cable to the
free serial connection on the PC side, and to the RS 232 jack labelled
"External" on the router side.
It is not relevant whether MS Windows or Linux is installed on your PC,
because both operating systems include the required tools.
The method described here pertains to Windows 2000.
NOTE
Now go to Control Panel Network Connections and start the
"New Connection Wizard".
Choose "Connect directly to another computer" for the type of
connection:
4-23
