Page 1 V10.1.00...
Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4 Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 6: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 7: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 8: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 9 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 10: Power Safety
Preface Power Safety The computer has specific power requirements: •Only use a power adapter approved for use with this computer.  •Your AC/DC adapter may be designed for international travel but it still requires a steady, uninterrupted power supply. If you are unsure of your local power specifications, consult Power Safety Warning your service representative or local power company.
Page 11: Polymer Battery Precautions
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Page 12: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 13: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 14: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 15 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 16 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 17: Lcd Screen Care
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 18 Preface...
Page 19: Table Of Contents
Preface Contents Notice .................I Keyboard ................1-9 FCC Statement ..............III Function/Hot Key Indicators ........1-10 FCC RF Radiation Exposure Statement: ......IV System Map: Front & Left Views ........1-11 Instructions for Care and Operation ....... VI System Map: Right & Rear Views ......1-12 Power Safety ..............
Page 20 Preface Finger Sensing Pad Configurator .........2-14 Battery Power ..............3-11 Gestures ...............2-15 Conserving Battery Power ...........3-12 Audio Features .............2-16 Battery Life ..............3-13 VIA HD Audio Deck ...........2-17 New Battery ..............3-13 Realtek HD Audio Manager ........2-19 Recharging the Battery with the AC/DC Adapter ..3-13 Optimizing Audio Recording ........2-20 Proper handling of the Battery Pack ......3-14 Adding a Printer ............2-21...
Page 21 Preface Audio ................4-7 Advanced Menu .............5-8 Windows Experience Index ...........4-8 Advanced Chipset Control (Advanced Menu) ....5-8 Optional Drivers ............4-9 Installed O/S (Advanced Menu) ........5-9 Wireless LAN Module ...........4-9 SATA Mode Selection (Advanced Menu) .....5-9 MEI Driver ..............4-9 DFOROM (Robson) Support (Advanced Menu > 3.75G/HSPA Module .............4-9 SATA Mode Selection) ..........5-9 PC Camera Module ............4-10...
Page 22 Preface Upgrading the Optical (CD/DVD) Device ....6-7 Statistics & Information ..........7-49 Upgrading the System Memory (RAM) ......6-9 PC Camera Module ............7-50 Changing the Optional LCD Back Covers ....6-12 PC Camera Driver Installation ........7-51 Bluetooth Module ............7-58 Modules & Options Bluetooth Combo Driver Installation ......7-59 Bluetooth &...
Page 23 Preface Video ................B-1 Communication ............. C-4 Dynamic Video Memory Technology ...... B-1 Communication (Cont’d) ..........C-4 Power Management ............C-4 Intel GMA Driver for Mobile ........B-2 Power ................C-4 Scheme Options ............B-4 Security ................. C-4 Display Devices & Options ........B-5 Operating System ............
Page 24 Preface XXII...
Page 25: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 26: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 27: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Page 28: System Startup
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 29: Model Differences
Quick Start Guide Model Differences This notebook series includes different models that vary slightly in LCD type, design style, color and general appearance. Note that though your computer may look slightly different from that pictured throughout this man- ual. Changeable LCD Back Covers Note that this computer series includes some model designs with specially designed changeable LCD back cover options.
Page 30: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open  Built-In PC Camera (Optional) Wireless Device Operation Aboard Power Button Aircraft Hot Key Buttons LED Status The use of any portable elec- Indicators (see tronic transmission devices aboard aircraft is usually pro- Table 1 - 2, on...
Page 31: Led Indicators
Quick Start Guide LED Indicators Icon Color Description The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Scroll Lock Activated (to activate Green press Fn & Scr Lk) Green Caps Lock Activated Orange DC Power is Plugged In Green...
Page 32: Hot Key Buttons & Keyboard
Quick Start Guide Hot Key Buttons & Keyboard These buttons give instant access to the default Internet browser and e-mail program, and allow you to toggle the Silent Mode on/off with one quick button press. Hot Key Function Toggle *Silent Mode (for power saving) Activate the Default Internet Program Activate the Default E-Mail Browser (Note that in Windows 7 without Outlook/Outlook Express installed this button has no function.
Page 33: Keyboard
Quick Start Guide Keyboard  The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 4, on page 1 - 10 for full function key combination details.
Page 34: Function/Hot Key Indicators
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Keys Function Keys...
Page 35: System Map: Front & Left Views
Quick Start Guide System Map: Front & Left Views Figure 1 - 4 Front & Left Views LED Power Indica- tors (see Table 1 - 1, on page 1 - DC-In Jack External Monitor Port RJ-45 LAN Jack HDMI-Out Port 2 * USB 2.0 Ports ...
Page 36: System Map: Right & Rear Views
Quick Start Guide System Map: Right & Rear Views Figure 1 - 5 Right & Rear Views Microphone-In Jack Headphone-Out Jack USB 2.0 Port *Modem Port (Optional) Optical Device Drive Bay (for CD/ DVD Device) Security Lock Slot Battery * Note the Modem is a factory option for certain computer models in this series only.
Page 37 Quick Start Guide   Changing DVD Regional Codes Disk Eject Warning Go to the Control Panel and double-click Device Don’t try to eject a CD/DVD while the system is ac- Manager (Hardware and Sound), then click the + cessing it. This may cause the system to “crash”. Stop next to DVD/CD-ROM drives.
Page 38: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 6 Bottom View  Battery Component Bay Battery Information Cover Always completely dis- Vent/Fan Intake/ charge, then fully charge, a Outlet new battery before using it. Hard Disk Bay Completely discharge and Cover charge the battery at least 3.75G USIM Card...
Page 39 Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 40: Video Features
Quick Start Guide Video Features You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For more detailed video information see Appendix To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel. Click Display (icon) - In the Appearances and Personalization category.
Page 41 Quick Start Guide Figure 1 - 8 - Screen Resolution & Intel GMA Driver for Mobile Video Features 1 - 17...
Page 42: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 15) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 43: Mofa Lcd Back Covers
Quick Start Guide MOFA LCD Back Covers MOFA (Magic of Film Art) technology allows fashionable and unique pictorial designs to be printed on the spe- cially designed changeable LCD back covers. If your purchase option includes the specially designed change- able LCD back cover option, then follow the instructions in “Changing the Optional LCD Back Covers”...
Page 44 Quick Start Guide 1 - 20...
Page 45: Features & Components
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • Multi-in-1 Card Reader • ExpressCard Slot - Optional •...
Page 46: Hard Disk Drive
Features & Components Hard Disk Drive  The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other serial (SATA) hard disk drives (see “Storage” on page C - 3 for specification information).
Page 47: Optical (Cd/Dvd) Device
Features & Components Optical (CD/DVD) Device  There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...
Page 48: Handling Cds Or Dvds
Features & Components Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Page 49: Dvd Regional Codes
Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Page 50: Multi-In-1 Card Reader
Features & Components Multi-in-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 51: Expresscard Slot - Optional
Features & Components ExpressCard Slot - Optional  The computer is equipped with an (optional) ExpressCard 34 slot that reads Ex- ExpressCard press Card/34 formats. ExpressCards are the successors to PCMCIA (PC Cards). Slot Cover Make sure you install the Card Reader driver (see “CardReader”...
Page 52: Touchpad And Buttons/Mouse
Features & Components TouchPad and Buttons/Mouse  The TouchPad is an alternative to the mouse; however, you can also add a mouse to TouchPad Scrolling your computer through one of the USB ports. The TouchPad buttons function in This computer model se- much the same way as a two-button mouse.
Page 53: Synaptics Driver
Features & Components Synaptics Driver  Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 7) you can configure the functions by double-clicking the TouchPad driver icon in the Mouse Driver taskbar. You may then configure the TouchPad tapping, buttons, scrolling, pointer If you are using an ex- motion and sensitivity options to your preferences.
Page 54: Gestures And Device Settings
Features & Components Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- Show Video tion) on the surface of the TouchPad to perform specific actions to manipulate doc- uments, objects and applications. You can get a clearer view of the gestures in- volved by clicking the...
Page 55 Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the TouchPad surface and slide both fingers in the direction required (in a straight con- tinuous motion).
Page 56 Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the TouchPad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Page 57: Sentelic Driver
Features & Components Sentelic Driver  Once you have installed the TouchPad driver (see “TouchPad” on page 4 - 7) you can configure the functions by double-clicking the TouchPad driver icon in the Mouse Driver taskbar. You may then configure the buttons, pointers and finger-sensing pad op- If you are using an ex- tions to your preferences.
Page 58: Finger Sensing Pad Configurator
Features & Components Finger Sensing Pad Configurator The Finger Sensing Pad Configurator allows you to use a configure the settings for the Finger Pad device and software. The left pane in the control panel contains all the configurable items, and you can click the “+” to expand the menu selections. You can configure the settings from the Device Settings tab in Mouse Properties: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 59: Gestures
Features & Components Gestures  Click Gestures and make sure that the Enable Gestures tickbox is clicked. Double- click Gestures and then double-click Advanced to open the submenu. You can con- Play Video figure any of the gestures from this submenu. You can get a clearer view of the gestures in- volved by clicking the...
Page 60: Audio Features
Features & Components Audio Features This computer will feature one of two possible audio systems depending on your purchase configuration. See the appropriate following pages for audio control panel information. 2 - 16 Audio Features...
Page 61: Via Hd Audio Deck
Features & Components VIA HD Audio Deck  You can configure the audio options on your computer from the Sound control panel in Windows, from the HD VDeck icon on the desktop or VIA HD Audio Sound Volume Deck control panel Adjustment The sound volume level The volume may also be adjusted by means of the Fn + F5/F6 key combination.
Page 62 Features & Components Expert Mode will allow you to access more advanced configuration menus. Figure 2 - 15 VIA HD Audio Deck (Expert Mode) “HDMI Audio Configuration” on page B - 12 for more information on the au- dio settings for HDMI. 2 - 18 Audio Features...
Page 63: Realtek Hd Audio Manager
Features & Components Realtek HD Audio Manager  You can configure the audio options on your computer from the Sound control panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Sound Volume control panel (right-click the taskbar icon to bring up an audio menu).
Page 64: Optimizing Audio Recording
Features & Components Optimizing Audio Recording Follow these instructions to optimize your audio recording. Double-click the taskbar icon to bring up the Realtek HD Audio Manager. Click the Microphone tab. Click the Noise Suppression button to prevent any background noise or feedback.
Page 65: Adding A Printer
Features & Components Adding a Printer  The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- USB Printer...
Page 66 Features & Components 2 - 22...
Page 67: Power Management
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 68: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the left of the computer.
Page 69: Turning On The Computer
Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 70: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 71 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 72: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Page 73: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 74: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Page 75: Resuming Operation
Power Management Resuming Operation  You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color...
Page 76: Energy Star Power Saving
Power Management Energy Star Power Saving  This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Taskbar Icon of inactivity. If you want to enable Energy Star power saving then follow these in- If the taskbar icon does structions: not appear then click the...
Page 77: Battery Information
Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Page 78: Conserving Battery Power
Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Wireless Hot Keys • Lower the brightness level of the LCD display. The system will decrease LCD The computer’s wireless brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 79: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 80: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 81: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 82 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 83 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 84 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 85: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the lat- est versions of most available operating systems haven’t built in drivers and utilities.
Page 86: Windows 7 Driver Installation
Drivers & Utilities Windows 7 Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers/Option Drivers (button). Figure 4 - 1 - Drivers Installer Screen 1 Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu below.
Page 87 Drivers & Utilities Driver for Win 7 Page # Chipset Page 4 - 6 Video (VGA) Page 4 - 6 Modem (optional) Page 4 - 6 Page 4 - 7 CardReader Page 4 - 7 TouchPad Page 4 - 7 Hot Key Page 4 - 7 Audio...
Page 88: Updating/Reinstalling Individual Drivers
Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click Browse CD/DVD (button) in the Drivers Install- If you wish to update/reinstall individual drivers it er application and browse to the executable file in the may be necessary to uninstall the original driver.To do appropriate driver folder.
Page 89: User Account Control
Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue or ing the installation procedure (other than when out- Allow, and follow the installation procedure as direct- lined in the driver install procedure), click Cancel to close the window, and follow the installation proce-...
Page 90: Driver Installation Procedure
Drivers & Utilities Driver Installation Procedure Modem Insert the Device Drivers & Utilities + User’s Manual Optional 1. Click 3.Install Modem Driver > Yes. disc and click Install Drivers (button). 2. Click OK. Chipset 3. The modem is ready for dial-up configuration. 1.
Page 91: Lan
Drivers & Utilities Hot Key 1. Click 4.Install LAN Driver > Yes. 1. Click 7.Install Hotkey Utility > Yes. 2. Click Install. 2. Click Next > Next. 3. Click Finish. 3. Click Finish > Finish to restart the computer. CardReader Audio 1.
Page 92: Windows Experience Index
Drivers & Utilities Windows Experience Index After the drivers are installed follow this procedure to  ensure an accurate rating from the Windows Experi- Windows Update ence Index (make sure the AC/DC adapter is plugged After installing all the drivers make sure you enable Windows in): Update in order to get all the latest security updates etc.
Page 93: Optional Drivers
Drivers & Utilities Optional Drivers Wireless LAN Module See the pages indicated for the driver installation pro- See the introduction in “Wireless LAN Module” on cedures for any modules included in your purchase op- page 7 - 2, and check the installation procedure. tion.
Page 94: Pc Camera Module
Drivers & Utilities PC Camera Module See the introduction in “PC Camera Module” on page 7 - 50, and check the installation procedure. Bluetooth Module A driver is only required for the Combination Wireless LAN & V3.0 Bluetooth. See “Bluetooth Combo Driver Installation”...
Page 95: Bios Utilities
BIOS Utilities Chapter 5: BIOS Utilities  Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s Configuration: The Phoenix SecureCore(tm) Setup Utility BIOS.
Page 96: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST)  When the Boot-time Diagnostic Screen is enabled (see page 9), each time you POST Screen turn on the computer, the system takes a few seconds to conduct a POST, including a quick test of the on-board RAM (memory). 1.BIOS information 2.CPU type As the POST proceeds, the computer will tell you if there is anything wrong.
Page 97: Failing The Post
BIOS Utilities Failing the POST  Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. BIOS Settings Warning Fatal Errors Incorrect settings can These stop the boot process and usually indicate there is something seriously wrong cause your system to with your system.
Page 98: The Setup Utility
BIOS Utilities The Setup Utility The Phoenix SecureCore(tm) Setup Utility tells the system how to configure itself and manage basic features and subsystems (e.g. port configuration). Entering Setup To enter Setup, turn on the computer and press F2 during the POST. The prompt (Press F2 to Enter Setup) seen on page 5 - 2 is usually present for a few seconds...
Page 99: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 100: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 101: Sata Port 1/2/4 (Main Menu)
BIOS Utilities SATA Port 1/2/4 (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Port 1/2/4. Use the Auto (Type:) setting to have the items configured automatically for you. System/Extended Memory (Main Menu) This item contains information on the system memory, and is not user configurable.
Page 102: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) Pressing Enter here will access the sub-menu that allows you to enable/disable the automatic detection (Detect External CRT) of any attached display (this can be dis- abled for power saving purposes).
Page 103: Installed O/S (Advanced Menu)
BIOS Utilities Installed O/S (Advanced Menu)  This setting tells the computer what kind of operating system you’re using. Make sure you choose the correct setting for your O/S in order to prevent system problems. SATA Mode Selection SATA Mode Selection (Advanced Menu) If you have installed the If you have selected Vista / Win 7 as you installed OS you can configure SATA (Se- Windows Vista/ Win-...
Page 104: Legacy Os Boot: (Advanced Menu)
BIOS Utilities Legacy OS Boot: (Advanced Menu) Enable this item to support only system boot from the Legacy OS (e.g Windows Vis- ta). If disabled the system will attempt to boot from the EFI (Extensible Firmware Interface) before the Legacy OS. Reset Configuration Data (Advanced Menu) This item is set to No as default.
Page 105: Security Menu
BIOS Utilities Security Menu  Security Menu changes make here affect the access to the Setup utility itself, and also access to your ma- chine as it boots up af- ter you turn it on. These settings do not affect your machine or network passwords which will be set in...
Page 106: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu)  You can set a password for user mode access to the Phoenix SecureCore(tm) Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless Password Warning you choose to set a Password on Boot (see below). Many menu items in the Phoenix If you set a boot pass- SecureCore(tm) Setup Utility cannot be modified in user mode.
Page 107: Boot Menu
BIOS Utilities Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual screens appear slightly different from...
Page 108: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Set- up defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 109: Upgrading The Computer
Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.
Page 110: When Not To Upgrade
Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Page 111: Removing The Battery
Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.
Page 112: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive  The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3).
Page 113 Upgrading The Computer Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and loosen screws & Remove the hard disk bay cover Figure 6 - 2 Hard Disk Bay Cover Removal Upgrading the Hard Disk Drive 6 - 5...
Page 114 Upgrading The Computer Grip the tab and slide the hard disk in the direction of arrow  Lift the hard disk out of the bay Remove the screw(s) and the adhesive cover Hard Disk Screws & Reverse the process to install a new hard disk drive (do not forget to replace all the Cover screws and covers) The hard disks and cov-...
Page 115: Upgrading The Optical (Cd/Dvd) Device
Upgrading The Computer Upgrading the Optical (CD/DVD) Device  Turn off the computer, and turn it over and remove the battery. Fan Cable & Cover Locate the component bay cover and remove screws Carefully (a fan and cable are attached to the under side of the cover) lift up Make sure you recon- the bay cover.
Page 116 Upgrading The Computer Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device. Figure 6 - 5 Removing the Optical Device 6 - 8 Upgrading the Optical (CD/DVD) Device...
Page 117: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM)  The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- Fan Cable & Cover DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page C - 3 details of supported module types).
Page 118 Upgrading The Computer Gently pull the two release latches on the sides of the memory socket in the direction indicated by the arrows ( & Figure 6 - Figure 6 - 7 RAM Module Release Latches The RAM module will pop-up, and you can remove it.
Page 119 Upgrading The Computer Pull the latches to release the second module if necessary.  Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. The module’s pin alignment will allow it to only fit one way. Make sure the module Cover Pins is seated as far into the slot as it will go.
Page 120: Changing The Optional Lcd Back Covers
Upgrading The Computer Changing the Optional LCD Back Covers  If your purchase option includes the specially designed LCD back cover option, then Rubber Screw follow the instructions below to change the covers (note these covers are not appli- Covers cable to all models in this series - consult your service center for details).
Page 121 Upgrading The Computer Carefully slide the cover forward in the direction of the arrows & illustrated below Figure 6 - 11 Slide the Cover Forward Remove the LCD back cover Figure 6 - 12 Remove the LCD Back Cover Changing the Optional LCD Back Covers 6 - 13...
Page 122 Upgrading The Computer Align the replacement cover with the dotted line as illustrated below (and as marked on the cover). Figure 6 - 13 Replacing the LCD Back Cover Slide the cover forward until it clicks firmly into place Run your hands around the sides and front of the cover to make sure it is firmly aligned in place (carefully press down to make sure the fit is secure).
Page 123: Modules & Options
Modules & Options Chapter 7: Modules & Options  Overview Wireless Device Operation Aboard This chapter contains information on the following modules, which may come with Aircraft your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Page 124: Wireless Lan Module
Modules & Options Wireless LAN Module  If you have included an Intel® Wi-Fi Link Series or 3rd Party 802.11b/g/n WLAN Wireless Device module in your purchase option, make sure that the Wireless LAN module is on be- Operation Aboard fore installing the driver.
Page 125: 802.11B/G/N Driver Installation
Modules & Options 802.11b/g/n Driver Installation 1. Make sure the module is powered on, then insert the Device Drivers & Util- ities + User’s Manual disc into the CD/DVD drive. 2. Click Option Drivers (button). 3. Click 1.Install WLAN Driver > Yes. 4.
Page 126: Connecting To A Wireless Network In Windows 7
Modules & Options Connecting to a Wireless Network in Windows 7  Make sure the Wireless LAN module is turned on. Network and Click the taskbar wireless icon , and then double-click an access point to con- Sharing Center nect to or click to Open Network and Sharing Center if you do not see a network you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net- setting changes, and creating a new network).
Page 127 Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 128 Modules & Options Click the taskbar icon to see any currently connected networks.  To disconnect from the wireless network you can click the taskbar wireless icon click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se- cure network.
Page 129: Intel My Wifi Configuration
Modules & Options Intel My WiFi Configuration ®  Intel® My WiFi Technology uses your WLAN (for Intel WLAN modules only) module to allow you to connect up to eight other WiFi enabled devices (e.g. digital Intel® My WiFi Help cameras, other computers, cell phones, handheld devices etc.) to your computer To get help on Intel®...
Page 130 Modules & Options Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the taskbar icon Click Enable (on the first run of the program there will be no connected...
Page 131 Modules & Options Click Start and click Control Panel. Click Network and Sharing Center (Network and Internet). Click Change adapter settings. Figure 7 - 5 Network and Sharing Center Click Change adapter settings Wireless LAN Module 7 - 9...
Page 132 Modules & Options Right-click Wireless Network Connection and select Properties. Figure 7 - 6 Network Connections Right-click Wireless Network Connection and select Proper- ties. 7 - 10 Wireless LAN Module...
Page 133 Modules & Options Click Sharing (tab) and select “Allow other network users to connect through this computer’s Internet connection”. Select Wireless Network Connection under Home networking connection. Click OK. Click “Allow other network users to connect through this computer’s Internet connection”.
Page 134 Modules & Options 10. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the taskbar icon 11. Click Profiles Figure 7 - 8 Intel®...
Page 135 Modules & Options 12. Click Profiles, click Intel Wireless PAN and click Edit or New (Note that all preset settings may not be editable - see sidebar). Figure 7 - 9 Profiles  Profile Settings Profiles that are preset may not be fully edit- 13.
Page 136 Modules & Options 14. Click Security (tab). 15. Change the Security Type to WEP and the Encryption Type to 64bit. 16. Enter a password (8 characters long) in the Password box. Figure 7 - 11 Intel® My WiFi Profile Settings - Security 7 - 14 Wireless LAN Module...
Page 137 Modules & Options 17. Click Sharing (tab). 18. It is recommended that the Filter Network Traffic and DHCP and DNS Server are Disabled. Figure 7 - 12 Intel® My WiFi Profile Settings - Sharing Wireless LAN Module 7 - 15...
Page 138 Modules & Options 19. Click Advanced (tab). 20. It is recommended that the Default Channel is set to Channel 1, 6 or 11. 21. Click OK to save the settings. Figure 7 - 13 Intel® My WiFi Profile Settings - Advanced 7 - 16 Wireless LAN Module...
Page 139 Modules & Options 22. Double-click Wireless Network Connection in Network Connections. 23. Click Details to display the Network Connection Details. Figure 7 - 14 Wireless Network Connection Details Wireless LAN Module 7 - 17...
Page 140 Modules & Options 24. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon 25. To add a new device follow the instructions in the devices’ user guide for connecting to a WiFi network.
Page 141: Windows Mobility Center
Modules & Options Windows Mobility Center  The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. Wireless Hot Keys To access the Windows Mobility Center: The computer’s wireless function keys will not func- Click Start, and click Control Panel (or point to Settings and click Control...
Page 142: G/Hspa Module
Modules & Options 3.75G/HSPA Module  If you have included an optional 3.75G/HSPA (High Speed Packet Access) module 3.75G/HSPA Module (see “Communication” on page C - 4 for specification details) in your purchase op- tion, you will have the appropriate application (Mobile Partner or BandLuxe HS- Options DPA Utility) provided for your particular module.
Page 143 Modules & Options Turn off the computer, and turn it over and remove the battery (see page Locate the 3.75G USIM card cover and loosen screw , and then remove the Figure 7 - 17 USIM card cover USIM Card Cover Removal ...
Page 144 Modules & Options Lock the SIMLOCK by pushing it in the direction of the arrow in Figure 7 - 19 until it clicks into the lock position. Figure 7 - 19 SIMLOCK Lock  3.75G/HSPA Modules & System Wake Up Note that the 3.75G modules DO NOT sup- port system wake up on...
Page 145 Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see Table 1 - 4, on 10) to toggle power to the 3.75G/HSPA module.
Page 146: Mobile Partner
Modules & Options Mobile Partner  With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard Aircraft puter.
Page 147: Mobile Partner Application
Modules & Options Mobile Partner Application  You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn +...
Page 148 Modules & Options Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. Access the Mobile Partner application from the Start menu (Start > Programs/ All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop The software will run and you can select the Profile Name from the menu.
Page 149 Modules & Options When the connection is successful you can move the cursor over the network icon in the taskbar to display the connection information. Figure 7 - 23 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
Page 150 Modules & Options To disconnect click the Disconnect icon, or right click the taskbar icon and select Disconnect. Figure 7 - 24 Disconnect 10. The program will disconnect from the service provider. 11. The module will still be on, and you will need to press the Fn + key combination to turn it off.
Page 151 Modules & Options 12. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection. Figure 7 - 25 Exit Prompt 13. Exiting the program terminates the connection, but DOES NOT turn off the 3.75G/ HSPA module, and you will need to press the Fn + key combination to turn off the module (pay careful attention to this aboard aircraft - see...
Page 152: Text Messaging Service
Modules & Options Text Messaging Service In addition to standard internet services you may also send and receive SMS text messages using the Mobile Partner program, if your service supports SMS. Reading SMS Messages An icon will blink at the bottom of the Mobile Partner interface to notify you of any new messages received.
Page 153: Bandluxe Hsdpa Utility
Modules & Options BandLuxe HSDPA Utility  With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the BandLuxe HSDPA Utility. The BandLuxe HS- Wireless Device DPA Utility allows you to directly access your HSPA internet service from the com- Operation Aboard puter.
Page 154: Bandluxe Hsdpa - Connection Manager
Modules & Options BandLuxe HSDPA - Connection Manager The connection information is stored on the USIM card supplied by the service pro- vider (where this is not the case you may need to create a profile - see “Creating a Profile”...
Page 155 Modules & Options The system will connect to your network (you may need to set your network connection to home, work or public on the first connection). The connected icon will appear at the top of the utility screen. Figure 7 - 27 Connected You can then access the internet, download e-mail etc.
Page 156 Modules & Options While you are connected the taskbar icon will display the connected icon , and the taskbar will display the connected icon Figure 7 - 29 Taskbar Icon (Connected) To disconnect from the service provider, click the Disconnect icon, or click the close icon at the top right of the utility, and click Yes to confirm.
Page 157: Creating A Profile
Modules & Options Creating a Profile Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu > Profile. Figure 7 - 30 Menu - Profile The default profile will display the service provider’s name from the USIM card.
Page 158 Modules & Options Click New (button) and input any Network Settings required by your service  provider (all fields may not need to be filled in). The profile name is used to identify your profile if a number of profiles are used. Password You will need to check with your service provider to confirm if the User Name and Password are required.
Page 159 Modules & Options Click the newly created profile in the profile window and then click Default (button)  to set the profile as the default connection (note that only one profile may be stored as the default connection). 10. The newly created profile will now be stored as the default connection when you New SIM Card click Connect in the Connection Manager Home screen.
Page 160: Choosing A Profile
Modules & Options Choosing a Profile If you need to switch stored profiles follow the instructions below: Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu >...
Page 161: Editing A Profile
Modules & Options Editing a Profile  If you need to edit stored profiles follow the instructions below: Get the Latest Access the Connection Manager from the Start menu (Connection Manager Access Point Name ), or (Start > Programs/All Programs > BandLuxe > BandLuxe Database HSDPA Utility R11 >...
Page 162: Text Messaging Service (Sms)
Modules & Options Text Messaging Service (SMS)  In addition to standard internet services you may also send and receive SMS text messages using the Connection Manager, if your service supports SMS. Incoming Messages Inbox If the program is open The Inbox will contain any received SMS.
Page 163 Modules & Options Sent  The Sent folder contains any successfully sent SMS. Select the message and press the Delete to erase the record. Contact List Types Outbox Select a contact The Outbox folder contains any completed but unsent SMS. Select the message and from the SIM card.
Page 164 Modules & Options Template A template can store text that is used regularly in messages, and can be easily insert- ed in to any new SMS. Click Template (button) to view any stored templates. Click to highlight a template and click Select (button) to insert it into the message. Click New (button) to create a new template, and Save (button) to add it to the existing list.
Page 165: Setting
Modules & Options Setting  The Setting menu allows you to edit the programs basic parameters. Access the Connection Manager from the Start menu (Connection Manager Language ), or (Start > Programs/All Programs > BandLuxe > BandLuxe The Connection Manager HSDPA Utility R11 >...
Page 166 Modules & Options SMS - Preference Click the New SMS Notify checkbox to be automatically notified when a new SMS arrives. If enabled a the incoming message notification will appear in the taskbar, Figure 7 - 40 Incoming SMS Notification and an envelope icon will appear in the upper left corner of the Home screen when a new message arrives.
Page 167 Modules & Options This menu allows you to edit the USIM card Personal Identification Number (PIN) and Enable/Disable the PIN if necessary. Press Apply after making any changes. A SIM card must be inserted for this function to be activated. Figure 7 - 42 Setting - SIM If a PIN code is enabled, the input will be requested during USIM card initialization.
Page 168 Modules & Options Radio Set the appropriate network search options from the dual mode setting menu. Click Apply (button) after making any changes. Figure 7 - 43 Setting - Radio Note: 2G/3G/3.5G data transferring will be disconnected when you apply a new Ra- dio setting.
Page 169 Modules & Options Network - Network Selection Edit the network selection settings from this menu. The Standard (auto) setting will  search for networks in the order specified in the Prefer list. Click Standard (auto) Network Setting > Next to view and adjust the Prefer list. The Prefer list is displayed at the top of the screen, and the bottom of the screen lists all available networks.
Page 170 Modules & Options The Manual setting allows you to choose a network from all available. Click Man- ual > Next to view the list. Click to highlight a network from the list, and click Se- lect (button) to choose the network, or Cancel (button) to make no change. Figure 7 - 45 Setting - Network Manual...
Page 171: Statistics & Information
Modules & Options Statistics & Information The Statistics screen displays a graph of recent upload and download activity. No data will be displayed if there is no current connection. Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 >...
Page 172: Pc Camera Module
Modules & Options PC Camera Module  Before installing the PC Camera driver, make sure that the optional PC Camera is Latest PC Camera on. Use the Fn + F10 key combination (see “Function/Hot Key Indicators” on Driver Information 10) to toggle power to the PC Camera module. Make sure you install the page 1 - drivers in the order indicated in Table 4 - 1, on page 4 -...
Page 173: Pc Camera Driver Installation
Modules & Options PC Camera Driver Installation  1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive. PC Camera Screen 2. Click Option Drivers (button). Refresh 3. Click 4.Install Camera Driver > Yes. The PC Camera module 4.
Page 174 Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 175 Modules & Options Figure 7 - 47 Audio Setup for PC Camera Right-click PC Camera Module 7 - 53...
Page 176 Modules & Options Camera Application  The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Pre-Allocating File Space Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see Set Capture File below).
Page 177 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 178 Modules & Options Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 179 Modules & Options Zoom The camera application allows you to zoom the camera in and out (note the zoom function is not available in all camera model applications). Run the camera application from the desktop shortcut. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 49 Zoom/Setting ...
Page 180: Bluetooth Module
Modules & Options Bluetooth Module  There are two Bluetooth module options available for this computer. If your pur- Wireless Device chase option includes the Combination Wireless LAN & V3.0 Bluetooth module Operation Aboard then install the driver as instructed overleaf (see “Bluetooth &...
Page 181: Bluetooth Combo Driver Installation
Modules & Options Bluetooth Combo Driver Installation  Note this driver is required only for the combo Bluetooth and WLAN module only. High Speed Bluetooth 1. Make sure the module is powered on, then insert the Device Drivers & Util- Data Transfer ities + User’s Manual disc into the CD/DVD drive.
Page 182: Bluetooth & Wlan Combo Settings
Modules & Options Bluetooth & WLAN Combo Settings  This information applies to the combo Bluetooth and WLAN module only. Bluetooth Module & Make sure the Bluetooth module is powered on. Resuming From Sleep Double-click the My Bluetooth application on the desktop (or access it from the Mode Programs/All Programs menu).
Page 183 Modules & Options Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 51 General Settings Bluetooth Module 7 - 61...
Page 184 Modules & Options Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 52 File Transfer Settings 7 - 62 Bluetooth Module...
Page 185: Bluetooth Networking Setup
Modules & Options Bluetooth Networking Setup This information applies to the combo Bluetooth and WLAN module only. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu). Click My Bluetooth Settings (see Figure 7 - 50 on page 7 - 60).
Page 186: Bluetooth & Wlan Combo Module Configuration
Modules & Options Bluetooth & WLAN Combo Module Configuration  This information applies to the combo Bluetooth and WLAN module only. Bluetooth Module & Setup your Bluetooth Device so the Computer Can Find it Resuming From Sleep Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Mode Make the device discoverable (to do this check your device documentation).
Page 187 Modules & Options You will then be presented with a menu of options to select from. Figure 7 - 55 Bluetooth Device Options Click the appropriate button to connect to the device. Bluetooth Module 7 - 65...
Page 188 Modules & Options You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection.
Page 189: Bluetooth Configuration In Windows 7
Modules & Options Bluetooth Configuration in Windows 7  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click To Turn the Bluetooth Module On Control Panel and then...
Page 190 Modules & Options To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
Page 191 Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 59 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 192 Modules & Options To Change Settings for the Bluetooth Device  Click the taskbar icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Page 193: Troubleshooting
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 194: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 195: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 196: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 197: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 198 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 199: Problems And Possible Solutions
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 200 Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 201 Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 202 Troubleshooting Problem Possible Cause - Solution  Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.
Page 203 Troubleshooting Problem Possible Cause - Solution The PC Camera module cannot be The module is off. Press the Fn + F10 key combination in order to enable the detected. module (see “Function/Hot Key Indicators” on page 1 - 10). Run the camera application to view the camera picture.
Page 204 Troubleshooting Problem Possible Cause - Solution The Card Reader/Network (LAN) Device This is a power saving feature. When not in use the Card Reader/Network (LAN) does not appear in the Device Manager in Device will not appear in the Windows Device Manager as they are not Windows.
Page 205: Bluetooth Connection Problems
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 206 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 207 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 208 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio 8 - 16 Bluetooth Connection Problems...
Page 209: Interface (Ports & Jacks)
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Page 210: Notebook Ports And Jacks
Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
Page 211 Interface (Ports & Jacks) Item Description RJ-11 Phone Jack This port connects to the built-in modem. You may plug the telephone line directly into this RJ-11 telephone connection. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. (Models A & B Only) RJ-45 LAN Jack This port supports LAN (Network) functions.
Page 212 Interface (Ports & Jacks) A - 4...
Page 213: Intel Video Driver Controls
Intel Video Driver Controls Appendix B: Intel Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on  page 1 - DVMT Notes Intel Video Driver Installation DVMT is not local video Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 - memory.
Page 214: Intel Gma Driver For Mobile
Intel Video Driver Controls Intel GMA Driver for Mobile  Advanced video configuration options are provided by the Intel(R) Graphics Me- Taskbar Icon dia Accelerator Driver for Mobile. To access the Intel(R) Graphics Media Accel- erator Driver for mobile control panel: You can also access the controller properties...
Page 215 Intel Video Driver Controls You may make changes to the devices, color, schemes, Hot Keys etc. by clicking  the appropriate menu item or button. Help Menus Right-click on many of the items in the tabs to bring up the “What’s This?”...
Page 216: Scheme Options
Intel Video Driver Controls Scheme Options  Use Scheme Options to configure quick settings for applications which require spe- cific resolution and color settings in order to run properly e.g. games, multimedia Application.exe programs. To set the scheme options: You will need to locate Go to the GMA for mobile control panel (see page the actual application executable (.exe) file,...
Page 217: Display Devices & Options
Intel Video Driver Controls Display Devices & Options  Besides the built-in LCD you can also use an external monitor/flat panel display/TV (TV through HDMI-Out port only), connected to the external monitor port or to the Function Key Combination HDMI-Out port (High-Definition Multimedia Interface) as your display device. The following are the display options: You can use the Fn + F7 key combination to tog-...
Page 218: Configuring An External Display - Intel Gma
Intel Video Driver Controls Configuring an External Display - Intel GMA  If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port or HDMI-Out port on the left of the computer. At least one other dis- To Enable Intel(R) Dual Display Clone Mode play must be attached in...
Page 219 Intel Video Driver Controls To Enable Extended Desktop Mode:  Attach your display to the external monitor port or HDMI-Out port, and turn it on. Go to the Intel(R) GMA Driver for mobile control panel and click Display Display Settings Devices.
Page 220: Configuring An External Display - Win 7
Intel Video Driver Controls Configuring an External Display - Win 7  Attach your display to the external monitor port or HDMI-Out port, and turn it on. Function Key Go to the Screen resolution control panel. Combination Click the Detect button. The computer will then detect any attached displays.
Page 221 Intel Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure B - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 222 Intel Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays + P key combination to quickly change display configura- You can also use the tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 223: Intel Clear Video Technology
Intel Video Driver Controls Intel Clear Video Technology  Intel Clear Video Technology is designed to help users get high-quality video play- TV Wizard back, sharp image quality, precise color control and advanced support for the latest High Definition displays without the need for expensive video cards etc. Use the TV Wizard to configure the external Attach your external display to the external monitor port or HDMI-Out port, and...
Page 224: B - 12 Hdmi Audio Configuration
Intel Video Driver Controls HDMI Audio Configuration As HDMI (High-Definition Multimedia Interface) carries both audio and video sig- nals you will need to configure the audio output as per the instructions below. Windows Audio Setup for HDMI Connect a device with HDMI support to the HDMI-Out port. Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 225 Intel Video Driver Controls To play audio sources through your external display’s (TV or LCD) speakers you will need to go to the audio configuration control panel on the display and configure  the audio input accordingly (see your display device manual). Other Applications HDMI Notes If you are using a third...
Page 226 Intel Video Driver Controls B - 14...
Page 227: Specifications
Specifications Appendix C: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 228: Processor
Specifications Processor Processor (Cont’d) Processor (Cont’d) Intel® Core™ i7-620M Processor: Intel® Core™ i5-450M Processor: Intel® Core™ i3-330M Processor: (2.66GHz) (2.40GHz) (2.13GHz) 32nm (32 Nanometer) Process 32nm (32 Nanometer) Process 32nm (32 Nanometer) Process Technology, 4MB L3 Cache & 1066MHz Technology, 3MB L3 Cache & 1066MHz Technology, 3MB L3 Cache &...
Page 229: Core Logic
Specifications Core Logic BIOS Interface Intel® HM55 Chipset One 32Mb SPI Flash ROM Three USB 2.0 Ports Phoenix™ BIOS One External Monitor Port Display One HDMI Out Port Storage One Headphone-Out Jack 14.0” / 35.56cm 16:9 HD (1366 * 768) One Microphone-In Jack One Changeable 12.7mm(h) Super Multi...
Page 230: Slots
Specifications Slots Communication (Cont’d) Power One ExpressCard 34 Slot Supporting Bluetooth 2.1 + EDR (Enhanced Data Full Range AC/DC Adapter USB & PCIe Interfaces (Factory Rate) Module (Factory Option) AC input 100 - 240V, 50 - 60Hz, Option) DC Output 19V, 3.42A or 18.5V, 3.5A (65 Combo WLAN (802.11b/g/n) and Two Mini-Card Slots with PCIe (Slot 1) &...
Page 231: Environmental Spec
Specifications Design Feature Options IMR (Injected Molded Resin) LCD Back Covers Magic Of Film Art II Changeable LCD Back Covers (Note these covers are applicable only to certain computer models in this series) Environmental Spec Temperature ° ° Operating: C - 35 Non-Operating: -20°C - 60°C Relative Humidity...
Page 232 Specifications C - 6...

Clevo E4120 User Manual

Quick Start Guide

Features & Components

Power Management

Drivers & Utilities

BIOS Utilities

Upgrading the Computer

Modules & Options

Troubleshooting

Interface (Ports & Jacks)

Intel Video Driver Controls

Specifications

Quick Links

Related Manuals for Clevo E4120

Summary of Contents for Clevo E4120
