- Page 1 EVO42 42mm MAGNETIC DRILLING SYSTEM Original Instruction Manual Read instructions before operating this tool. Guard omitted for illustrative purposes only. www.evolutionsteel.com...
-
Page 2: Ec Declaration Of Conformity
EC - DECLARATION OF CONFORMITY We, manufacturer and importer Evolution Power Tools Ltd. Venture One Original Sheffield S20 3FR Instruction Declare that the product Manual Part numbers: EVO42 Evolution: EVO42 Read instructions before operating this tool. 42mm Magnetic Drilling System... -
Page 3: 12 Month Limited Warranty
If you are uncertain about any aspect of using this Evolution Power Tools is not liable for any costs equipment, please contact our Technical Helpline. incurred on such goods or consequential damages. -
Page 4: Health Advice
5. Store idle tools. When not in use, tools should 18. Use outdoor extension leads. When the tool is be stored in a dry locked-up place, out of reach of used outdoors, use only extension cords intended children. for outdoor use and so marked. 6. -
Page 5: Specific Safety Rules
WARNING: Do not use the machines cutting head drill bits or cutters. as a ‘lifting point’. N) Reduce the risk of unintentional starting. Make sure switch is in off position before plugging in. O) Use recommended accessories. Only use genuine Evolution accessories. www.evolutionsteel.com... -
Page 6: Labels And Symbols
Wear Ear Protection to protect the operator are based on an estimation of exposure in the actual conditions of use (taking Only use genuine Evolution replacement parts. account of all parts of the operating cycle, such Unauthorized parts may be dangerous! -
Page 7: Items Supplied
EVO42 ASSEMBLY Your Evolution Power Tools saw is shipped complete. Remove all contents from the box and FIG 1 inspect to ensure no damage was incurred during shipping, and that the items listed below are included. ITEMS SUPPLIED Description Quantity... - Page 8 GETTING STARTED The optional chuck adaptor (part HTA 47) can be WARNING: Always Disconnect The Machine fitted into the EVO42 machines arbor, and then the From Power Source Before Making machine can be fitted with a standard 3 jawed self Adjustments.
-
Page 9: Operating Advice
EVO42 etc, should be removed from the work area before 1. Using the supplied 3mm Hex Key slightly loosen the machine is positioned. 10 mm is the optimum the 3 cap screws. (Fig. 6A shows 1 of the cap material thickness for safe operation. Keep the screws). -
Page 10: Maintenance
the machine and allow to run up to full speed. MAINTENANCE 5. Turn the crank handle to begin cutting. Use light pressure at first to keep the cutter from wandering, and then gradually increase until normal Note: Any maintenance must be carried out with pressure is being applied. - Page 11 EVO42 www.evolutionsteel.com...
- Page 12 UK 25.10.11...
