Table of Contents
1. Please read these instructions .......................................... 2
What's in the Quick Start Guide? ................................................. 2
What's in the User Manual? .......................................................... 2
2. Package contents .............................................................. 2
3. Select and prepare the installation location .................... 3
4. Installing the swivel base .................................................. 4
Important safety notes ................................................................... 4
Installing the swivel base ............................................................... 4
5. Getting to know your display .......................................... 5
Front view ...................................................................................... 5
Control panel (right side view) ..................................................... 6
External AV devices terminal panel (left side view) .................... 7
Rear view ........................................................................................ 8
6. Making connections ......................................................... 9
Input options ................................................................................. 9
Connecting the Composite Video input ...................................... 10
Connecting the S-Video input ...................................................... 10
Connecting the Component Video input .................................... 11
Connecting the PC D-Sub input .................................................. 11
Connecting the DVI input ............................................................ 12
Connecting the HDMI input ........................................................ 12
Connecting the stereo audio output ............................................. 13
Connecting the headset audio output .......................................... 13
7. Connect the power cable .................................................. 14
8. Adjust the viewing angle .................................................. 14
9. Basic operations ................................................................ 15
Power on, off and standby ............................................................ 15
Switching inputs ............................................................................ 15
Adjusting volume .......................................................................... 15
Care and cleaning information ............................................ 16
What's next? .......................................................................... 16
OSD (On-Screen Display) menu .......................................... 18
OSD structure ....................................................................... 18
Navigating the OSD menu ................................................... 19
Operations in the OSD menu ....................................................... 19
Audio menu .......................................................................... 20
Table of Contents
i
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BenQ VB2621
Summary of Contents for BenQ VB2621
-
Page 1: Table Of Contents
Table of Contents Section 1: Quick Start Guide 1. Please read these instructions .......... 2 What’s in the Quick Start Guide? ..........2 What’s in the User Manual? ............2 2. Package contents .............. 2 3. Select and prepare the installation location ....3 4. - Page 2 Setting up Personal EQ Mode ............21 Picture menu .................22 Using the Picture Modes ............... 24 Adjusting the contrast ..............24 Adjusting the brightness ..............24 Setting up the Personal Picture Mode .......... 24 Senseye menu ................25 Setup menu ................26 Reference ................
-
Page 3: Section 1: Quick Start Guide
VB Series LCD Display Section 1: Quick Start Guide Welcome... -
Page 4: Please Read These Instructions
Please read these instructions Congratulations. You have a state-of-the-art flat widescreen digital LCD display which should provide you with years of viewing pleasure. Please take a few minutes to read these quick start instructions through before installing and using the display. What’s in the Quick Start Guide? Section 1 contains the Quick Start Guide which provides you with enough information to get familiar with and setup the display. -
Page 5: Select And Prepare The Installation Location
Select and prepare the installation location In order to prevent potential dangers and prolong the service life of the display, please observe the following points when installing, operating and cleaning the display. All Liquid Crystal Display (LCD) Do NOT place the display on an screens have a very thin protective uneven, sloping or unstable layer of glass which is liable to... -
Page 6: Installing The Swivel Base
4. Installing the swivel base Important safety notes Please pay attention to the following before installing: • For safety reasons, it is recommended that the installation be carried out by at least two adult persons. • The LCD panel of the display is extremely fragile and subject to damages easily. -
Page 7: Getting To Know Your Display
4. Rotate the swivel base counter- clockwise until it is stopped by the tenon on the display. 5. Carefully lift the display upright and check the installation. Move the display to the position where it will be placed. 5. Getting to know your display Front view Name Description... -
Page 8: Control Panel (Right Side View)
Control panel (right side view) No. Name Description Toggles the display between standby mode and on. See (Power/standby) "Power on, off and standby" on page button Displays the OSD (On-Screen Display) menu if not visible, or exits the current menu if displayed. See button MENU "Navigating the OSD menu"... -
Page 9: External Av Devices Terminal Panel (Left Side View)
External AV devices terminal panel (left side view) VB3222 / VB3223E VB2621 No. Name Description Digital tuner slot Reserved for the optional digital tuner. • VIDEO: Connect to the Composite Video (AV) output as appropriate for your AV source device. See "Connecting the... -
Page 10: Rear View
Rear view VB2621 VB3222 / VB3223E No. Name Description Connect to the DVI digital video or HDMI digital audio/video output of your digital source device. See HDMI/DVI "Connecting the DVI input" on page 12 "Connecting the HDMI input" on page Connect each to the Component Video (Y C ) output of an appropriate video source device. -
Page 11: Making Connections
6. Making connections Input options There are multiple sockets on the display for video/graphic and their corresponding audio inputs (see also "External AV devices terminal panel (left side view)" on page 7 "Rear view" on page 8). With these sockets, this display supports the simultaneous connection of several different types of signal sources, and permits you to select whichever one of the available sources you wish to view at any time by pressing... -
Page 12: Connecting The Composite Video Input
Connecting the Composite Video input Connect the Composite Video output of your output equipment (like a VCR) to the AV2 VIDEO and AUDIO L/R terminals on the display using the Composite Video cable as illustrated. A Composite Video cable consists of three connectors: Yellow (video), White (left channel audio), and Red (right channel audio). -
Page 13: Connecting The Component Video Input
Connecting the Component Video input 1. Connect the Component Video output of your output equipment (like a TV game console) to the display's AV1 Y, C terminals using a Component Video cable (not provided). A Component Video cable consists of three plugs: Green (Y), Blue (C ), and Red (C 2. -
Page 14: Connecting The Dvi Input
Connecting the DVI input 1. Connect the digital video output of your output equipment (like a PC or DVD player) to the HDMI/DVI terminal on the display using a DVI to HDMI adaptor cable (not provided). 2. Connect the DVI audio output of your output equipment to the display's DVI- AUDIO INPUT L/R input terminals using a suitable RCA type audio cable. -
Page 15: Connecting The Stereo Audio Output
Connecting the stereo audio output This display provides a set of stereo audio output terminals (RCA type) for delivering the audio signal to a sound system or other audio devices. 1. Connect the audio input terminals of an amplifier or other audio device to the AUDIO OUTPUT L/R terminals on the display using a suitable RCA type audio cable. -
Page 16: Connect The Power Cable
POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. Please handle this display with care. If damaged, turn off the power and unplug the power cable from the display. Transport the display to your nearest BenQ authorised service centre for repair. 8. Adjust the viewing angle This display is equipped with an adjustable swivel base. -
Page 17: Basic Operations
9. Basic operations Power on, off and standby Make sure that the display is connected to the power outlet and switched on (if the power outlet is switched). Turning the display on After plugging the display's power cable into a wall outlet, the display will enter standby mode automatically. -
Page 18: Care And Cleaning Information
Care and cleaning information • Always turn off the display and disconnect it from the mains power before cleaning. • Do NOT use cream, liquid, aerosol or spray cleaners. Use only a slightly damp well wrung-out (drip-free) and lint-free, clean soft cloth and lightly wipe the display. -
Page 19: Section 2: User Manual
VB Series LCD Display Section 2: User Manual Welcome... -
Page 20: Osd (On-Screen Display) Menu
OSD (On-Screen Display) menu OSD structure Input signal type HDMI Menu AV2 (AV2-S) Video Video PC mode mode mode mode • Volume • Balance • Sound Type • Steady Sound Audio • Surround • Speaker Out • Advanced Audio Settings •... -
Page 21: Navigating The Osd Menu
Navigating the OSD menu You can use the On-Screen Display (OSD) menu to adjust the settings on your display. To display the OSD menu, press on the display. MENU Picture Audio Senseye Setup Operations in the OSD menu • Press Selection) Selection) VOL (Volume) -
Page 22: Audio Menu
Audio Volume Audio menu Balance Sound Type Stereo The available menu items are Steady Sound dependent on the input source being selected. Surround The illustration is for reference Speaker Out only. Advanced Audio Settings > 回上頁 Item Function Operation Range Adjusts the volume level of Press to increase or... -
Page 23: Setting Up Personal Eq Mode
• Rock • JAZZ To restore a factory preset Press VOL+ VOL- or user customised EQ • Classic EQ Mode change selection. Mode. • POP • Personal Adjusts treble tones for the Treble EQ Mode. Personal Adjusts mid-treble tones for Mid Treble EQ Mode. -
Page 24: Picture Menu
Picture Picture Mode Standard Contrast Picture menu Brightness Color The available menu items are dependent on the input source Sharpness being selected. Color TEMP. Normal The illustration is for reference Backlight only. NTSC Tint NTSC Setup 7.5 IRE 回上頁 Item Function Operation Range... - Page 25 Press VOL+ sharper image, Sharpness Adjusts image sharpness level. 0 to 6 for softer VOL- image. • Warm Adjusts the color tint of the Color Press VOL+ black and white part of the • Normal TEMP. to make VOL- image. •...
-
Page 26: Using The Picture Modes
Using the Picture Modes You can choose a Picture Mode to suit your viewing condition: Picture Mode Description Suitable for viewing in environments with normal lighting Standard condition. In this mode, the contrast and levels of colors are optimized in Cinema order to display more details in the bright and dark areas of images. -
Page 27: Senseye Menu
Senseye menu Black Extension The available menu items are dependent on the input source being selected. Noise Reduction The illustration is for reference only. 回上頁 Item Function Operation Range Enhances the contrast among • Low details when viewing dark images. •... -
Page 28: Setup Menu
Setup Setup menu Language English Sleep Timer The available menu items are dependent on the input source HDMI/DVI Input being selected. Blue Screen The illustration is for reference only. Reset All Settings 回上頁 Item Function Operation Range • English Select your desired language for the OSD Language menu. -
Page 29: Reference
Disclaimer BenQ Corporation makes no representations or warranties, either expressed or implied, with respect to the contents of this document. BenQ Corporation reserves the right to revise this publication and to make changes from time to time in the contents thereof without obligation to notify any person of such revision or changes. - Page 30 VB3222 VB3223E Unit: mm Reference...
-
Page 31: Specifications
Specifications Model VB2621 VB3222 VB3223E With swivel 11.68 Kg 15.04 Kg 14.5 Kg Weight Without swivel 10.98 Kg 14.34 Kg 13.7 Kg 725.6 × 579.7 × With swivel 845.2 × 655.3× 220 mm 220 mm Dimensions (W × H × D) 725.6 ×... -
Page 32: Supported Pc (D-Sub/Dvi) Input Signal Resolutions
Supported PC (D-Sub/DVI) input signal resolutions Horizontal Vertical Dot Clock Resolution Frequency Frequency Frequency Note (KHz) (Hz) (MHz) 720 × 400 31.47 70.08 28.322 640 × 480 31.5 25.18 640 × 480 37.5 31.5 640 × 480 37.86 72.81 31.5 800 ×... -
Page 33: Supported Hdmi Input Signal Resolutions
Supported HDMI input signal resolutions Horizontal Vertical Dot Clock Resolution Frequency Frequency Frequency Note (KHz) (Hz) (MHz) 720 × 480i 15.735 SDTV 480i 720 × 480p 31.47 74.25 EDTV 480p 720 × 576i 15.625 EDTV 576i 720 × 576p 31.25 74.25 EDTV 576p 1280 ×... -
Page 34: Troubleshooting
Troubleshooting There are many external influences and circumstances beyond the control of BenQ which may be causing problems with your display. Some of the more common and user fixable problems are listed below for your information. Please check the following list before calling your nearest BenQ Customer... - Page 35 • Ensure the display's aspect ratio is correctly set to suit the image source. The image appears • Try a different input source to confirm if the symptom is distorted still present or whether the source is at fault. • Lower the setting.
- Page 36 <Memo> Reference...
